COMPONENT loudSpeaker Manual
Manual De Composantes
Models: R65CS
Features
• LAMINATE-TREATED PAPER CONE - Advanced laminating process produces excellent stiffness to weight ratio, superior damping qualities
• 19mm BALANCED DRIVE TWEETER - Excellent reproduction of high frequencies
• POLYMIDE VOICE COIL FORMER - High temperature light-weight voice coil structure for increased sensitivity
• TRIPLE-LAYER UV TREATED FOAM SURROUND - Premium design for long term reliability
• RIGID POWDER COATED STEEL FRAME - Designed for precise motor alignment
© 2010 Phoenix Gold • www.phoenixgold.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R65CS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Phoenix Gold R65CS

Summary of Contents for Phoenix Gold R65CS

  • Page 1 COMPONENT loudSpeaker Manual Manual De Composantes Models: R65CS Features • LAMINATE-TREATED PAPER CONE - Advanced laminating process produces excellent stiffness to weight ratio, superior damping qualities • 19mm BALANCED DRIVE TWEETER - Excellent reproduction of high frequencies • POLYMIDE VOICE COIL FORMER - High temperature light-weight voice coil structure for increased sensitivity • TRIPLE-LAYER UV TREATED FOAM SURROUND - Premium design for long term reliability • RIGID POWDER COATED STEEL FRAME - Designed for precise motor alignment © 2010 Phoenix Gold • www.phoenixgold.com...
  • Page 2 Speaker placement in the door, dash, or rear deck using a rain shield or equivalent. If in doubt, please contact your is the most common. See your local Phoenix Gold Dealer for additional location Phoenix Gold Dealer.

  • Page 3: Surface Mount

    For other custom mounting configurations, tweeter. (figure 6) please contact your authorized Phoenix Gold Dealer. Flush Mount: For optimal tweeter installation, use the Flush Mount option. The Flush mount requires 3⁄4” depth and a 1-13/16” hole in the mounting surface.

  • Page 4: Specifications

    Due to continual product improvement, all specifications subject to change without notice. T/S Parameters R65CS RMS Power Handling (watts) Peak Power Handling (watts) 150W Impedance (ohms) Cut Out Dimension (mm)Inches (144) 5.7 Mounting Depth (mm) Inches (64) 2.5 © 2010 Phoenix Gold • www.phoenixgold.com...
  • Page 5 Traités Contre Les Rayons Uv, Possédant Une Bonne Course - Le design parfait pour la fiabilité à long terme • Une Structure D’acier Poudré Rigide - La conception assistée par ordinateur permet un alignement précis © 2010 Phoenix Gold • www.phoenixgold.com...

  • Page 6: Installation De Base

    Phoenix Gold. INSTALLATION DU HAUT PARLEUR SANS GRILLES Phoenix Gold a fourni un joint statique de montage en mousse. Lors de l’installation de vos nouveaux systéme de composantes dans une usine, assurez-vous d’utiliser les joints statiques de montage en mousse comme le montre la figure 1.

  • Page 7: Montage En Surface

    Chaque composante R Series est livrée avec un montage encastrable et un kit d’installation en surface. Pour d’autres configurations de montage personnalisées, veuillez contacter votre revendeur autorisé Phoenix Gold. Encastrables : Pour optimiser l’installation du haut-parleur d’aigus, utilisez l’option Encastrables. L’encastrable nécessite 19mm de profondeur et un trou de 46.5mm dans la surface de montage.

  • Page 8: Limited Warranty

    Phoenix Gold A Division of AAMP of America™ 13190 56th Court Clearwater, Florida 33760 P: 888-228-5560 info@phoenixgold.com www.phoenixgold.com © 2010 AAMP of Florida, Inc Designed and Engineered in the USA LIMITED WARRANTY Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer in the United States of America only. Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction, Phoenix Gold will (at its discretion), repair or replace the defective product with new or remanufactured product at no charge. Damage caused by the following is not covered under warranty: accident, misuse, abuse, product modification or neglect, failure to follow installation instructions, unauthorized repair attempts, misrepresentations by the seller. This warranty does not cover incidental or consequential damages and does not cover the cost of removing or reinstalling the unit(s). Cosmetic damage due to accident or normal wear and tear is not covered under warranty. INTERNATIONAL WARRANTIES: Products purchased outside the United States of America are covered only by that country’s Authorized Phoenix Gold reseller and not by Phoenix Gold. Consumers needing service or warranty information for these products must contact that country’s reseller for information.
