CAMERA LINK FC1600FCL Instruction Manual page 21

[Description of CR data]
Bit Abbrev.
0 MENU Disabled display of menu screen
1 BZ Disabled buzzer output
2 PATTERN ON/OFF selection for test pattern
3 BIT Selection of output data format
4 (Not used)
5 (Not used)
6 STRB-C Enabled STRB signal output for continuous shutter
7 Vinit2 Selection of trigger signal (Vinit2) polarity via CC1
8 H-RESET Enabled H-reset in asynchronous operation
9 BAUD 9600bps/19200bps selection for serial communication baud rate 1=19200bps
10 - (Not used)
11 - (Not used)
12 - (Not used)
13 - (Not used)
14 CCD0 (Not used)
15 DEFR Request for reading out default value at next start-up
(Note) All the items of the CR data are "0" as factory default.
The items marked with <* C> can not be changed by the communication command.
[Description of FR data]
Bit Abbrev
0 ASYE Selection of continuous/asynchronous shutter 1: Asynchronous (ASYNC)
1 PWCE Selection of enabled/disabled for pulse width
control
2 LEXE Selection of high speed/low speed shutter
3 PSCE Selection of normal scan/partial scan
4 DSCE (Not used)
5 - (Not used)
6 - (Not used)
7 - (Not used)
8 ESP(0)
9 ESP(1)
Externally designated shutter speed position
10 ESP(2)
11 ESP(3)
12 ESPE
Validity of externally designated shutter speed 1: Valid
13 - (Not used)
14 - (Not used)
15 AGCE (Not used)
(Note) All the items of the FR data are "0" as factory default.
(Example) If "MF=H'0008.0003" is displayed on the menu screen, the camera is in the following state (converting the
numbers to ones in binary system):
H'00=B'00000000, H'08=B'00001000 and H'03=00000011 are substituted to the above numbers.
CR=B'0000000000001000, FR=B'0000000000000011
......... CR(3)=FR(1)=FR(0)=1, All other bits = 0
(Where CR(n) and FR(m) represent the nth bit of CR and mth bit of FR respectively)
Based on 1 or 0 of these bits and the information in the above table, the user can know that the camera is in the
state of "8bit format", "ASYNC" and "Enabled pulse width control".
[Explanation]
The setting values (1 or 0 of respective bits) of (CR) and (FR) vary according to the change to be made using the switches
on the rear panel of the camera. The operation modes that cannot be changed by the RS-232C commands can be
changed by altering the bits of (CR) and (FR).
(Example 1) When a change is made from the continuous shutter mode → asynchronous shutter mode,
"MF=0000.0000" is replaced by "MF=0000.0001" (ASYE bit = 1).
(Example 2) When CR (0) is changed from 0 → 1 using a serial communication command, "ON" on the menu display is
replaced by "OFF" (MIND=1).
Content
Content
- 21 -
1: Disabled (OFF)
1: Disabled (OFF)
1: Test pattern ON
1: 8bit format
1: Enabled
1: Positive polarity
1: H-reset Enabled
1: Request
Logic
1: Enabled pulse width control
1: Low speed shutter
1: Partial scan
H'0 to H'9 or H'F
K11208a;21/36
Logic Remark
0: 10bit format
* 1
* 1
Remark
Where ESPE=1, externally
designated number from 0
to 9 (designated position)
is reflected. In case of H'F,
external shutter speed in
H unit is selected.
