February 2007
K220
Snap and Tune

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K220 and is the answer not in the manual?

Questions and answers

Related Manuals for Sony Ericsson K220

Summary of Contents for Sony Ericsson K220

  • Page 1 February 2007 K220 Snap and Tune...

  • Page 2: Purpose Of This Document

    In no event document. shall Sony Ericsson or its licensors be liable for Any rights not expressly granted herein are incidental or consequential damages of any nature, including but not limited to lost profits or reserved.

  • Page 3: Sony Ericsson Developer World

    On www.sonyericsson.com/developer, developers will find documentation and tools such as phone White papers, Developers guidelines for different technologies, SDKs and relevant APIs. The Web site also con- tains discussion forums monitored by the Sony Ericsson Developer Support team, an extensive Knowl- edge Base, Tips & Tricks, example code and news.

  • Page 4: Table Of Contents

    White paper K220 Contents Product overview ........................5 Key features ..........................6 Images ............................7 Technologies in detail ........................ 8 Functions and features ......................9 Facts and figures ........................18 Technical specifications ......................19 General technical data ......................19 Performance and technical characteristics ................. 19 USSD technical data ......................

  • Page 5: Product Overview

    White paper K220 Product overview K220 is an easy to use and affordable FM radio phone with elegant classic design. The radio features an RDS function that brings information directly to the display, and a headset is included in the kit.

  • Page 6: Key Features

    White paper K220 Key features RDS FM Radio The FM radio with RDS (radio data system) offers instant and easy access to FM radio channels. The RDS function brings information directly to the display, which is sent out by the currently tuned in radio station.

  • Page 7: Images

    White paper K220 Images February 2007...

  • Page 8: Technologies In Detail

    White paper K220 Technologies in detail This chapter offers a detailed description of the technologies available in this product. February 2007...

  • Page 9: Functions And Features

    White paper K220 Functions and features The following table is a description of the features in this product. It also compares this product with two other Sony Ericsson products. Feature K220 K310 J220 Alarm clock Antenna Built-in Backlight Illuminates your phone screen.
  • Page 10 White paper K220 Feature K220 K310 J220 Chinese input method Text input methods based on Simplified or Traditional Chinese; Bopomofo, Pinyin or Stroke. cHTML A mobile device adapted version of the standard Internet communications protocol HTML. Clock Visible clock on the screen.
  • Page 11 White paper K220 Feature K220 K310 J220 Design Stick phone, Stick phone, dual Stick phone, gloss finish front, front, exchangeable painted back exchangeable front and battery cover front and battery covers cover Device Management (DM) DM utilizes GPRS as bearer of the provisioning...
  • Page 12 White paper K220 Feature K220 K310 J220 Frames Before you take a picture, you can choose to have a frame surrounding the picture. Games download Replace your in-phone games with new ones. Games embedded GPRS Multislot class 8 Multislot class 10 General Packet Radio Services –...
  • Page 13 White paper K220 Feature K220 K310 J220 Keypad Keypad with 12 Keypad with 12 16 keys, 4+1 keys, 2 selection keys, 2 selection way navigation keys, Call key, keys, clear and End/on/off key, 4 back keys, 4+1 way navigation way joystick,...
  • Page 14 White paper K220 Feature K220 K310 J220 OTA settings WAP and other settings can be sent over-the- air to the phone. PhotoDJ™ Picture gallery A thumbnail image gallery. Picture phonebook Add a picture to a saved contact. The picture appears on the screen when the saved contact calls.
  • Page 15 Up to 10 Concatenated SMS text messaging. concatenations concatenations concatenations Sony Ericsson Remote Update Service Download the latest operator approved version of the mobile phone software over the air. Sony Ericsson Update Service Download the latest operator approved version of the mobile phone software via a computer.
  • Page 16 White paper K220 Feature K220 K310 J220 Status view Shows the network being used, time and other status information. Stopwatch Style-Up™ covers Exchangeable covers to alternate the look of your phone. Synchronization PC Synchronize and share phone content with a computer.
  • Page 17 White paper K220 Feature K220 K310 J220 Voice control Voice answer, reject and call. Assign voice commands to items in your phone book. Voicemail Support for voicemail operator service including automatic answering and message recording. Yes. Yes. Yes. 1.2.1 1.2.1 A mobile Internet standard enabling you to access specially designed Internet sites.

  • Page 18: Facts And Figures

    White paper K220 Facts and figures This chapter offers readers a detailed listing of all the technical data relating to the product. Comprehen- sive descriptions of performance and technical characteristics are presented in table format for quick and easy access.

  • Page 19: Technical Specifications

    White paper K220 Technical specifications General technical data System GSM phase 2 recommendations. Quad-band GSM 900/1800 or 850/1900 Speech coding HR, FR, EFR, AMR supported where available, for high speech quality GSM SIM/USIM card Small plug-in card, 1.8 V and 3 V Memory (user free) Up to 2.0 MB...

  • Page 20: Ussd Technical Data

    White paper K220 Dimension GSM 850 GSM 900 GSM 1800 GSM 1900 Receiver RF sensitivity Better than – 102 Better than – 102 – 102 dBm – 102 dBm Receiver RX Bit error < 2.4% < 2.4% < 2.4% < 2.4%...
  • Page 21 White paper K220 Dimension Support Support of GPRS re-selection C31/ Support of static and dynamic addressing Support of power control Uplink Uplink = yes, Downlink is a network feature and Downlink Support of ciphering algorithms GEA1, GEA2 Support of compression algorithms Yes, V42bis and IP header compression...

  • Page 22: Sim At Services Supported

    White paper K220 SIM AT services supported Service Mode Support CALL CONTROL BY SIM DATA DOWNLOAD TO Cell Broadcast DISPLAY TEXT Text of up to 240 characters (120 UCS2 coded) bit 1: 0 = normal priority 1 = high priority...
  • Page 23 White paper K220 Service Mode Support PLAY TONE POLLING OFF POLL INTERVAL PROVIDE LOCAL '00' = Location Information (MCC, MNC, LAC and INFORMATION Cell Identity) '01' = IMEI of the ME '02' = Network Measurement results '03' = Date, time and time zone (DTTinPLI)
  • Page 24 White paper K220 Service Mode Support SET UP CALL General: Capability configuration Set-up speech call CallParty Sub address DTMF support '00' = set up call, but only if not currently busy on another call '01' = set up call, but only if not currently busy on...

  • Page 25: Vga Camera

    White paper K220 Service Mode Support SEND DATA GET CHANNEL STATUS User Interaction with SIM AT • ‘Back’ – Backward move in proactive session. • ‘OK’ – Command performed successfully. Display text Select item Text clearing times are 2-35 seconds and a 30- second time-out limit for the user to clear the text.

  • Page 26: Pictures And Animations

    White paper K220 Pictures and animations Formats JPEG, BMP, GIF (including animated), WBMP Sharing via MMS, EMS, WAP, IR Image decoders Decoder Details Size Colour depth File format 87a/89a 128x128 pixels JPEG ISO/IEC JPEG JFIF v1.02 Baseline DCT EXIF Progressive DCT...
  • Page 27 White paper K220 Feature Support Input methods Predictive text input and multitap Reply to messages It is possible to reply to received messages by SMS or phone call Message creation methods support Predictive writing and multitap Copy, cut and paste words...

  • Page 28: Enhanced Messaging Service

    White paper K220 Feature Support via phone call (set up a call to the number contained in the message body) via WAP call (go to the WAP address contained in the message body) via USSD session Possibility to send a text message to a list of...

  • Page 29: Multimedia Messaging Service

    White paper K220 Feature Support Melodies It is possible to: • Send and receive melodies via EMS, if the melodies are not protected by ODI. • Download melodies and commercial tunes from WAP portals. • Create melodies on WAP portals.
  • Page 30 White paper K220 Feature Support Supplier indication of realized interoperability tests between its MMS User Agent and MMS Relay/Server from other suppliers Support of a standard or a proprietary Proprietary procedure for OTA provisioning of MMS parameters Functionalities that the user is able to set •...

  • Page 31: Browser Technical Data

    White paper K220 Browser technical data Feature Support in the browser Back to previous page Bearer type GPRS (IP) Bookmarks Yes, up to 20 named bookmarks for easy access to frequently visited pages, with folders and sorting supported. Bookmark Export/Import Yes, can be sent and received using SMS.

  • Page 32: Operator Technical Data

    White paper K220 Operator technical data Feature Support for WAP WAP Browser Version 1.2.1 baseline WAP Provisioning types OMA Client provisioning (v1.1) Total Parameter sets 10 (shared between the provisioning types). < or = 10 (total number of profiles) Parameter set list...
  • Page 33 White paper K220 Feature Support for WAP OTA via SMS Same interface as above If the settings previously installed were privileged or have higher priority, the settings might not be possible to install again unless the terminal is reset, otherwise as above...
  • Page 34 White paper K220 Feature Support for WAP Push de-activate Dynamic push menu changes No, there are no changes in the menus when activating or deactivating push Security Mechanisms for push WSP push sessions HTTP push session User agent profile UA profile content sent at beginning...
  • Page 35 White paper K220 Feature Support for WAP Selection keys Separate/dedicated back or delete keys Screen backlight on when browsing Yes Predictive writing “http://” string displayed automatically when entering URLs Elements Pop-up menus Yes, in XHTML Radio buttons Yes, in XHTML...

  • Page 36: Abbreviations

    White paper K220 Abbreviations 3GPP™ 3rd Generation Partnership Project. Collaboration Digital Rights Management; controlling copying between a number of telecommunications stand- and distribution of content, with respect to intellec- ards bodies to specify 3G. 3GPP also maintains tual property rights.
  • Page 37 White paper K220 GPRS MPEG General Packet Radio Services Moving Picture Experts Group. A working group of ISO/IEC in charge of the development of standards for coded representation of digital audio and video. Global System for Mobile Communications. The GSM system family includes GSM 850, GSM 900, GSM 1800 and GSM 1900.
  • Page 38 White paper K220 and memory for a personal directory of numbers. The card can be a small plug-in type or credit card- sized, but both types have the same functions. Wireless Markup Language. A markup language used for authoring services, fulfilling the same pur- pose as HyperText Markup Language (HTML) does on the World Wide Web (WWW).

  • Page 39: Related Information

    White paper K220 Related information Documents • Sony Ericsson User guide • AT Command Reference Manual • Sony Ericsson FAQ • WAP 1.2.1 Specifications Links • www.sonyericsson.com/ • www.imc.org/pdi/ • www.ericsson.com/mobilityworld/ • www.etsi.fr • www.midi.org • www.wapforum.org • www.extendedsystems.com •...
