Twin cutter 1200w
Hide thumbs
Table of Contents

Advertisement

Quick Links

X2
- TWIN
TM
CUTTER
1200W
INSTRUCTION MANUAL
SPECIFICATIONS
Motor:
1200W
No Load Speed:
5500/min
Blades Size:
125mm (5")
Depth of Cut:
Wood:
28mm
Steel:
2mm
Other Metals:
3mm
Weight:
3.6kg
ozito.com.au
WHAT'S IN THE BOX
Twin Cutter
Side Handle
Wrench & Locking Pin
Wax Lubricating Sticks x 6
TCS-6100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X2 TWIN CUTTER and is the answer not in the manual?

Questions and answers

Related Manuals for Ozito X2 TWIN CUTTER

Summary of Contents for Ozito X2 TWIN CUTTER

  • Page 1 CUTTER Twin Cutter 1200W INSTRUCTION MANUAL Side Handle SPECIFICATIONS Motor: 1200W No Load Speed: 5500/min Blades Size: 125mm (5”) Depth of Cut: Wood: 28mm Steel: Other Metals: Wrench & Locking Pin Weight: 3.6kg ozito.com.au Wax Lubricating Sticks x 6 TCS-6100...

  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION TWIN CUTTER 1. SIDE HANDLE 1. Main Handle 5. Blades 2. On/Off Switch 6. Upper Blade Guard Side Handle 3. Lock Off Switch 7. Side Handle 4. Lower Blade Guard 8. Wax Feeder Knob 1.

  • Page 3: Operation

    WARNING: Always ensure that the lower guard is releasing 1. Turn on the Twin Cutter. freely and is fully cloesd before commencing work. If it is binding or sticking do not proceed and contact Ozito Customer Service. CAUTION: ALLOW THE BLADE TO REACH FULL SPEED BEFORE CUTTING.

  • Page 4: Cutting Metal

    4. CUTTING METAL 5. REMOVING BLADES Always use the wax lubricating system when cutting aluminium, copper, stainless steel sheet and cast iron up to 3mm thick. 1. Unplug the Twin Cutter and allow the blades to cool. 1. Remove the end caps from 2.

  • Page 5: Fitting Blades

    6. FITTING BLADES Caution: The Twin Cutter is not designed to be used with abrasive wheels. 1. P lace Blade A onto the blade flange with the pins of the flange in the corresponding holes in the blade. 2. Place Blade B over the shaft. 3. Screw in the blade bolt but do not tighten. 4.

  • Page 6: Cutting Tips

    CUTTING TIPS A lways hold the main handle with one hand and the side handle with • the other. • M aintain a firm grip and operate the on/off switch with a positive action. • A lways wait until the blades have reached full speed before commencing to cut the workpiece. • A lways hold the saw so that the blades are at right angles to the workpiece and the saw is inclined at an angle of approximately 30°. • A lways keep your body positioned behind the blades and to one side –...

  • Page 7: Maintenance

    Always replace both carbon brushes at the same time. Broken or missing Replace blade teeth Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the saw by an unauthorised person or by mishandling of the Blunt teeth Replace blade saw.
  • Page 8 Tool:125mm X2 - Twin Cutter SPARE PARTS Model No. TCS-6100 17 16 15 14 1312 11 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Description Part No.

  • Page 9: Electrical Safety

    Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.

  • Page 10: Warranty

    • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0912...

This manual is also suitable for:

X2 tcs-6100

Table of Contents
