SERVICE MANUAL
Level 3
Ver. 1.0 2001. 09
This service manual contains information for Japanese model as well.
Contents of LEVEL 2 Service Manual
SERVICE NOTE
1. GENERAL
2. DISASSEMBLY
3. BLOCK DIAGRAMS
4. PRINTED WIRING BOARDS AND
SCHEMATIC DIAGRAMS
5. ADJUSTMENTS
6. REPAIR PARTS LIST
The information that is not described in this
Service Manual is described in the LEVEL 2
Service Manual.
When repairing, use this manual together with
LEVEL 2 Service Manual.
DSC-F707
Canadian Model
Hong Kong Model
Australian Model
Chinese Model
Japanese Model
OVERALL
POWER
CD-355 BOARD
UJ-001 BOARD
FR-181 BOARD
PD-155 BOARD
BT-006 BOARD
AL-012 BOARD
LB-075 BOARD
SW-362 BOARD
EXPLODED VIEWS
ELECTRICAL PARTS LIST
DIGITAL STILL CAMERA
US Model
AEP Model
UK Model
E Model
Korea Model
Tourist Model
