Samsung T220HD Service Manual page 39

5. Exploded View & Part List
Level Location No.
......6 D1
......6 D0254
......6 R1
......6 C
......6 T0077
....4
.....5
.....5 T0174
......6 R1
......6 C1
......6 C5
......6 CN330
......6 CN330
......6 CN906
......6 IC125
......6 T0077
...3 M0102
0.1 M0002
..2 M0013
...3 M0081
...3
...3 CCM1
...3 M0006
...3 T0071
...3 T0530
....4 CCM1
....4 T0151
..2 M0081
0.1 M0107
..2 M0215
0.1 M0112
..2 M0523
...3 T0279
...3 T0578
..2 M0090
...3
...3 M0125
..2 CIS1
..2 CIS1
0.1 M0017
..2 M0081
..2 M0174
..2 M0014
...3 SUB05
...3 T0245
...3 CN500
...3 CN501
5-4
Code No.
0403-000510 DIODE-ZENER;MTZJ6.2B,5.96-6.27V,500mW,DO
0609-001204 MODULE REMOCON;HORIZONTAL,6.5mm,TR
2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
2401-001507
BN41-01013A PCB MAIN;T220D,FR-1,1L,PCB1.0,1.6T
BN94-02473N ASSY PCB MAIN-POWER PCB;LS22TDSSUMZD
BN81-02334A A/S-DOUBLE SIDE TAPE;T MFM POWER,103*52,
BN97-02902K
2007-000819 R-CHIP;390Kohm,5%,1/10W,TP,1608
2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608
3711-002162 HEADER-BOARD TO CABLE;BOX,2P,1R,1.25mm,S
3711-005935 HEADER-BOARD TO CABLE;BOX,4P,1R,1mm,SMD-
3711-006471 CONNECTOR-HEADER;BOX,5P,1R,1mm,SMD-A,AU,
BN13-00007A IC ASIC;ADA03,6,2.2 TO 6.5 V,-20 TO +75
BN41-01012A PCB MAIN;T220D,FR-4,2L,PCB1.0,1.6T
BN96-07569B ASSY BLU P;T220HD,A7-10040180-A0,WHITE,B
BN90-01611B ASSY COVER REAR;LS22TD_MFM,USA
BN96-07408C ASSY COVER P-REAR;LS22TD,USA_KOR,PMMA AB
6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW
BN61-03947A GUIDE-CONTROL;T200D / T220D / T240D / T2
BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20
BN63-04408A COVER-REAR;T220HD,PMMA ABS,HB,BK23,H/GLO
BN64-00875A INLAY-TERMINAL;T220D,PS SHEET,T0.3,-,-,-
BN96-08054A ASSY COVER P-DOOR CONTROL;LS22TD,PMMA AB
BN63-02183B COVER-SHEET;Rhcm,PE Vinyl,T0.05,150mm,20
BN64-00859B DOOR-CONTROL;LS22TD(MFM),PMMA ABS HB,BK2
6003-001086 SCREW-TAPTITE;BH,+,-,B,M3,L12,ZPC(BLK),S
BN91-01517P
BN07-00427A
BN91-02209B ASSY SHIELD;LS22TD_MFM,TOC,USA
BN96-07409B ASSY COVER P-JACK;LS22TD,ADC(USA),PC+ABS
BN63-04402A COVER-JACK;T220D / T200D,PC+ABS,5V,BK23,
BN64-00862B
BN96-08017A ASSY SHIELD P-LAMP;LS22TD(MFM),SPTE,T 0.
BN63-04401A SHIELD-LAMP;T(22W MFM),SPTE,T 0.3
BN63-04770A
BN74-00021A TAPE-FILAMENT;Filament tape,clear,#8915,
BN74-00021A TAPE-FILAMENT;Filament tape,clear,#8915,
BN91-02236A
6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW
BN44-00177C IP BOARD;SIP-20224L,T 22" MFM,1.4 ~2.8mA
BN94-01764A ASSY PCB MAIN-CTZ;LS22TDNSUV/ZA
0202-001477 SOLDER-CREAM;LST309-M,-,D20~45um,96.5Sn/
0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0.
3701-001385 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU
3701-001386 CONNECTOR-DVI;24P,3R,FEMALE,AU
Description & Specification
C-AL;47uF,20%,16V,GP,TP,6.3x5,5
ASSY SMD;LS22TDSSUMZD
ASSY LCD-CTZ;LS22PEB*
LCD-PANEL;M220Z1-L03
INLAY AV;T220HD,PS SHEET,T0.5
SHIELD-PANEL;LS22TD,SPTE,T0.3
ASSY CHASSIS;LS22TDNSUV/ZA
Q'ty SA/SNA Remark
1 S.A
1 S.N.A
1 S.N.A
1 S.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.A
1 S.N.A
1 S.A
1 S.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.A
1 S.N.A
1 S.A
2 S.N.A
2 S.N.A
0.5 S.N.A
1 S.N.A
1 S.N.A
1 S.A
0.07 S.N.A
1 S.N.A
4 S.A
1 S.N.A
1 S.A
1 S.N.A
1 S.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
0.06 S.N.A
0.06 S.N.A
1 S.N.A
1 S.N.A
1 S.A
1 S.A
2.104 S.N.A
0.25 S.N.A
1 S.A
1 S.A
