Summary of Contents for ALLEN & HEATH GL 2000
-
Page 2: Limited One-Year Warranty
LIMITED ONE YEAR WARRANTY This product has been manufactured in the UK by ALLEN & HEATH and is warranted to be free from defects in materials or workmanship for a period of one year from the date of purchase by the original owner. To ensure the high level of performance and reliability for which this equipment has been designed and manufactured please read this User Guide before use. -
Page 3: Service And Technical Support
INTRODUCTION The GL2000 continues ALLEN & HEATH’s commitment to provide high quality audio mixing consoles engineered to meet the exacting requirements of today’s audio business. It brings you the latest in high performance technology and offers the reassurance of over two decades of console manufacture and customer support. This user guide presents a quick reference to the function, application and installation of the GL2000. -
Page 4: Earthing The Audio System
CONNECTING AC MAINS TO THE CONSOLE Refer to the SAFETY WARNING on the first page of this User Guide. Mains input to the GL2000 is via a standard 3 pin IEC mains input connector. A mains cable with moulded mains plug suitable for the local supply is supplied. -
Page 5: Plugging Up The Cables
PLUGGING UP THE CABLES Where possible use balanced connections to prevent noise and interference pickup especially on long microphone cable runs. Avoid running audio cables next to AC mains, computer or lighting cables, near thyristor dimmer units or power supplies etc. The use of low impedance sources such as good quality microphones of 200 ohms or less significantly reduces interference pickup. - Page 6 The ALLEN & HEATH GL2000 represents a breakthrough in price versus performance and functionality. It offers the professional user a new level of versatility to quickly adapt to the exacting demands of live sound engineering today. The GL2000 is developed from the very successful GL3 console which first introduced the innovative 'mode switching' that quickly converts the console from Front-of-House to On-stage Monitor operation.
-
Page 8: Specification
THE RANGE 12, 16, 24 and 32 channel models. GL2000-412 10 mono, 2 stereo, 4 groups, 6 aux, 2 stereo returns, L,R, Mono sum GL2000-416 14 mono, 2 stereo, 4 groups, 6 aux, 2 stereo returns, L,R, Mono sum GL2000-424 22 mono, 2 stereo, 4 groups, 6 aux, 2 stereo returns, L,R, Mono sum GL2000-432 30 mono, 2 stereo, 4 groups, 6 aux, 2 stereo returns, L,R, Mono sum... -
Page 15: Internal Link Options
INTERNAL LINK OPTIONS The console is set to satisfy most applications that should be encountered. However, the following internal link options are offered to provide alternative settings for those applications that may require them. These options involve resoldering of circuit board links and should only be carried out by competent technical personnel. Further information is available in the GL2000 SERVICE MANUAL and from your agent.
