Toshiba Satellite L640 Maintenance Manual page 265

Pin Assignment
145 GND
147 M_A_DQ45
149 M_A_DQ44
151 GND
153 M_A_DM5
155
157 M_A_DQ47
159 M_A_DQ46
161 GND
163 M_A_DQ48
165 M_A_DQ53
167 GND
169 M_A_DQSN6
171 M_A_DQSP6
173 GND
175 M_A_DQ55
177 M_A_DQ54
179 GND
181 M_A_DQ61
183 M_A_DQ60
185 GND
187 M_A_DM7
189 GND
191 M_A_DQ58
193 M_A_DQ59
195 GND
197 DIMM0_SA0
Satellite L600/L640/L645, Satellite Pro L600/Pro L640/Pro L645 Maintenance Manual (960-Q08)
---
I/O
I/O
---
I/O
GND ---
I/O
I/O
---
I/O
I/O
---
I/O
I/O
---
I/O
I/O
---
I/O
I/O
---
O
---
I/O
I/O
---
O
146 M_A_DQ40
148 M_A_DQ41
150 GND
152 M_A_DQSN5
154 M_A_DQSP5
156 GND
158 M_A_DQ42
160 M_A_DQ43
162 GND
164 M_A_DQ52
166 M_A_DQ49
168 GND
170 M_A_DM6
172 GND
174 M_A_DQ51
176 M_A_DQ50
178 GND
180 M_A_DQ57
182 M_A_DQ56
184 GND
186 M_A_DQSN7
188 M_A_DQSP7
190 GND
192 M_A_DQ62
194 M_A_DQ63
196 GND
198 PM_EXTTS#0
I/O
I/O
---
I/O
I/O
---
I/O
I/O
---
I/O
I/O
---
O
---
I/O
I/O
---
I/O
I/O
---
I/O
I/O
---
I/O
I/O
---
I
