Gigaphone 2420 User Manual

Vtech communication owner's manual cordless telephone 2420
Hide thumbs Also See for 2420:
Table of Contents

Advertisement

Quick Links

Download this manual

Important Safety Instructions

When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury to persons, including the
following:
1.
Read and understand all instructions.
2.
Follow all warnings and instructions marked on the product.
3.
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning.
4.
Do not use this product near water (for example, near a bath tub, kitchen sink,
or swimming pool).
5.
Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
6.
Slots and openings in the cabinet and the back or bottom are provided for ventilation.
To protect it from overheating, these openings must not be blocked by placing
the product on the bed, sofa, rug, or other similar surface. This product should
never be placed near or over a radiator or heat register. This product should not
be placed in a built-in installation where proper ventilation is not provided.
7.
This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your
home, consult your dealer or local power company.
8.
Do not allow anything to rest on the power cord. Do not locate this product where
the cord will be abused by persons walking on it.
9.
Never push objects of any kind into this product through cabinet slots as they
may touch dangerous voltage points or short out parts that could result in a risk
of fire or electric shock. Never spill liquid of any kind on the product.
10.
To reduce the risk of electric shock, do not disassemble this product, but take
it to an authorized service facility. Opening or removing cabinet parts other than
specified access doors may expose you to dangerous voltages or other risks.
Incorrect reassemb-ling can cause electric shock when the appliance is
subsequently used.
11.
Do not overload wall outlets and extension cords as this can result in the risk
of fire or electric shock.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2420 and is the answer not in the manual?

Questions and answers

Related Manuals for Gigaphone 2420

Summary of Contents for Gigaphone 2420

  • Page 1: Important Safety Instructions

    Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Read and understand all instructions. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning.

  • Page 2: Save These Instructions

    Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions: A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled into the product. C.

  • Page 3: Introduction

    This manual is designed to familiarize you with the GIGAPHONE cordless telephone. We strongly recommend you read the manual before using your phone. To order additional systerm Handsets (model# 2420), battery packs or headsets, call Vtech Communications Inc at 1-800-595-9511.

  • Page 4: Parts Check List

    Base Unit Handset AC Power Adapter Telephone Cord To purchase replacement battery packs, call Vtech Communications Inc at 1-800- 595-9511. In Canada, call VTech Electronics Ltd at 1-800-267-7377. Handset Base Unit AC Power Adapter Telephone Line Cord Parts Check List...

  • Page 5: The Handset Layout

    Antenna Earpiece Headset Jack (2.5mm) Scroll Keys On (Flash) Dialing Keys (0-9) Handsfree Speakerphone The Handset Layout LCD Display Select 10. Off (Clear) 11. Battery Compartment 12. Intercom 13. Microphone...

  • Page 6: The Base Unit Layout

    The Base Unit Layout AC Power Jack Phone Cord Jack Message Waiting Indicator Page Key Charge Indicator...

  • Page 7: Setup

    Plug the AC power adapter into an electrical outlet, and the DC connector into the back of the base unit. To AC outlet To telephone socket outlet Connecting to phone line Plug one end of the telephone line cord into the jack on the back of the base unit. Plug the other end of this cord into the wall jack.

  • Page 8: Installation Of Battery Pack In Handset

    Installation of Battery Pack in Handset The original Handset that is shipped with your GIGAPHONE system will be automatically registered to the Base. This Handset is HANDSET 1. As you register additional Handsets to the system, they will be assigned extension numbers in the following order: HANDSET 2, HANDSET 3, and finally HANDSET 4.

  • Page 9: Charging Of Handset

    The Handset of your GIGAPHONE cordless telephone is powered by a rechargeable battery pack. It charges automatically whenever the Handset is in the Base Unit. You should charge the battery pack for 12 hours when you first receive your phone. You'll know the battery pack needs charging when: •...

  • Page 10: Wall Mounting

    The Wall Mount bracket is designed for use on standard Wall Mount plates only. Line up the tabs on the wall mount adapter with the holes on the bottom of the base unit. Snap the wall mount bracket firmly in place. Plug the AC adapter into an electrical outlet, and the DC connector to the back of the base unit.

  • Page 11: Handset

    The accessory Handset consists of the following: Belt Clip Handset Battery Pack Charger Unit Setup Of The 2420 Accessory Handset Plug the AC power adapter into an electrical outlet. Remove the Handset battery cover by pressing on the indent and sliding downward.

  • Page 12: Registration And Operation

    Enter Base ID Code After charging the Handset, remove it from its Charge Cradle, the screen will display: Press NEW, then enter the 15 digit Base Unit ID code, located on the underside of the Base Unit. Press OK. The Handset will display: PLEASE WAIT!! Wait approximately 15 seconds.

  • Page 13: Handset And Base Indicators

    Handset Icons Description Icon Line In Use indicator On steady with no number next to it when a parallel set is in use. On steady with one or more numbers next to it, indicating which extensions are using the line. For example, Handset 1 and Handset 2 are on an outside call.
  • Page 14 Handset LEDs Description • Lights to indicate that you have new messages in your voicemail. Message Service must be subscribed to through your local telephone Waiting company. Base LEDS Description • Flashes to indicate that you have new messages in your voicemail. Message Service must be subscribed to through your local telephone Waiting...

  • Page 15: Soft Menu Functions

    The GIGAPHONE has an advanced design that uses a menu structure and soft keys to access all of the built-in features. Example of the idle mode display: RDL (Redial) Press RDL to display the last 5 telephone numbers dialed. The number on the top line is the most recent number dialed.

  • Page 16: Calls Log (Caller Id)

    From the idle (OFF) mode, press MENU, use the scroll keys to select CALLS LOG, then press OK. The Caller ID information of the most recently received call will be displayed. For example: To scroll to other records, use the aaaaaa scroll keys.

  • Page 17: Handset Settings

    From the Handset Settings menu, you can select the following options: • RINGER VOLUME Select this option to adjust the ringer volume. Use the adjust the volume up or down. A Handset will display a graphic indicator of the selected volume setting. Press OK to confirm your selection and return to the Handset Settings menu.

  • Page 18: Range Extender

    Your GIGAPHONE has an enhanced feature that is designed to improve performance. If you are using your GIGAPHONE in an area with excessive interference, or you require a moderate increase in operating range. the Range Extender feature can help to improve both the sound quality and range.
  • Page 19 The GIGAPHONE can store up to 50 names/numbers in memory. Each memory location can hold up to 32 digits and up to 16 characters for the name. When prompted to ENTER NAME?, use the digit keys to 'spell' the name. Each press of a particular key causes characters to be displayed in the following order: Number Key MEM (Memory)

  • Page 20: Mem (Memory)

    To Store a Number/Name: • Starting from the idle screen, enter the number you want to store in memory. • Be sure to include long distance codes and pauses (using the PAUSE softkey) if necessary. Press the MEM softkey. • You will then be prompted to ENTER NAME? Use the digit keys to 'spell' the name.

  • Page 21: To Search For And Dial A Number/Name

    To Search For and Dial a Number/ Name: • Starting from the idle screen, press the MEM softkey to review memory contents. • Using the softkeys scroll through the memory contents in alphabetical order. • Or, you can press the FIND softkey, enter the first few chararcters of the name and then press FIND to search.

  • Page 22: To Edit A Number

    • Press the DEL softkey. The Handset will display: • To delete this record, press THIS. • To confirm the deletion of ALL records, press YES. To exit without deleting press NO. To Edit a Number/Name • Using the steps in To Search For and Dial a Name/Number, locate the entry you want to edit.

  • Page 23: Handset Operation

    Hold Function • Press the HOLD soft key to place a call on hold. To return to the call press the ON or HANDSFREE key. Flash Function You can use your GIGAPHONE with services such as Call Waiting. Simply press the ON key on the Handset.

  • Page 24: Page/Intercom

    From Handset to Handset : • Press the INTERCOM key followed by the number of the other Handset you wish to call (e.g. INTERCOM • Handset 3 can then answer the intercom call by pressing the INTERCOM key. • To end the intercom call press OFF on either Handset.

  • Page 25: Handsfree Speakerphone

    Handsfree Speakerphone Operation Your GIGAPHONE handset has a built-in handsfree speakerphone. This feature allows you to stand the Handset upright on a table or desktop and have handsfree conversations. For more information, refer to MAKING CALLS in HANDSET. Line in Use Indication On the Handset : When the telephone line is currently being used by a GIGAPHONE Handset, a status...

  • Page 26: Conference Calling

    Conference Calling The GIGAPHONE is capable of supporting conference calls with up to two registered Handsets. To enter a conference call, simply access the line with two extensions by pressing ON (or HANDSFREE) on the Handset. The phone icon and two extension numbers will be displayed in the upper left corner of the Handset.

  • Page 27: Belt Clip

    Headset option, you must obtain an optional accessory Headset, which is compatible with the GIGAPHONE. To purchase a Headset or Battery Pack, please call Vtech Communications at 800- 595-9511 Once you have a compatible 2.5mm Headset, locate the Headset Jack on the GIGAPHONE Handset.

  • Page 28: Maintenance

    Taking Care Of Your Telephone Your GIGAPHONE cordless telephone contains sophisticated electronic parts, so it must be treated with care. Avoid rough treatment Place the Handset down gently. Save the original packing materials to protect your telephone if you ever need to ship it. Avoid water Your telephone can be damaged if it gets wet.

  • Page 29: In Case Of Difficulty

    If you have difficulty operating your phone, the suggestions below should solve the problem. If you still have difficulty after trying these suggestions, call VTECH Communications at 1-800-595-9511. In Canada, call VTECH Electronics at 1-800-267- 7377. The Phone Doesn't Work At All •...
  • Page 30 You Hear Other Calls While Using Your Phone • Disconnect your Base Unit from the telephone jack, and plug in a regular telephone. If you still hear other calls, the problem is probably in your wiring or local service. Call your local telephone company. You Hear Noise In The Handset, And None Of The Keys Or Buttons Work •...

  • Page 31: Warranty Statement

    ("Consumer" or "you") that the product and all accessories provided by VTECH in the sales package ("Product") are free from material defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with operation instructions.
  • Page 32 If the Product failure is not covered by this limited warranty,or proof of purchase does not meet the terms of this limited warranty , VTECH will notify you and will request that you authorize the cost of repair prior to any further repair activity. you must pay for the cost of repair and return shipping costs for the repair of Products that are not covered by this limited warranty.

  • Page 33: Fcc And Ic Regulations

    This equipment is compatible with inductively coupled hearing aids. Should you experience trouble with this telephone equipment, please contact: VTech Communication Inc SERVICE DEPT. at 1-800-595-9511. In Canada, call VTECH Electronics at 1-800-267- 7377. For repair/warranty information. The telephone company may ask you to disconnect this equipment from the line network until the problem has been corrected.
  • Page 34 Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents or by others who may be authorized by the FCC. For repair procedures, follow the instructions outlined under the VTECH Limited Warranty.

  • Page 35: The Rbrc Seal

    The RBRC program provides a convenient alternative to placing used nickel-cadmium batteries into the trash or municipal waste,which may be illegal in your area. VTech’s partnership with RBRC makes it easy for you to drop off the spent battery at local retailers participating in the RBRC centers.

  • Page 36: Technical Specifications

    FREQUENCY CONTROL Crystal controlled PLL synthesizer TRANSMIT FREQUENCY 2401.056 - 2481.408 MHz RECEIVE FREQUENCY 2401.056 - 2481.408 MHz CHANNELS 94 Channels NOMINAL EFFECTIVE RANGE Maximum power allowed by FCC. Actual operating range may vary according to environmental conditions at the time of use.

  • Page 37: Table Of Contents

    Table Of Contents 1. Important Safety Instructions 3. Introduction Parts Check List The Handset Layout The Base Unit Layout 7. Getting Started Setup Installation of Battery Pack in Handset Charging Of Handset Battery Pack Wall Mounting Registration and Operation of the VT2420 Accessory Handset Registration and Operation 13.
  • Page 38 91-5237-10-00 Printed in China ISSUE 0...
