Important Safety Instructions

When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury to persons, including the
following:
1.
Read and understand all instructions.
2.
Follow all warnings and instructions marked on the product.
3.
Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol
cleaners. Use a damp cloth for cleaning.
4.
Do not use this product near water (for example, near a bath tub, kitchen sink,
or swimming pool).
5.
Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage.
6.
Slots and openings in the Handset and Base Unit are provided for ventilation.
To protect it from overheating, these openings must not be blocked by placing
the product on a bed, sofa, rug, or other similar surface. This product should
never be placed near or over a radiator or heat register. This product should
not be placed in a built-in installation where proper ventilation is not provided.
7.
This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your
home, consult your dealer or local power company.
8.
Do not allow anything to rest on the power cord. Do not install this product where
the cord might be damaged by anyone walking on it.
9.
Never push objects of any kind into this product through holes and slots in the
Handset and Base Unit as they may touch dangerous voltage points or short
out parts that could result in a risk of fire or electric shock. Never spill liquid
of any kind on the product.
10.
To reduce the risk of electric shock, do not disassemble this product, but take
it to an authorized service facility. Opening or removing cabinet parts other than
specified access doors may expose you to dangerous voltages or other risks.
Incorrect reassembling can cause electric shock when the appliance is
subsequently used.
11.
Do not overload wall outlets and extension cords as this can result in the risk
of fire or electric shock.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2652 and is the answer not in the manual?

Questions and answers

Related Manuals for Gigaphone 2652

Summary of Contents for Gigaphone 2652

  • Page 1: Important Safety Instructions

    Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Read and understand all instructions. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning.

  • Page 2: Save These Instructions

    Important Safety Instructions Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions: A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled into the product. C.

  • Page 3: Introduction

    The 2652 is an advanced cordless telephone that operates in the 2.4 GHz frequency range. Your 2652 is capable of supporting up to a maximum of 4 Handsets. Using additional Handsets, up to three people can be conferenced on a call (2 Handsets and the Base Speakerphone), or two extensions can be conferenced on a call, while two other extensions can be talking internally, using the Intercom feature.

  • Page 4: Parts Check List

    Parts Check List 1. Base Unit 5. Battery Pack 2. Handset 6. Belt Clip 3. AC Power Adapter 7. User's Manual 4. Telephone Cord Base Unit Handset Telephone Cord Belt Clip Battery Pack AC Power Adapter...

  • Page 5: The Handset Layout

    The Handset Layout Antenna LCD Display Message Waiting Indicator Select Earpiece Off/Clear Headset Jack (2.5mm) Intercom Scroll Keys Billed Services On/Flash Microphone Dialing Key (0 - 9, *, #) Handsfree Speakerphone...

  • Page 6: The Base Unit Layout

    The Base Unit Layout AC Power Jack Phone Cord Jack Page Key Charge Indicator Power Indicator In Use Indicator Erase Key Skip Key Redial Key Flash Key Hold Key Mute Key Play Key Volume Keys Dialing Keys (0 - 9, *, #) Speaker Key Auto Callback Key 3-Way Calling Key...

  • Page 7: Setup

    Handset display, and you will hear dial tone. If not, see In Case of Difficulty. Tone/Pulse selection See BASE SETTINGS for details. CAUTION: Use only the power supply provided with your 2652 Unit. IMPORTANT: For best performance the 2652...

  • Page 8: Installation Of Battery Pack In Handset

    8 hours should be sufficient. The original Handset that is shipped with your 2652 system will be automatically registered to the Base. This Handset is HANDSET 1. As you register additional Handsets to the system, they will be assigned extension numbers in the following order: HANDSET 2, HANDSET 3 and HANDSET 4.

  • Page 9: Spare Battery Charger/Power Backup Function

    Spare Battery Charger/Power Backup Function The 2652 can use the spare battery in the Base Unit to provide operational backup in the event of a power failure. With a fully charged battery pack in the spare battery charger, you will still be able to place and receive calls from the Handset for up to 3 hours.

  • Page 10: Charging Of Handset Battery Pack

    Charging Of Handset Battery Pack The Handset of your 2652 cordless telephone is powered by a rechargeable battery pack. It charges automatically whenever the Handset is in the Base Unit. You should charge the battery pack for 12 hours when you first receive your phone.

  • Page 11: Registration And Operation

    Registration and Operation Registration and Operation of the 2603 Accessory Handset Your 2652 system can operate up to 4 Handsets. The accessory Handset consists of the following: Setup of the 2603 Accessory Handset Plug the AC power adapter into an electrical outlet, then the DC connector into the bottom of the Charger Unit.
  • Page 12 Registration and Operation Enter Base ID Code NO BASE After charging the Handset, remove SUBSCRIPTION it from its Charge Cradle, the screen will display: Press NEW, then enter the 15 digit Base Unit ID code, located on the underside of the Base Unit. Press OK.

  • Page 13: Handset And Base Indicators

    Handset and Base Indicators Handset Icons Icon Description Line In Use indicator On steady with no number next to it when a parallel set is in use. On steady with one or more numbers next to it, indicating which extensions are using the line. For example, 12 indicates that Handset 1 and Handset 2 are on an outside call.
  • Page 14 Lights when Base unit is receiving power from wall outlet. Power • Flashes when unit is in Power Backup mode. • Lights when line is being used by any Handset of the 2652 system. In Use • Flashes when another telephone on the same line (parallel extension) is in use.

  • Page 15: Soft Menu Functions

    Soft Menu Functions The 2652 has an advanced design that uses a menu structure and soft keys to access all of the built-in features. Example of the idle mode display: RDL (Redial) Press RDL to display the last 5 telephone numbers dialed. The number on top line is the most recent number dialed.

  • Page 16: Calls Log (Caller Id)

    These are subscription services, provided by most regional telephone service providers. You must subscribe to these services to get the benefits of these features. If you do not subscribe to Caller ID services, you can still use your 2652 and the other features it offers.

  • Page 17: Handset Settings

    Handset Settings From the Handset Settings menu you can select the following options to modify: • RINGER VOLUME Select this option to adjust the ringer volume. Use the scroll keys to adjust the volume up or down. The Handset will display a graphic indicator of the selected volume setting.

  • Page 18: Range Extender

    That means the standby and talk time of your Handset will be shorter. Register Use this option to register a Handset to the 2652 Base. You can register a total of four Handsets to the 2652 Base. This process is activated automatically whenever a new Handset is powered up in range of the 2652 Base.
  • Page 19 MEM (Memory) The 2652 can store up to 50 numbers with names in memory. Each memory location can hold up to 32 digits for the number for the number and up to 16 characters for the name. When prompted to ENTER NAME, use the digit keys to 'spell' the name. Each press...

  • Page 20: Mem (Memory)

    MEM (Memory) To Store a Number/Name: • Starting from the idle screen, enter the number you want to store in memory. • Be sure to include long distance codes and pauses (using the Pause softkey) if necessary. Press OFF to correct if you make 1234 a mistake.

  • Page 21: To Search For And Dial A Number/Name

    MEM (Memory) To Search For and Dial a Number/ Name: • Starting from the idle screen, press the MEM softkey to review memory contents. • Using softkeys scroll through the memory contents in alphabetical order. Or, you can press the FIND softkey, enter the first few chararcters of the name.

  • Page 22: To Edit A Name Or A Number

    MEM (Memory) • Press the DEL softkey. The Handset will display: • To delete the displayed records, press THIS. To delete all records, press ALL. • If you press ALL, The screen will display: ARE YOU SURE? • To confirm the deletion of all records, press YES.

  • Page 23: Base Settings

    Base Settings The 2652 Base Unit has several settings that can be adjusted according to your preference and system requirements. Select Base Ringer Melody: • The phone must be off. • Press the star key three times ( ). The Base will emit a happy tone and the Power and In Use LEDs will flash rapidly.

  • Page 24: Select Base Ringer Volume And Off

    Base Settings Select Base Ringer Volume and OFF: • The phone must be off. • Press the star key three times ( ). The Base will emit a happy tone and the Power and In Use LEDs will flash rapidly. •...

  • Page 25: Handset And Base Operation

    Handset and Base Operation Making Calls From the Handset: • Press ON (or HANDSFREE to use the Handset Speakerphone feature).Dial the phone number. -OR- • Dial the phone number first, then press ON (or HANDSFREE). • Press OFF to end your call. From the Base Unit: •...

  • Page 26: Mute Function

    To return to the call press either HOLD or SPEAKER. You can use your 2652 with services such as Call Waiting. When you receive a call waiting signal, simply press the ON/FLASH key on the Handset or the FLASH key on the Base (when in speakerphone mode) to Flash the line.

  • Page 27: Volume Control

    Handset and Base Operation Function Press: End the first call and answer the second call Place the first call on hold and answer the waiting call FLASH Add the waiting call to your first call Send a hold message to your waiting call Forward the waiting call to your Voicemail* * Voicemail service, provided by your local telephone company, is required.

  • Page 28: Handsfree Speaker Operation

    HANDSFREE again to the Handset earpiece. Base Speaker Operation The Base of your 2652 is equipped with a full duplex speaker. This is a very useful feature for handsfree conversations or conference calls at the Base Unit. For more...

  • Page 29: Line In Use Indication

    EXTENSION IN USE will be displayed. On the Base: When a system Handset or a 2652 Base is currently being used, the IN USE LED on the Base will illuminate steadily. When a parallel set is currently being used, the IN USE LED on the Base will flash.

  • Page 30: Conference Calling

    Handset. Transferring Calls You can transfer calls on the 2652 system from the Base to Handset, Handset to Handset, or Handset to Base. Blind Transfer...

  • Page 31: Message Waiting

    You will then need to program your voicemail PASSWORD. First, you must activate and define your voicemail password with the voicemail service provided by your local telephone company. Once you have defined your password, you can then program it into the 2652.

  • Page 32: Using The Dedicated Play, Skip And Erase Keys

    When finished press SAVE. Using the dedicated PLAY, SKIP and ERASE keys The 2652 is factory programmed with the appropriate key sequences for PLAY, SKIP, and ERASE. When retrieving voicemail messages, you can use the dedicated keys on the Base Unit to access these functions.

  • Page 33: Skip Access Key

    Handset and Base Operation SKIP Access Key From the idle (OFF) mode, press MENU, use PASSWORD PLAY scroll keys to select ERASE VOICEMAIL SETUP, then press OK. The SKIP following screen will be displayed: Use the scroll keys to select SKIP, then press OK.

  • Page 34: Talking Cid

    Talking CID Talking CID is an advanced feature that enables your telephone to announce the name or telephone number of callers before you answer the call. Announcements are made from the Base Unit speaker. You must subscribe to Caller ID service in order to use this feature.

  • Page 35: Review, Play, Erase Or Re-Record A Talking Cid Announcement

    Talking CID Speak directly into the handset microphone to record up to 3 seconds of audio. • You can press the STOP key when you are done, or simply wait for recording to automatically stop after 3 seconds. • Press PLAY to review the Talking CID announcement.

  • Page 36: Custom Pay-Per-Use(Ppu) Features

    Custom Pay-Per-Use (PPU) Features AUTO CALL BACK dials the last party who called you, whether or not you answered the call. A charge is added to your phone bill each time you use this feature. 3-WAY CALLING allows you to talk with 2 separate parties from a single line. To use this feature, follow these steps: 1) Call your first party, after the party answers, 2) Press 3-WAY CALLING.

  • Page 37: Headset Operation

    Headset Operation Your 2652 cordless telephone is equipped with a 2.5mm Headset Jack for use with an optional accessory Headset for hands-free operation. To purchase a Headset, call 1-800-298-0973. Once you have a compatible 2.5mm Headset, locate the Headset Jack on the Handset.

  • Page 38: In Case Of Difficulty

    In Case Of Difficulty If you have difficulty operating your phone, the suggestions below should solve the problem. If you still have difficulty after trying these suggestions, call the Customer Service at 1-800-298-0973. The Phone Doesn't Work At All • Make sure the Power Cord is plugged in.
  • Page 39 In Case Of Difficulty Common Cure Electronic Equipment NO BASE If the unit does not seem to be responding normally, then try putting the Handset in the SUBSCRIPTION cradle. If it does not seem to respond, do the following (in the order listed): Disconnect the power to the Base.

  • Page 40: Maintenance

    Maintenance Taking Care Of Your Telephone Your 2652 cordless telephone contains sophisticated electronic parts, so it must be treated with care. Avoid Rough Treatment Place the Handset down gently. Save the original packing materials to protect your telephone if you ever need to ship it.

  • Page 41: Limited Warranty

    Limited Warranty The Supplier warrants, to the original purchaser only, the material and workmanship of this product for ONE YEAR from the date of purchase. We will repair or replace, at our option, this product without charge should it fail due to a defect in material or workmanship within that time period.

  • Page 42: Fcc And Acta Regulations

    FCC and ACTA Regulations This equipment complies with Parts 15 of the Federal Communications Commission (FCC) rules for the United States. It also complies with regulations RSS210 and CS- 03 of Industry and Science Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 43 FCC and ACTA Regulations phrase “FCC Reg No.” and the REN is listed separately. For equipment approved after that date, the product identifier is preceded by “US” and a colon (:), and the REN is encoded in the product identifier without a decimal point as the sixth and seventh characters following the colon.
  • Page 44 FCC and ACTA Regulations However, if you do make a call to an emergency number: • You must remain on the line and briefly explain the reason for the call before hanging • Programming/testing of emergency numbers should be performed during off-peak hours, such as in the early morning or late evening, when the emergency services tend to be less busy.

  • Page 45: Technical Specifications

    Technical Specifications WEIGHT FREQUENCY CONTROL Crystal controlled Handset: 187 grams PLL synthesizer Base: 385 grams POWER REQUIREMENTS TRANSMIT FREQUENCY Handset: 800 mAh Ni-Cd Battery 2401.056-2482.272 MHz Pack or 1500 mAh NiMH Battery Pack RECEIVE FREQUENCY 2401.056-2482.272 MHz Base: 7 VDC @ 900mA CHANNELS MEMORY 95 Channels...

  • Page 46: Table Of Contents

    Table Of Contents 25. Advanced Operations 1. I m p o r t a n t S a f e t y 25. Handset and Base Instructions Operation 25. Making Calls 3. Introduction 25. Answering Calls Parts Check List 25. Redial from Base Unit The Handset Layout 26.
  • Page 47 91-5572-30-00 ISSUE 0...
