Chapter 4 Replacement Procedures
Installing the I/O Board
The following describes for installing the I/O Board
1. Fix the below screws then incline insert in I/O Board
M2.0x3.0
FLAT BIND screw
x1
2. Insert the I/O Board FFC into base case and connect I/O board cable and speaker cable
NOTE: Be careful not to catch the cables between Top cover assembly and base cover
assembly.
4-40
Satellite L640/L645, Satellite Pro L640/Pro L645 Maintenance Manual (960-Q08)
