- Page 1 DMW2420 Page # Sheet Title Oven Parts Control Panel / Door Parts Revised 04-04-2011 Technical Service | 14425 Clark Avenue | City of Industry, CA 91745 | PH 800-353-2267 | FAX 909-348-5601...
- Page 2 DMW2420 - Oven Parts 4-16 6-10 4-11 1-13 4-15 4-14 4-13 1-10 6-12 4-10 1-11 1-12 4-12 Technical Service | 14425 Clark Avenue | City of Industry, CA 91745 | PH 800-353-2267 | FAX 909-348-5601...
- Page 3 DMW2420 - Oven Parts Ref # Part # Description 105418 High Voltage Assembly 105419 AH Sensor 105420 Oven Lamp 101937 Noise Filter 86805 Fan Motor 66179 Monitor Switch & Fuse Assembly 66236 Secondary Interlock Switch 86794 Magnetron Temperature Fuse 86795...
- Page 4 DMW2420 - Control Panel / Door Parts CONTROL PANEL PARTS 6-11 DOOR PARTS MISCELLANEOUS Actual wire harness may be di erent from illustration. Technical Service | 14425 Clark Avenue | City of Industry, CA 91745 | PH 800-353-2267 | FAX 909-348-5601...
- Page 5 DMW2420 - Control Panel / Door Parts Ref # Part # Description 105439 Door Frame Assy 86785 Latch Head 86786 Latch Spring 105440 Door Panel 105441 Choke Cover 105442 Door Stopper Recipe Card 105443 Main Wire Harness 105444 Turntable Support...
