EXPLODED VIEW PARTS LIST

LOCA. NO
112
6335V21009B
120
121
4810V00088A
150
170
174
300
3091V00B25C
310
5020V00704A
320
330
5020V00703A
400
3809V00A74D
520
6871VMMN97H
913
943
1PTF0403116
PART NO
CPT ASSEMBLY A51QDX992X005 0.4G 0G SDIH ZH 48,ITC
120-C77M
SPEAKER,FULLRANGE 8 OHM 10/15W 130DB 57*117MM
BRACKET,SPEAKER
150-D02X
COIL,DEGAUSSING CU 21 60TURN 12 OHM D02N (NYLON)
170-A01N
CPT EARTH 21 64T 2LUG 1P HSG
174-009E
POWER CORD(W/HOLD,HOUSING,L=200,4.0
CABINET ASSEMBLY STEREO MC019A W/O EYE, W/O TXT
BUTTON,CONTROL
320-062E
SPRING,KNOB
BUTTON,POWER
BACK COVER ASSEMBLY 1SCART C/SKD
PWB ASSEMBLY,MAIN MC019A RE-21FB50RX KUSLMP8
332-057B
SCREW ASSY,HEXAGON HEAD
SCREW,TAP TITE(P)[TRUSS HEAD]
The components identified by mark
critical for safety.
Replace only with part number specified.
DESCRIPTIONS
- 19 -
