- Page 1 INSTRUCTIONS FOR USE MODE D’EMPLOI ROYAL OAK OFFSHORE DIVER 3120 CALIBRE SELFWINDING...
- Page 2 A B C D...
- Page 3 ENGLISH...
- Page 4 INtroductIoN p 29 Quick-link contents page. ‐ the Manufacture audeMars Piguet Simply click on the relevant title or subheading to following the link to your chosen section. Click on the white « English » to return to the main contents...
- Page 5 MANufActurE AudEMArS pIGuEt The Vallée de Joux : cradle of The waTchmaker’s arT in the heart of the swiss jura, around 50 kilometres north of geneva, nestles a landscape which has retained its natural charm to this day : the vallée de joux.
- Page 6 — jules louis audemars and edward daring. august Piguet — decided to pool their skills to audemars Piguet continued to build on its now design and produce watches with complications in international reputation with creative designs. the vallée de joux, the cradle of haute horlogerie.
- Page 7 TradiTion and innoVaTion as visibility and resistance to saltwater must also audemars Piguet has always striven to safeguard and be taken into account during the manufacturing uphold its independence. this is why the company process.
-
Page 8: Technical Specifications
tEcHNIcAL SpEcIfIcAtIoNS gear Train of tHE MovEMENt a train produced according to aP quality standards fulfils the following criteria : regulaTing organ Pinions are polished 1. through balance bridge 1 : the pivots and sweep of the pivots are burnished. guarantees high precision positioning of the the non-functional surfaces of the wheels are balance and greater degree of shock resistance, thus... - Page 9 auTomaTic winding daTe mechanism this calibre meets the following standards : the date display fulfils the following criteria : extremely low friction at the wheels and springs. instantaneous date jump at midnight via the date jumper train 1. rapid winding in both directions 1. fast correction of date disc via the correction barrel with large power reserve (approx.
- Page 10 vIEwS of tHE MovEMENt Technical daTa of The moVemenT calibre 3120 total thickness : 4.26 mm total diameter : 26.60 mm bridge side frequency : 21,600 vibrations/hour (3 hz) number of jewels : 40 Minimal power reserve : approx. 60 hours bidirectional automatic winding balance with variable inertia blocks flat balance-spring...
- Page 11 wAtcH INdIcAtIoNS ANd fuNctIoNS (see figure on the inside cover) hour hand Minute hand second hand date aperture rotating bezel Your watch is fitted with two crowns : four-position crown (at 3 o’clock) : crown in "screwed down" position crown in manual winding position crown in position for rapid date correction crown in time-setting position caution : unscrew the crown prior to adjusting.
- Page 12 seTTing The Time winding The waTch unscrew the crown before use. the unscrewed crown unscrew the crown before use. the unscrewed crown will automatically position itself at B. will automatically position itself at B. Pull the crown to position D. it is advisable to turn the crown at least 30 times (in position B) set the time clockwise and to adjust it precisely to wind the watch.
- Page 13 funcTion of The inner roTaTing bezel warning : for safety reasons, the rotating bezel can only be turned anti-clockwise (see indications). this function is used to measure time lapsed based on the position of the bezel arrow in relation to reading the rotating bezel the minute hand.
