White Mountain LS18SRAO-1 Installation And Owner's Manual

Log set for unvented gas log heater or vented decorative appliance

Advertisement

The White Mountain Log Collection
STACKED AGED OAK
INSTALLer:
Leave this manual with the appliance.
cONSuMer:
retain this manual for future reference.
wArNINgS
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
wHAT TO DO If YOu SMeLL gAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone
in your building.
Immediately call your gas supplier from neighbor's
phone. follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire de-
partment.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.

INSTALLATION INSTrucTIONS

AND OwNer'S MANuAL
LOg SeT fOr uNVeNTeD
gAS LOg HeATer
VeNTeD DecOrATIVe APPLIANce
MODeLS
LS18SrAO-1
LS24SrAO-1
LS30SrAO-1
Log sets comply with ANSI Z21.11.2 unvented Heaters and
also comply with ANSI Z21.60 Decorative Vented Appliances
for Solid fuel Burning fireplaces. State or local codes may
only allow operation of log sets in a vented configuration.
check your state or local codes.
wArNINg: If not installed, operated and maintained in ac-
cordance with the manufacturer's instructions, this product
could expose you to substances in fuel or from fuel combus-
tion which can cause death or serious illness.
The Qr code below provides a link to our helpful
"how-to" video. To get started, scan the code with
your smart phone or tablet.
Or
GAS-FIRED
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS18SRAO-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for White Mountain LS18SRAO-1

  • Page 1: Installation Instructions

    INSTALLATION INSTrucTIONS AND OwNer'S MANuAL The White Mountain Log Collection LOg SeT fOr uNVeNTeD STACKED AGED OAK gAS LOg HeATer VeNTeD DecOrATIVe APPLIANce MODeLS LS18SrAO-1 LS24SrAO-1 LS30SrAO-1 GAS-FIRED INSTALLer: Leave this manual with the appliance. cONSuMer: retain this manual for future reference.
  • Page 2: Table Of Contents

    REQUIREMENTS FOR CANADA ................4 LOG IDENTIFICATION ....................5 LOG PLACEMENT ....................6-14 EMBER PLACEMENT - ALL BURNERS ..............15 PLACEMENT OF GLOWING EMBERS LS18SRAO-1 ........16-17 PLACEMENT OF GLOWING EMBERS LS24SRAO-1 ........18-19 PLACEMENT OF GLOWING EMBERS LS30SRAO-1 ........20-21 PARTS LIST & PARTS VIEW .................22 MASTER PARTS DISTRIBUTOR LIST ..............23...
  • Page 3: Important Installation Guidelines

    IMPOrTANT INSTALLATION guIDeLINeS Proper Log Placement wArNINg: Do not allow fans to blow directly into the fireplace. Log placement is critical to proper burner performance. Logs must Avoid any drafts that alter burner flame patterns. be correctly positioned onto the burner. The photos in this manual wArNINg: Do not use a blower insert, heat exchanger insert or show the proper pinned position for logs on this set.
  • Page 4: Requirements For Canada

    reQuIreMeNTS fOr cANADA wArNINg; DO NOT OPerATe THIS gAS LOg SeT wITH This unit cannot be installed in a UNVENTED application, this gLASS DOOrS cLOSeD unit can only be installed as a VENTED application with these requirements. • Clothing or other flammable material should not be placed on or near the appliance.
  • Page 5: Log Identification

    LOg IDeNTIfIcATION 30583-1-1013 Page 5...
  • Page 6: Log Placement

    LOg PLAceMeNT Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are not properly and firmly positioned in the appliance.
  • Page 7 LOg PLAceMeNT Place Back Ember Log (A) between the rear log support shelf and the main burner pan. The left side of the Back Ember Log will set on the venturi shield. TOP VIew Scan this code to see the log assembly video. frONT VIew 30583-1-1013 Page 7...
  • Page 8 LOg PLAceMeNT Place the Back Right Log (B) so that it sets on Back Ember Log (A) and the main burner pan. The back of the Back Right Log will rest against the rear log support shelf. TOP VIew Scan this code to see the log assembly video. frONT VIew Page 8 30583-1-1013...
  • Page 9 LOg PLAceMeNT Place the Back Left Log (C) on the left side of the burner pan. The right side of the Back Left Log (C) fits into the cut out on the Back Ember Log (A). TOP VIew Scan this code to see the log assembly video. frONT VIew 30583-1-1013 Page 9...
  • Page 10 LOg PLAceMeNT Place the Front Left Log (D) onto the two front left pins on the burner pan. TOP VIew Scan this code to see the log assembly video. frONT VIew Page 10 30583-1-1013...
  • Page 11 LOg PLAceMeNT Place the Front Right Log (E) onto the two front right pins on the burner pan. TOP VIew Scan this code to see the log assembly video. frONT VIew 30583-1-1013 Page 11...
  • Page 12 LOg PLAceMeNT Place the Top Middle Log (F) into the right recess on the Back Left Log (C) and the left end of the Right Front Log (E). TOP VIew Scan this code to see the log assembly video. frONT VIew Page 12 30583-1-1013...
  • Page 13 LOg PLAceMeNT Place the Top Left Log (G) into the left recess on the Back Left Log (C) and the recess on the Front Left Log (D). TOP VIew Scan this code to see the log assembly video. frONT VIew 30583-1-1013 Page 13...
  • Page 14 LOg PLAceMeNT Place the Top Right Log (H) into the recess on the Back Right Log (B) and right recess on the Front Right Log (E). TOP VIew Scan this code to see the log assembly video. frONT VIew Page 14 30583-1-1013...
  • Page 15: Ember Placement - All Burners

    eMBer PLAceMeNT - ALL BurNerS TOP VIew frONT VIew 30583-1-1013 Page 15...
  • Page 16: Placement Of Glowing Embers Ls18Srao-1

    PLAceMeNT Of gLOwINg eMBerS LS18SrAO-1 Page 16 30583-1-1013...
  • Page 17 PLAceMeNT Of gLOwINg eMBerS LS18SrAO-1 Area for glowing embers. Do not cover any large rear ports with glowing embers. Do not cover any large front ports with glowing embers. 30583-1-1013 Page 17...
  • Page 18: Placement Of Glowing Embers Ls24Srao-1

    PLAceMeNT Of gLOwINg eMBerS LS24SrAO-1 Page 18 30583-1-1013...
  • Page 19 PLAceMeNT Of gLOwINg eMBerS LS24SrAO-1 Area for glowing embers. Do not cover any large rear ports with glowing embers. Do not cover any large front ports with glowing embers. 30583-1-1013 Page 19...
  • Page 20: Placement Of Glowing Embers Ls30Srao-1

    PLAceMeNT Of gLOwINg eMBerS LS30SrAO-1 Page 20 30583-1-1013...
  • Page 21: Placement Of Glowing Embers Ls30Srao-1

    PLAceMeNT Of gLOwINg eMBerS LS30SrAO-1 Area for glowing embers. Do not cover any large rear ports with glowing embers. Do not cover any large front ports with glowing embers. 30583-1-1013 Page 21...
  • Page 22: Parts List & Parts View

    PArTS LIST & PArTS VIew Attention: When ordering parts, it is very important that part number and description of part coincide. STAcKeD refrAcTOrY AgeD OAK LOgS INDeX PArT NO. DeScrIPTION LeTTer LS18SrAO-1 R11426 BACK EMBER LOG R11425 BACK RIGHT LOG R6080 BACK LEFT LOG...
  • Page 23: Master Parts Distributor List

    MASTer PArTS DISTrIBuTOr LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort. com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit.
  • Page 24 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com Page 24 30583-1-1013...
