- Page 1 INSTRUCTIONS FOR USE MODE D’EMPLOI SELFWINDING MOVEMENT 3120 3129 CALIBRES...
- Page 2 COURONNE VISSÉE - S CREWED CROWN avec date sans date with date without date COURONNE NON VISSÉE - NOT SCREWED CROWN avec date sans date with date without date...
- Page 3 ENGLISH...
- Page 4 INtroductIoN p 29 Quick-link contents page. - the Manufacture audeMars Piguet Simply click on the relevant title or subheading to following the link to your chosen section. Click on the white « English » to return to the main contents...
- Page 5 MANufActurE AudEMArS pIGuEt The Vallée de Joux : cradle of The waTchmaker’s arT in the heart of the swiss jura, around 50 kilometres north of geneva, nestles a landscape which has retained its natural charm to this day : the vallée de joux.
- Page 6 — jules louis audemars and edward daring. august Piguet — decided to pool their skills to audemars Piguet continued to build on its now design and produce watches with complications in international reputation with creative designs. the vallée de joux, the cradle of haute horlogerie.
- Page 7 The auTomaTic calibre calibres 3120 and 3129 by audemars Piguet are selfwinding movements. the movements of the wrist produce the energy required for them to function. this energy, harnessed by a 22 carat gold oscillating weight, is transmitted to the mainspring by a gear-train.
-
Page 8: Technical Specifications
tEcHNIcAL SpEcIfIcAtIoNS gear Train of tHE MovEMENt a train produced according to aP quality standards fulfils the following criteria : regulaTing organ Pinions are polished 1. through balance bridge 1 : the pivots and sweep of the pivots are burnished. guarantees high precision positioning of the the non-functional surfaces of the wheels are balance and greater degree of shock resistance, thus... - Page 9 auTomaTic winding daTe mechanism (model wiTh daTe display only) this calibre meets the following standards : the date display fulfils the following criteria : extremely low friction at the wheels and springs. instantaneous date jump at midnight via the date rapid winding in both directions 1.
- Page 10 MovEMENt Technical daTa of The moVemenT calibre 3120 total thickness : 4.26 mm total diameter : 26.60 mm caseback side frequency : 21,600 vibrations/hour (3 hz) number of jewels : 40 Minimal power reserve : approx. 60 hours...
- Page 11 vIEwS of tHE MovEMENt Technical daTa of The moVemenT calibre 3129 total thickness : 4.31 mm total diameter : 26.60 mm caseback side frequency : 21,600 vibrations/hour (3 hz) number of jewels : 38 Minimal power reserve : approx. 60 hours bidirectional automatic winding balance with variable inertia blocks flat balance-spring...
- Page 12 wAtcH INdIcAtIoNS ANd fuNctIoNS (see figure on the inside cover) hour hand Minute hand second hand date aperture (certain models) waTch wiTh daTe display your watch is fitted wih a three or four-position crown : crown in "screwed down" position (certain royal oak models only) crown in position for winding movement manually crown in position for rapid date correction...
- Page 13 seTTing The Time winding The waTch on certain royal oak models, always unscrew the on certain royal oak models, always unscrew crown before use. the crown before use. the unscrewed crown will automatically position itself at B. Pull the crown to position D. it is advisable to set the time clockwise and to adjust it precisely by turn the crown at least 30 times (in position B) moving the hands forward carefully until you reach...
