CAMERA LINK FC1600FCL Instruction Manual page 16

(Note) When any setting item is changed, it must be saved in one of the program pages from "A" to "F" before turning off
the power to store the data in the memory of the camera. Carefully note that the new setting is not automatically
saved and that the prior setting will be effective at the next time of power-on if the power is turned off before storing
it. The configuration items, however, are automatically saved whenever they are changed.
[Terminology] Configuration items ···· They are the common setting items that are independent of the program pages.
Start-up condition (at time of power-on)
Position of mode switch
Arbitrary position
from 0 to F
A
C
D
Table 6-4 Set contents for Operation Mode Setting [Group 1]
Position of
mode switch
0 Change of gain
1 Menu display
2 Preset select 1 or 2
3 Preset select 3 or 4
4 (Not used)
5 Shutter – continuous/asynchronous
6 Shutter – high speed/low speed
7 Change of shutter speed (S.TIME)
8 Digital offset
9 Switch between normal scan/partial scan (SCAN)
A to F Program pages from A to F
(Note )The decibel value of Preset select is a relative value(reference value) based on Preset 2.
(Note) The shutter speed can be changed only when the shutter switch is currently set at any other positions than "0".
When the shutter switch is positioned at "0", the shutter speed cannot be changed even if the mode switch is set to
the position "7" and the UP/DOWN switch is manipulated. (The shutter is always OFF where shutter switch = "0".)
Table 6-5 Set contents for Operation Mode Setting [Group 2]
Position of
mode switch
1 Menu display
2 (Not used)
3 (Not used)
4 Enabled/disabled for pulse width control (PWC) (!)
A to F Program pages from A to F
(!) When the setting of " Enabled/disabled for pulse width control" is not set to be "ENABLED", the pulse width control is
not effective even if the shutter switch is set to the position "9" for the asynchronous shutter operation. In this case, the
preset shutter in asynchronous shutter mode is effective.
Table 6-6 Set contents for Operation Mode Setting [Group 3]
Position of
mode switch
1 Menu display
2 Operation confirmation buzzer
3 Serial communication baud rate
4 (Not used)
5 H-reset in asynchronous shutter mode (H-RESET) <* C>
6 Polarity setting for Vinit2
7 Continuous shutter strobe signal
(Note) Although this version of the firmware is designed to display the setting items of (CLOCK), any change made for
these items is disabled and not affect the internal operation. As a general rule, use with the default setting.
(Note) As the external sync operation and the H-reset operation in the asynchronous shutter mode are conflicting, ensure
to select one out of these two operations. If both operation modes are simultaneously selected, it can not function well.
Table 6-7 Set contents for Operation Mode Setting [Group 4]
These items are automatically saved in the internal EEPROM at the same time as
they are changed by manipulating the switches on the rear panel.
Table 6-3 Start-up condition for each setting Group
UP/DOWN switch
Neutral position (no switch
manipulation)
Retention of UP or DOWN
position
Item to be changed
(MENU) <* C>
(S.FORM )
(S.TIME)
(OFFSET)
Item to be changed
(MENU) <* C>
Item to be changed
(MENU)
(BZ)
(BAUDP) <* C>
( - )
(Vinit2)
(STRB-C) <* C>
- 16 -
The groups of Operation
Mode Setting
Group 1
Group 2
Group 3
Group 4
UP/DOWN switch
UP position
Increase in gain
ON
Preset2 (±0dB)
Preset4 (+12dB)
Continuous
(NORMAL)
High speed (HIGH)
Shorter
Increase in offset
All pixels (NORMAL)
Write
UP position
ON
-
-
ENABLED
Write
UP position
<* C> ON
<* C> ON
19200 bps
-
DISABLED
<* C> Positive logic
(INVERTED)
ON
K11208a;16/36
Operation state of camera at
start-up
By normal automatic loading
(→ Table 6-8)
Start-up with the settings
stored in program page A
DOWN position
Decrease in gain
OFF
Preset1 (-3dB)
Preset3 (+6dB)
Asynchronous
(ASYNC)
Low speed (LOW)
Longer
Decrease in offset
Partial (PARTIAL)
Read
UP/DOWN switch
DOWN position
OFF
-
-
DISABLED
Read
UP/DOWN switch
DOWN position
OFF
OFF
9600 bps
-
ENABLED
Negative logic
(NORMAL)
OFF
