I N-WA LL S p E Ak E r S
CLeAR SOUND ANyWHeRe
Turn the entire home into a living theater with Phoenix Gold's
affordable solutions. Speaker selectors deliver flexibility, and
with our in-ceiling, in-wall and indoor/outdoor speakers, there's
a speaker solution for every need.
Speaker
Selectors
Pg. 6-8
Volume Controls
Pg. 9
In-Ceiling
LCRs Pg. 9
6
Indoor/Outdoor
Speakers
Pg. -3
IN-WALL 2-WAy LCR
FeATUReS
Dual 5.25˝ Polypropylene Woofers
25mm Pivoting Parachute Silk Dome Tweeter
Mid, Tweeter, Mid Configuration (MTM)
Butyl Rubber Surround
Robust Dog-Leg Mounting System
Spray-Paintable Frame and Grill
Integrated Rear Dust Shield
Left, Center, Right Application
Magnetically Shielded
with grill
Sold Individually
In-Wall
LCRs
Pg. 6
ATI55
SPeCIFICATIONS
Power Handling: 5 - 50 Watts
Impedance: 8 Ω
Frequency Response: 60Hz - 20kHz
Sensitivity 2.83V/1m: 92dB
Cut-Out Dimension: 3
Mounting Depth: 3
In-Ceiling
Speakers
Pg. 8-9
In-Wall
Speakers
Pg. 6-7
⁄
x 6
⁄
˝
5
7
6
8
(354 x 75mm)
⁄
˝ (89mm)
2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Phoenix Gold ATC-8
Summary of Contents for Phoenix Gold ATC-8
- Page 1 I N-WA LL S p E Ak E r S CLeAR SOUND ANyWHeRe Turn the entire home into a living theater with Phoenix Gold’s affordable solutions. Speaker selectors deliver flexibility, and with our in-ceiling, in-wall and indoor/outdoor speakers, there’s a speaker solution for every need.
- Page 2 IN-WALL 2-WAy ATI8 FeATUReS 8˝ Polypropylene Woofer 25mm Pivoting Parachute Silk Dome Tweeter Butyl Rubber Surround Robust Dog-Leg Mounting System Spray-Paintable Frame and Grill Textured Woofer for Reduced Resonance Sold as a Pair IN-WALL 2-WAy ATI6 FeATUReS 6.5˝ Polypropylene Woofer 25mm Pivoting Parachute Silk Dome Tweeter Butyl Rubber Surround Robust Dog-Leg Mounting System...
- Page 3 I N-C EI LI N G S pE A kE r S IN-CeILING 2-WAy ATC8 FeATUReS 8” Polypropylene Woofer 25mm Pivoting Parachute Silk Dome Tweeter Butyl Rubber Surround Robust Dog-Leg Mounting System Spray-Paintable Frame and Grill Textured Woofer for Reduced Resonance Sold as a Pair IN-CeILING 2-WAy ATC6...
- Page 4 IN-CeILING 2-WAy LCR ATCLCR6 FeATUReS 6.5˝ Polypropylene Woofer 25mm Pivoting Parachute Silk Dome Tweeter 5 Degree Speaker Inclination Butyl Rubber Surround Robust Dog-Leg Mounting System Spray-Paintable Frame & Grill Left, Center, Right Application Textured Woofer for Reduced Resonance Sold Individually...
- Page 5 InDOOR/OutDOOR SPeakeR PlaCeMent Like all speakers, Indoor/Outdoor Speakers sound best when placed in the line of sight of the listener, with no obstructions. They can be mounted vertically or horizontally and will pivot 80 degrees. Indoor/Outdoor Speakers are manufactured to resist a variety of weather conditions.
- Page 6 INDOOR/OUTDOOR 2-WAy IHS6B FeATUReS 6.5˝ Polypropylene Woofer 25mm Parachute Silk Dome Tweeter Butyl Rubber Surround CAD/CAe Designed, Audiophile Phase Compensated Crossover Magnetically Shielded Weather and UV Resistant Design Aluminum Grill and Mounting Brackets Pivoting Bracket Design with 5 Degree Marked Increments Corner Mounting Holes in Brackets Sold as a Pair INDOOR/OUTDOOR 2-WAy...
- Page 7 I ND oor/oU TD o o r S pEAk ErS Also available in black - AtO62B Also available in black - AtO52B Also available in black - AtO42B INDOOR/OUTDOOR 2-WAy ATO62W FeATUReS 6.5˝ Polypropylene Woofer CAD/CAe Designed, Phase Compensated Crossover 25mm Aluminum Dome Tweeter Weather and UV Resistant Design Mounting Brackets and Hardware Included...
- Page 8 INDOOR/OUTDOOR 2-WAy ATO5 FeATUReS 5.25˝ Polypropylene Woofer 9mm Polycarbonate Tweeter Weather Resistant Speaker System White Housing with White Powder Coated Microperf Grill Mounting Brackets and Hardware Included Spray-Paintable Grill and Housing Butyl Rubber Surround Sold as a Pair OUTDOOR ROCK...
