The White Mountain Log Collection
AGED OAK
INSTALLer: Leave this manual with the
appliance.
cONSuMer: retain this manual for future
reference.
wArNINgS
If the information in this manual is not followed
exactly, a fire or explosion may result causing
property damage, personal injury or loss of
life.
– Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
wHAT TO DO If YOu SMeLL gAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use
any phone in your building.
•
Immediately call your gas supplier from neigh-
bor's phone. follow the gas supplier's instruc-
tions.
•
If you cannot reach your gas supplier, call the
fire department.
– Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.

INSTALLATION INSTrucTIONS

AND OwNer'S MANuAL
LOg SeT fOr uNVeNTeD
gAS LOg HeATer
VeNTeD DecOrATIVe APPLIANce
MODeLS
LS-18rAO-1
LS-24rAO-1
LS-30rAO-1
Log sets comply with ANSI Z21.11.2 unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid fuel
Burning fireplaces. State or local codes may only
allow operation of log sets in a vented configuration.
check your state or local codes.
wArNINg: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to
substances in fuel or from fuel combustion which
can cause death or serious illness.
Or
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS-18RAO-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for White Mountain LS-18RAO-1

Summary of Contents for White Mountain LS-18RAO-1

  • Page 1: Installation Instructions

    The White Mountain Log Collection AGED OAK INSTALLer: Leave this manual with the appliance. cONSuMer: retain this manual for future reference. wArNINgS If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 2: Table Of Contents

    Section Page Important Installation Guidelines ...3 General Information...3 Requirements for Canada ...4 Log Placement ...5 LS-18RAO-1 Photos ...6 LS-24RAO-1Photos ...7 LS-30RAO-1 Photos ...8 Parts List & Parts View ...9 Master Parts Distributor List ...10 How to Order Repair Parts ...10 Service Notes ...11...

  • Page 3: Important Installation Guidelines

    IMPOrTANT INSTALLATION guIDeLINeS Proper Log Placement Log placement is critical to proper burner performance. Logs must be correctly positioned onto the burner. The photos in this manual show the proper pinned position for logs on this set. Owners need to be shown proper log placement and instructed not to move the logs.

  • Page 4: Requirements For Canada

    reQuIreMeNTS fOr cANADA This unit cannot be installed in a UNVENTED application, this unit can only be installed as a VENTED application with these requirements. IMPOrTANT SAfeTY INfOrMATION This unit complies with ANSI Z21.60and CGA 2.26 Decorative Gas Appliances For Installation In Solid Fuel Burning Fireplaces. Do not burn wood or solid fuels in a fireplace where a decorative gas log set is installed.

  • Page 5: Log Placement

    Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are not properly and firmly positioned in the appliance.

  • Page 6: Ls-18Rao-1 Photos

    LS-18rAO-1 PHOTOS Page 6 25736-0-0309...

  • Page 7: Ls-24Rao-1Photos

    LS-24rAO-1 PHOTOS 25736-0-0309 Page 7...

  • Page 8: Ls-30Rao-1 Photos

    LS-30rAO-1 PHOTOS Page 8 25736-0-0309...

  • Page 9: Parts List & Parts View

    Attention: When ordering parts, it is very important that part number and description of part coincide. refrAcTOrY AgeD OAK LOgS INDeX NO. PArT NO. DeScrIPTION LS-18rAO-1 R-6081 LEFT FRONT LOG R-6083 RIGHT FRONT LOG R-6080 LEFT REAR LOG R-6082 RIGHT REAR LOG...

  • Page 10: Master Parts Distributor List

    MASTer PArTS DISTrIBuTOr LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort.com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit.

  • Page 11: Service Notes

    SerVIce NOTeS 25736-0-0309 Page 11...
  • Page 12 EMPIRE EMPIRE Comfort Systems Page 12 Empire Comfort Systems Inc. 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.empirecomfort.com 25736-0-0309...
