Provision CHALLENGER PRO Technical Manual

2 wire - video intercom system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CHALLENGER P R O
2 WIRE - Video Intercom System
Technical Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHALLENGER PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Provision CHALLENGER PRO

  • Page 1 CHALLENGER P R O 2 WIRE - Video Intercom System Technical Guide...

  • Page 2: Table Of Contents

    PRO-DBC -4 Unit - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 20 This technical document is published for information purposes by PROVISION SECURITY PRODUCTS. In a policy of ongoing improvement, PROVISION SECURITY PRODUCTS reserves the right to modify the contents of this document and the features of the products referred to herein at any time and without prior notice.
  • Page 3 Section3 - Cables and Connections General Rules for Installation - - - - - - - - - - - - - - - - - - - - - -24 Connecting the Connectors - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 24 Installation Height - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 24 Door Station Install Condition - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 24 Table of Cables and Distance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 25...

  • Page 4: Section1 - Introduction

    • Provision Challenger Pro offers a variety of door stations to suit the fussiest of customers. Choose from the super slim wall/desktop mounted 3.5” PRO16 through to the 10” PRO21 all with colorful interface and touch screen operation.

  • Page 5: Home Applications

    Home Applications Supports up to 16 monitors and 4 door stations. 2 lock are also supported at each entrance...

  • Page 6: Apartment Applications

    Apartment Applications Supports up to 32 monitors and 4 door stations. 1 lock is also supported at each entrance...

  • Page 7: System Function

    System Function Internal monitor station ۞ Full range line 3.5’’/4’’/5’’/7’’/10’’ digital TFT; ۞ Super slim design with surface mounting; ۞ Touch screen operation with friendly interface; ۞ Intercom by name list and selective intercom; ۞ Selective monitoring each door stations or CCTV cameras; ۞...

  • Page 8: Door Station

    Door station ۞ Metal housing (Aluminium/Zinc –Alloy/ Stainless steel options-all IP66 weather rated); ۞ High resolution adjustable camera (CCD, ARS camera); ۞ Two independent relays for two locks control; ۞ Code lock control & Proximity access control ۞ Name plate display; ۞...

  • Page 10: Door Station

    Section2 - Units and Installations Door Station Features • Full zinc alloy panel. • Pin -hole color CCD camera. • Camera angle adjustable. • Night -view LED. • Backlight name plate. • DIP switches for multi door station configuration. • Direct connect to electronic lock of 12Vdc.

  • Page 11: Place Name Plate

    Place Name Plate Move the plastic cover away to open the transparent name label cover, insert a name paper, then put the plastic cover back to the panel. name label Adjusting Camera Angle Use a screwdriver to loosen the screw and then adjust the angle of the camera, then fix the screw. Electronic Specifications Power Supply : DC 24V (...

  • Page 12: Door Station Mounting

    Door Station Mounting Mounting Without Rainy Cover 160-165cm Mounting With Rainy Cover 160-165cm...

  • Page 13: Terminal Descriptions

    Terminal Descriptions 1 2 3 Lock Control Jumper Doorstation Code DIP MIC adjustment SPK adjustment Main Connect Port To select the lock type: see door lock connection section • Lock Control Jumper: • Total 4 door stations can be supported Door station Code DIP: DIP SWITCHES IN OFF POSITION ON SINGLE DOOR SYSTEM •...

  • Page 14: Door Lock Connection

    Door lock connection Door Lock Controlled with Internal Power Note: Electronic lock of Power -on -to -unlock type should be used. The door lock is limited to 12V, and holding current must be less than 250mA. The door lock control is not timed from Exit Button(EB). Parameter of Monitor must be set to 0 (by default).
  • Page 15 Connect one lock Connect two locks Take off the Jumper Take off the Jumper POWER POWER SUPPLY SUPPLY LOCK LOCK Unlock parameter setting(set on monitor) H/W : a1.3 S/W: V17.11.418.00 Manual Monitor Intercom Multimedia Local addr: Monitor Unlock timing: Video standard: UI-CODE: User Setup Close...

  • Page 16: Monitor

    Monitor Features Screen Indicator Microphone Manual Monitor Intercom Multimedia UNLOCK Button Monitor TALK/MON Button Close Memory Album User Setup Playback MENU Button About 09/30/2010 Thu.16:41 Mounting Hook Speaker Connection Port DIP S 1 2 3 4 5 6 Mounting Hook SD card slot •...

  • Page 17: Terminal Descriptions

    Terminal Descriptions • Door bell call button. SW+: Monitor • Door bell call button. SW-: Connection Board • External ringer output(12Vdc 100mA) EXT-RING: • Ground. GND: • Video signal output. VIDEO: S1: DIP switches for system configurations • DIPS BUS: non polarity bus line •...

  • Page 18: Color Picture Memory

    Color Picture Memory The monitors have been equipped with a built -in memory (about 120 MB) together with a SD card reader. An SD card up to 16 GB (Maximum) is supported . User can both record the pictures manually and set the Monitor to automatically record pictures. •...
  • Page 19 PROGRAMMING How to enter the installation setting page Installation settings: [0010]#:Remove all remote control H/W : -- a1.3 [0011]#:Add remote control S/W: [8000]#:Set as master unit 0 [8001]#:Set as slaver unit 1 [8002]#:Set as slaver unit 2 Manual Monitor Intercom Multimedia Local addr: [8003]#:Set as slaver unit 3...
  • Page 20 How to set the slave monitor address Maximum 4 monitors can be connected in one apartment, one master monitor together with 3 slave monitors, so you should set the address correctly.(note :must have one monitor to be set as master monitor) The code of 8000 # is used to set the master monitor.
  • Page 21 How to set the unlock parameter UNLOCK MODE:: 8010# is used to set the unlock mode to 0 ( POWER TO UNLOCK FAIL SECURE) 8011# is used to set the unlock mode to 1 (POWER TO LOCK FAIL SAFE) UNLOCK TIME: 8021# 1 SECOND ACTIVATION 2 SECOND ACTIVATION...
  • Page 22 Shortcut for touch screen calibration of monitor In standby mode,touch the “+” icon will be shown on The same as last operation. The same as last operation. unlock button and hold screen,then touch “+” icon When the screen display “ok”, for 2s.

  • Page 23: User Code Setup

    THIS IS ONLY REQUIRED FOR MULTI DOOR STATION SYSTEMS ONLY User Code Setup – Room stations There are 6 bit switches in total. The DIP switches are used to configure the User Code for each Monitor. Bit -6 is used to set video impedance, it should be set to ON if the Monitor is in the end of the line(bus), otherwise set to OFF.

  • Page 24: Monitor Extending Connection

    DIP user code settings for door station – Total 2 bits on the DIP switches can be configured. The switches can be modified either before or after installation. Bit state Descriptions Default setting, ID = 0(00), set to the first Door Station. ID = 1(10), set to the second Door Station.
  • Page 25 2. External Ringer External Ringer External ringer can be connected to the Monitor. The ringer will ring whenever the Door Station call button or the door bell call button is pressed, and it will stop ringing when the Monitor rejected or answered the call. EXT-RING 12Vdc 300mA VIDEO...

  • Page 26: Accessories

    Accessories 352 PS5 - Power Supply The PRO-PS5 power supply unit is designed for PRO system to supply up to 32 Monitors and total 4 Door Stations at the same time. • Universal AC input/full range. • Multi protection: short circuit, overload, over voltage •...

  • Page 27: Prodps

    DIN Installation PROS5 352DPS DIN nail 85~260AC PRODPS This unit is a power separator for the PROS5 or PROS4 power supply, it transfers the power from the power DPS: supply to the suitable power for the non -polarity bus. Note that the PRODPS must work together with the PROS5 or PROS4 power supply.

  • Page 28: Prodbc

    PRODBC This unit is a 2 wire branch controller unit used to transfer all data between the Monitor and the Bus Line. Every PRODBC: Monitor(except the last one at the end of the line) needs one DBC to connect to the Non -polarity Bus Line. No extra power supply needed, and one LED indicator to show the working state.

  • Page 29: Pro-Dbc -4 Unit

    85mm PRODBC 4S Unit Distributor is a 2 wire branch controller with 4 outputs distributor for the Challenger Pro system, to approach PRODBC-4 the star topology connection in the apartment system. See Section 3 Cables and Connection for detail connection information.
  • Page 30 Technical Specifications(PRODBC4S) Power Supply : DC24V Temperature: C~+40 C; Wiring: 2 wires (non -polarity); Dimension: 88(H)×140(W)×32(D)mm PRODBC4S Dimensions...
  • Page 31 140mm 70mm upward 84mm 32mm Trunk Bus A/B/C/D port: Connect to Monitors/Door Station Trunk Bus: Bus input/output. Direct Wall Mounting DIN Rail Mounting PRO - System - Technical Guide...

  • Page 32: Section3 - Cables And Connections

    Section3 - Cables and Connections General Rules for Installation Connecting the Connectors Before screw the wire to the plug -in connector, it's important to process the wire in the correct way. See the following steps to connect the wire. 1. Strip the wire 2.

  • Page 33: Table Of Cables And Distance

    Table of Cables and Distance The maximum distance of the wiring is limited in the Challenger Pro system. Using different cables may also effect the maxi - mum distance the system can reach. The farest monitor When Monitor quantity < 20 Cable Usage Twisted cable 2x0.75 mm...

  • Page 34: System Wirings And Connections

    System Wirings and Connections 1. Basic one to one wiring and Cable Length PRODPS PROS4 L1 L2 PL S1+ S2+ S- NP:Non-polarized Cable A(m) B(m) B(m) ≤2 PRO27 ≤16 PRO27 - - - - CAT5 Cable (Combined) - - - - Pair Cable (Parallel) 2X0.75 mm Twisted Cable 2X0.75 mm Twisted Cable 2X1.0 mm...

  • Page 35: Multi Monitors In -Out Wiring Mode

    2. Multi monitors IN -OUT wiring mode 3 4 5 6 Code=15, DIP-6=on 3 4 5 6 Code=14, DIP-6=off 3 4 5 6 Code=0, DIP-6=off 85~260AC ID=00 PRO - System - Technical Guide...

  • Page 36: Multi Monitors Star Wiring Mode

    3. Multi monitors Star wiring mode 3 4 5 6 3 4 5 6 Code=14, DIP-6=on Code=15, DIP-6=on 3 4 5 6 3 4 5 6 Code=12, DIP-6=on Code=13, DIP-6=on 3 4 5 6 3 4 5 6 Code=2, DIP-6=on Code=3, DIP-6=on 3 4 5 6 3 4 5 6...

  • Page 37: Section4 -System Setup

    = pick -up waiting time + maximum talking time) What’s User Code In 2 -wire CHALLENGER PRO system, each Monitor installed in system must be programmed with a calling address or calling number, which is User Code.

  • Page 38: Installation Setup On Monitor

    Master Monitor Slave Monitor 1 Slave Monitor 2 Slave Monitor 3 Slave Address Slave Address Slave Address Slave Address Please note, when called by Door Station, all Monitors will ring, however, only the Monitor which Sub User Code was programmed to 0 will turn on the screen by default. Programming Slave User Code is by means of Monitor Menu, for more detailed operation, please refer to the followings as below: Installation setup on monitor...
  • Page 39 CHALLENGER PRO User Code Programming Table page1/2 User code Bit state Room Name Label Remark 3 4 5 3 4 5 3 4 5 3 4 5 3 4 5 3 4 5 3 4 5 3 4 5 3 4 5...
  • Page 40 CHALLENGER PRO User Code Programming Table page1/2 User code Bit state Room Name Label Remark 3 4 5 3 4 5 3 4 5 3 4 5 3 4 5 3 4 5 3 4 5 3 4 5 3 4 5...
  • Page 41 Provision Security Products Pty Ltd www.provisioncctv.com.au PRO System Technical Guide_V1.0 PRO - System - Technical Guide...

  • Page 42: Basic Door Release Operation

    4. Basic Door Release Operation 1. Press CALL button on outdoor station, the DS-1 00:23 Monitor rings, at the same time, the screen displays the visitors' image. 2. Press TALK/MON Button on monitor or touch icon on screen, you can communicate hands free with the visitor for 90 seconds.After finishing communication,press TALK/MON button again or touch...

  • Page 43: Intercom Call

    : User in one apartment can call Intercom Call other apartments in the system. the namelist will Intercom Call be created automatically by the system. Touch a [ 00 ] Jim. Zhang [ 01 ] Calo. Liu [ 02 ] Jacko.

  • Page 44: Date And Time Setting

    Ring Volume and Night Ring Volume Setting User Setup (2) You can set a ring volume for day time and night Ring Volume ... time individually, 6:00 AM~18:00 PM is the day Night Ring Volume ... TPC Configure ... time and 18:00 PM~6:00 AM is the night time by Restore to default ...

  • Page 45: Restore To Default

    9. Restore to Default Touch User Setup item on main menu page to enter setup page,then touch Next Page item to enter User Setup 2 page, touch item ,a message will be asked Restore to default to confirm the restore operation. If touch icon ,All settings will be restored to default, if you don't want to restore, touch icon to cancel the operation.(Note that the...
  • Page 46 How to set the slave monitor address Maximum 4 monitors can be connected in one apartment,one master monitor together with 3 slave monitors, so you should set the address correctly.(note:must have one monitor to be set as master monitor) The code of 8000 is used to set the master monitor. The code of 8001 is used to set the first slave monitor .
  • Page 47 How to set the unlock parameter Unlock mode: There are two unlock modes: 1.power-on- to-unlock type:unlock mode=0(by default) 2.power-off-to-unlock:unlock mode=1. The code number of 8010 is used to set the unlock mode to 0 The code number of 8011 is used to set the unlock mode to 1 Unlock time: The unlock time can be changed by yourself at any time.it can be set from 1 to 9 seconds.

  • Page 48: Screen And Volume Adjustment

    11. Screen and Volume Adjustment During monitoring or talking, touch icon,the will be displayed. ADJUST MENU Touch and select the adjustment item you want; touch icon to decrease / increase the value. 1. The first item is Scene mode selection: Total 4 screen modes can be selected in sequence: Normal, Scene...
