Place Name Plate

Move the plastic cover away to open the transparent name label cover, insert a name paper, then put the plastic
cover back to the panel.
name label

Adjusting Camera Angle

Use a screwdriver to loosen the screw and then adjust the angle of the camera, then fix the screw.

Electronic Specifications

Power Supply : DC 24V ( );
supplied by PROS4 -24V or PROS5-24V
Power Consumption: Standby 50mA; Working status 200mA;
Camera: Pinhole Sharp Color CCD; 420 TV Lines;
Unlocking time: 1 -9S, set by monitor;
Talking Time: 90S;
Lock Power supply: 12Vdc, 300mA(Internal Power);
Working Temperature: -10 0 C~+45 0 C;
Dimension: 176(H)×90(W)×24(D)mm
PRO - System - Technical Guide 5
