Win eNet200 Reference Manual

IP580 Buttons & Controls applicable for 4 IP500 and
Displays information such as extension number, name, current time,
1 LCD display call status, caller ID, number of new messages, number of missed
calls and other settings.
Press to access call history mode, and then press
to select missed calls, received calls, or dialed calls. Press
to display the further details of call status.
Menu keys
2
Press and hold
mode, press
scroll through setting items.
Increases or decreases the volume of handset, headset, or
3 Volume buttons
speakerphone.
4 Ringer buttons Increases or decreases the ringer volume.
Can be programmed as CO line, CO group, extension, extension group
or other functions such as conference, page, park, login or logout.
When defined as CO lines or extensions, the LED displays different
colors to indicate different status:
[ No light ]
5 Programmable buttons
[ Steady green ]
[ Flashing amber ]
[ Flashing red ]
The programmable buttons can be configured through InterClient's
Button Mapping.
When the Intercom Button flashes, it indicates an incoming call
Intercom from another extension. You can also directly press the Intercom
6
Button to place internal calls.
7 Key pad Same as on traditional phones.
When the Message Button light is on, it indicates that you have
Message button
8
new messages. Press Message Button to access Voice Mailbox.
9 Auto- Answer button When selected, the phone answers calls automatically.
Press DND to activate Do-Not-Disturb function. Callers will be
DND button
10
forwarded to your Ring-No-Answer setting.
During a conversation, press Mute Button to turn off your
Mute button
11
microphone. The caller will not hear your voice.
To receive or make calls without using the handset.
Speakerphone button
12
( On IP500 and S300X, it is handsfree dialing. )
13 Redial button Press to redial the last external number you dialed.
14 Hold button Press to hold a call, or press again to retrieve the call.
During a call, press to transfer a call to another extension. Or
15 Transfer
press again to retrieve the call.
IP500 Buttons & Controls applicable for 4 S300X
5 Phone Book Uses as a record of personal phone book.
9 Conference Button Press to initiate a conference call with parties who are on hold.
During a call, press Rec/Play Button to record the call. When
11 Rec/Play Button
on-hook, press Rec/Play Button to play recordings.
4 S300X
or
again
for 3 seconds to access setup mode. In setup
to edit or save settings, or press or to
The line is available to use.
The line is in use (off-hook or busy).
The line is on hold.
The line is ringing.
Telephone Reference Guide Telephone Reference Guide
4
Please refer to the diagram below for tips and configuration.
4
4
4
7
4 4
4 4
4
4 4

InterClient

4
1.
Enter the InterServer IP address on the web browser. Once the page is accessed, click on User
Login icon to access InterClient. Or launch the InterClient Utility program and input the InterServer
4 4
IP address. ( Please consult your administrator
4 4
for InterServer IP address. )
4 4
2. Enter your extension number under Extension
4 4
No. item.
3. Under Password, enter your password.
( The default password is blank. )
4
4.
A list of available features such as Button
Mapping, Speed Dial, Answer Option, Mailbox,
Notification, Distribution List and Change
Password will be available.
1
4
9
10
11
15
12
14
13
Communication System Communication System
2
3
5
4
6
8
IP500
S300X
