Page 1: Operating Instructions
Operating Instructions Temperature Controller OUT1 ONTENTS section page R 38 – Description Operation Process Timer (if fitted) See also the main manual for the oven or other product to which the controller is fitted. MC24 - 1.00... - Page 2 1.1. R38 - PID This is a PID version of the R38 PID controller by Technologic. The PID control produces pulsed power to the elements. It features simple adjustment of the setpoint, a large display of the current temperature, and an indication of when heating is occurring.
- Page 3 R38 Controller To alter the setpoint, press the up or down arrow key once, “SPI” flashes. Then use the up and down arrow keys to adjust the setpoint. Press the P key to accept. 3. P ROCESS IMER IF FITTED...
- Page 4 R38 Controller 3.1. Overtemperature Control (if fitted) The hydraulic thermostat overtemperature controller should typically be set at 15°C above the main controller. If an overtemperature condition occurs, always investigate the possibility that the main control system has failed. An overtemperature condition always cuts off power to the heating elements. To reset the condition, first either allow the oven to cool, or increase the overtemperature setting.
- Page 5 Thank you for reading this data sheet. For pricing or for further information, please contact us at our UK Office, using the details below. UK Office Keison Products, P.O. Box 2124, Chelmsford, Essex, CM1 3UP, England. Tel: +44 (0)1245 600560 Fax: +44 (0)1245 808399 Email: sales@keison.co.uk...
