- Page 1 WHAT’S IN THE BOX METAL CUTTING SHEARS Metal Cutting Shears 500W INSTRUCTION MANUAL SPECIFICATIONS Hex Key Motor: 500W No load speed: 0 – 1,600 rpm Max. Thickness: 1.2mm Tool weight: 2.2kg ozito.com.au MCS-5000...
- Page 2 KNOW YOUR PRODUCT OPERATION METAL CUTTING SHEARS 1. ON/OFF 1 Shears 4 Trigger Switch 2 Shear Collar 5 Sure Grip The tool is recommended for use with a residual current device with a rated residual current of 30mA or less. 3 Belt Clip 6 Lock On Button 1.
- Page 3 2. VARIABLE SPEED 3. PREPARATION 1. Mark your cutting line 1. Vary the pressure on the trigger switch to change the speed of cutting to suit the job. 2. Start the tool and adjust the speed. Slower Faster Note: When using the lock on button, the variable speed trigger can only be set to maximum speed.
- Page 4 3. Move the blades along the cutting line with light pressure. IMPORTANT!: DO NOT FORCE THE BLADES. THE ANGLE OF THE TOOL IS CRITICAL TO THE PERFORMANCE OF THE TOOL. ENSURE THE CORRECT PROCEDURE IS FOLLOWED FOR OPTIMUM PERFORMANCE. MCS-5000...
- Page 5 Always replace both carbon brushes at the same time. Note: Ozito Industries will not be responsible for any damage or injuries caused Warning Read instruction manual by the repair of the metal cutting shears by an unauthorised person or by mishandling of the metal cutting shears.
- Page 6 Tool: 500W Metal Cutting Shears SPARE PARTS Model No. MCS-5000 34 35 36 37 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No.
- Page 7 Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.
- Page 8 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0712...
