UniData Communication Systems WPU-7700 User Manual

Phone
Hide thumbs Also See for WPU-7700:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Administrator's Manual, User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WPU-7700 and is the answer not in the manual?

Questions and answers

Related Manuals for UniData Communication Systems WPU-7700

Summary of Contents for UniData Communication Systems WPU-7700

  • Page 2 User Manual This manual includes product specifications and instructions for Wi-Fi phone operation. This manual must be read before operating the product. A Wi-Fi phone access point is required to use this product. Usage of the Wi-Fi access point provided in the full package is recommended.

  • Page 3: Safety Precautions

    Be sure to use only the designated batteries and accessories provided by our company for the WPU-7700. If you use unauthorized batteries or accessories, it may reduce the life of the WPU-7700, cause explosions or damage. If this occurs, free servicing is not applicable.
  • Page 4 Safety Precautions Do not hold the WPU-7700 close to your ears when turning on the power. This may cause hearing impairments or physical injuries. Do not look at the infrared window in a direct way when using the remote control, as doing so may cause visual impairment.

  • Page 5: Basic Components

    Basic Components Basic Components of WPU-7700 Please check whether the package includes all these items as shown in the picture below after purchasing the phone set. If you find that there is anything missing, please contact your dealer immediately. For safety in use, please purchase authentic products.

  • Page 6: Battery Replacement

    RISK OF EXPLOSION IF A BATTERY IS REPLACED WITH AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. Battery installation method Battery removal If the battery is inserted upside down, the WPU-7700 phone will not work. Please turn off the power before removing the battery from the WPU-7700 phone. (a sudden power shutdown can...

  • Page 7: Battery Charging Signal

    Battery Charging Signal If the battery needs to be charged, it displays , and the beep is sounding. If the beep is sounding, begin charging immediately.
  • Page 8 Time Taking to Charge / Battery Life Time Taking to Charge / Battery Life ※ Battery life varies with the environmental temperature, Model Standard Model battery age and movement of the user. Charging time 150 minutes -Battery life is not permanent.

  • Page 9: Key Features

    Key Features ② ③ Key Name Icon Basic functions Direction key Function of Shortcuts (Alarm, Message, Wi-Fi). ⑫ ⑪ menu viewing, Can be pressed up and down, left and ⑭ right ④ ⑤ Left selection key Submenu operation etc. ②③ Right selection key Function of Left and Right Selection Key ④...

  • Page 10: Display Indicators

    Display Indicators Signal strength Out of call coverage area Call trial or connection Call not available You have selected the sound setting Mute button, displayed when the volume is set to “0” An alarm is set You have one or more unread messages in the Inbox folder Setting to call forwarding service Remaining battery life Full...

  • Page 11: Power On/Off

    Power On / Off If you want to turn on the power, If you want to turn off the power, keep pressing keep pressing for 3 seconds or more. 3 seconds or more. If anything abnormal occurs, or if the power button does not work while using a Wi-Fi phone, start the phone after removing and inserting the battery.

  • Page 12: Making A Call

    Making a call Key in the phone number To delete the number or digit, press the <CLR> button If you have a missed call, press and the last In standby, enter the numeric keys and then press one of those calls will be answered. ※...

  • Page 13: Calling Functions

    Calling functions Write a memo on calling Mute To note something (numbers ONLY) , press the number To mute, select Left Selection Key Menu > Mute On key buttons during a call and select button then you can find the notes in the call list.

  • Page 14: Volume Control

    Calling functions Volume Control Add a Phone Number on calling To adjust receiver volume on calling, select direction To add a phone number on calling , select Left Selection key (Menu) > Save number up and down. To go to the precious screen after adjustment press To find a saved number in the phone book, use the Left or wait for 3 seconds.
  • Page 15 Phone Book Search for a phone number, select the Left selection key ( Menu > Contacts > Search Search all: To search by a part (more than 1 character) of a name, phone number or e-mail address, Select Left selection key > All Then you can enter letters or digits, after entering the letters or digits, all names starting with these letters/digits will be displayed.
  • Page 16 Phone Book To add Phone Numbers, select Left Selection key ( Menu > Contacts > New contacts ) Add a new phone number and other details. Name Save a name. (Up to 16 alphabet characters) Assign a group. Group Use the direction key to assign the group.
  • Page 17 Phone Book You can add a new number in standby mode. Dial a phone number and press the Right Selection Key <SAVE> during stand-by to save phone numbers.
  • Page 18 Phone Book Phone Book 3. To set speed dial, select the left selection ( Menu > Contacts > Speed dial ) Set speed dial numbers for phone numbers saved in the phone book that are frequently called (up to 99 speed dial numbers can be saved). 1.
  • Page 19 Phone Book Group Settings ( Menu > Contacts > Group Settings )+ Edit a group to assign a phone number or add a new group. Select a group to edit and change the group name Group name: Enter a group name (24 alphabet characters) and ring tone.
  • Page 20 Phone Book Group Settings ( Menu > Contacts > Call history) or press the for shortcut to view the call history in stand-by Outgoing calls Incoming calls Missed calls Memo during calling Call block Call forwarding You can see the total number of calls: incoming, outgoing and missed calls up to 100.

  • Page 21: Create A Text Message

    Message message mode, you can read, write and send messages. The messaging service can only be used if it is supported your network or service provider. Left selection key ( Menu > Message ) or press the shortcut key. Create a text message Select menu >...
  • Page 22 Message To set the message display type, alert time and assign a message ringtone, Select the Left selection key ( Menu > Message > Settings) or press the shortcut key. Settings folders My phrase – You can assign your own phrasing up to 10. Display type –...
  • Page 23 Organizer Alarm/Wakeup Call To set an alarm, select left selection Menu > Organizer > Alarm/Wakeup Call Display the current time. Assign the time. Set the alarm time manually. Assign the alarm period. Assign the alarm ringtone. Assign the alarm repeat time.

  • Page 24: World Time

    Organizer Calculator Calendar To use the calculator, select left selection To view the date of the month and year, select left selection Menu > Organizer > Calculator. Menu > Organizer > Alarm/Wakeup Call. provides date choices between January 1970 and December 2020.

  • Page 25: System Alert

    Sounds Ringtone/Vibrate Select left selection Menu > Sounds > Ringtone/Vibrate to choose how the phone notifies you of an incoming voice call. alert type allows you to choose between Ringing (Ringtone), Vibrating and Silent. System alert Select menu > Sounds > System alert to choose how the phone notifies you of low battery, warning and service area sound.
  • Page 26 Sounds Sound effects Select menu > Sounds > Sound effects to assign the key tone sound when turning the phone on/off. Volumes Select menu > Sounds > Volumes to adjust volumes of the receiver.
  • Page 27 Screen Wallpaper To assign the wallpaper, select left selection Menu > Screen > Wallpaper. This feature enables you to set a picture as a wallpaper image in your phone’s stand-by screen. There are 14 built-in pictures for you to change the background image.

  • Page 28: Set Lighting

    Screen Set lighting set the time to dim the display and adjust the brightness of the LCD light, select the left selection key Menu > Screen > Set lighting. • LCD backlight You can set the time to dim the display of the LCD backlight. •...
  • Page 29 Settings Security Manage the data and software on your device, and protect the security of the device and its contents. The default user password is 0000. Select the left selection key Menu > Settings > Security and from the following option: •...

  • Page 30: Call Block Mode

    Settings Call block mode To add and remove a blocked number, select the left selection key Menu > Settings > Call block mode can block up to 3 numbers. Reset to default To reset all preference settings and delete all personal data, such as contacts, messages, WLAN and SIP information, select the left selection key.

  • Page 31: Wlan Search

    If there is no registered Wi-Fi, a default profile will appear VoIP is a default profile. Registered profile WPU-7700 can register Wi-Fi up to 4. Default Profile 1 + Registered from User 3. 2. Display scanned AP list. (Bottom) Results of the WLAN search •...
  • Page 32 Settings WLAN search menu lists • Refresh: Refresh the scanned • Details: Detail information of selected • Add profile: Add new profile. • Delete: Delete selected item ( It displays on the menu when you select registered AP list). • Delete all: Delete all the registered AP list.

  • Page 33: Call Forwarding

    Settings Call forwarding To divert a call to another number, based on different conditions, select the left selection key Menu > Settings > Call forwarding. Activate Call Forwarding: There are four features that you can choose: • All: will transfer all calls under any conditions. •...
  • Page 34 Settings My phone information To view the settings information of the phone, select the left selection key Menu > Settings > My phone info. Network Information Phone Information Displays the IP address, netmask, gateway and My phone number, Firmware version, MAC address.

  • Page 35: Time Format

    Settings Time To change the clock type, time, time zone or date, select the left selection key Menu > Settings > Time. To set the current time automatically, select the Time server and enter the NTP IP in NTP Server1 and 2 then, select Current time and Time Server to <Start>.
  • Page 36 To change the time zone, select the left selection key Menu > Settings > Time > Time zone. The WPU-7700 supports 53 of the capital cities in the world times and selects your location in GMT. Finally the phone will be rebooted.

  • Page 37: Administration Menu

    System Administration Menu set the overall contents of the Administration Menu, select the left selection key Menu > Settings > Admin. Menu > Enter the password. The default administrator password is 000000. Password To change the user or administrator password, select the left selection key Menu >...
  • Page 38 System Administration Menu To view the network status such as WLAN, TCP/IP and PER(Packet Error Rate) between Gateway and DNS and testing DSP, LCD and Speaker, select the left selection key Menu > Settings > Admin. Menu > Diagnostic. It takes about 3 to 5 seconds to finish the each diagnostic process, and all the keys will be...
  • Page 39 System APS address To set up the Auto Provisioning Sever address, select the left selection Menu > Settings > Admin. Menu > APS address. supports HTTP, HTTPs and TFTP. For more information , please refer to the administration manual.

  • Page 40: Voip Setting

    System VoIP Setting Select the left selection key Menu > Settings > Admin. Menu > VoIP setting. You can set the information of the SIP server. SIP Account. If you select VoIP setting, the following options will appear: • Display name – It is the type of the banner as a phone number or a greeting in your phone’s stand-by screen. •...

  • Page 41: Firmware Upgrade

    System Firmware upgrade To set the server address for upgrading firmware, select the left selection key Menu > Settings > Admin. Menu > Firmware upgrade. It could not be upgraded if the firmware version is the same or lower than the current version.

  • Page 42: Web Configuration Tool

    Follow the screen prompts to enter the password for the Web Configuration tool and then click <OK>. 3. You can store frequently used phone number and names in the phonebook. You can also import or export saved information between the PC and WPU-7700.
  • Page 43 PC Sync 4. After displaying the Web Configuration Tool, click the <setup> button above the right side. Follow the screen prompts to enter the user name (admin) and password for administration and then click <OK>. define the settings, please refer to appendix file of the administration manual for the configuration entry.
