Weed Eater SoundStation User Manual

PARTS LIST NO.
530- - 082553
REPLACES
DATE
10/25/95 530- - 068262- - 5/25/9 5
2.
3.
4.
5.
56.
11.
31.
13.
17.
18.
19.
20.
23.
22.
26.
21.
27.
19.
28.
Ref. Part No. Description
1. 530- -015810 Screw- -Shroud
2. 530- -036345 Shroud
3. 530- -029929 Crankcase Cover
4. 530- -019181 Gasket- -Shrd./C'case
5. 530- -014307 Crankshaft Ass'y.
6. 530- -032125 Inner Bearing
7. 530- -015945 Retainer- -C'case
8. 530- -019179 Crankcase Seal
9. 530- -032124 Outer Bearing
10. Crankcase Ass'y. (Incl.
L
6- -9)See Ser. Ref. 1
11. 530- -015941 Retaining Ring
12. 530- -016080 Screw- -Pulley
13. 530- -039149 Flywheel Ass'y.
14. 530- -036145 Spacer- -Ignit. Mod.
15. 530- -039163 Ignition Module
16. 530- -015954 Screw- -Ignit. Mod.
17. 530- -047570 Spring- -Starter Dog
n
18. 530- -029939 Starter Dog
19. 530- -015828 Washer
20. 530- -015930 Flywheel Spacer
21. 530- -069232 Rope Kit
22. 530- -015963 Retainer
23. 530- -015496 Screw- -Retainer
24. 530- -069353 Starter Pulley
25. 530- -029395 Starter Spring
26. 530- -027569 Starter Handle
27. 530- -015886 Screw- -Fan Housing
=
n NEW PART NUMBER FOR THIS IPL
=
D THESE PARTS ARE ILLUSTRATED FOR CLARITY.
WEED EATER PARTS LIST
PARAMOUNT
POULAN
POULAN PRO
Note: Illustration may differ from actual model due to design changes
1.
6.
10.
7.
8.
39.
9.
37.
61.
38.
14.
55.
16.
32.
15.
12.
24.
25.
29.
30.
35.
Ref. Part No.
28. 530- -014396
29. 530- -014361
30. 530- -019182
31. 530- -015882
32. 530- -029930
33. 530- -023877
34. 530- -036180
35. 530- -015934
36. 530- -069352
37. 530- -019223
38. 530- -029924
39. - -
530- -069350
530- -069613
40. 530- -015953
41.
L
42. - -
952- -030078
530- -030075
43. 530- -019185
44. 530- -036191
45. 530- -016014
46. 530- -014384
47. 530- -015775
48. 530- -019194
49. 530- -036192
=
REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
K
ORDER COMPLETE ASSEMBLY.
R R
R R
PARTS LIST
r PARTS LIST
PARTS LIST
33.
59.
58.
45.
44.
43.
40.
41.
42.
34.
36.
Gasket
Kit
57.
Description
Clutch Ass'y. Kit
Fan Housing
Grommet
Screw- -Flywheel
Muffler Spring
Fuel Line Fitting
Muffler Screen
Screw- -Fan Hsg/Shrd.
Muffler Kit
Cylinder Gasket
Piston Ring
Piston Kit
(Incl. 38 & 55)
Type 1
Type 2
Screw- -Cylinder
Cylinder- -See Ser.
Ref l
Spark Plug
Type 1 (CJ- -8Y)
Type 2 (RCJ- -8Y)
Gasket- -Cylin./Carb.
Carb. Adaptor
Screw- -Carb. Adap.
Throttle Cable Ass'y.
Screw- -Cable
Gasket- -Carb. Adap
Air Box
MODEL(s)
GHT17 & GHT22
(N. Am. & Australia)
PAGE NO.
54.
60.
51.
52.
49.
50.
48.
47.
46.
WARNING
All repairs, adjustments
and maintenance not de-
scribed in the Operator's
Manual must be performed
by qualified service per-
sonnel.
Ref. Part No. Description
50. - - Carburetor
530- -035306 Type 1 WT 221
530- -069682 Type 2 WT 379 w/
Limiter Caps
51. 530- -015849 Screw- -Air Box
52. 530- -029934 Air Filter Foam
53. 530- -036193 Air Filter Cover
54. 530- -015635 Screw- -A.F. Cover
55. 530- -015162 Piston Pin Retainer
56. C'case & C'shaft Assy.
L
(Incl. 5 & 10) - -See
Ser. Ref. 1
57. Gasket Kit - - See Ser.
L
Ref. 1
(Incl. 4, 37, 43 & 48)
58. 530- -069599 Fuel Line Kit (Incl.
Fuel and Vent lines)
59. 530- -016103 Retainer Clip
60. 530- -014362 Fuel Pick- -Up Ass'y.
61. 530- -069615 Connecting Rod Kit
Not Shown
Operator Manual
530- -068174 Type 1
Type 2
530- -083474 English
530- -083471 French/English
1
53.
