Sensor Connections

Two terminal blocks are provided for making connections to analog and digital sensors.
These blocks are located inside MONITOR, behind the front panel. The terminals are
numbered 1 to 22. The following table gives a short description of each of the terminals.
Detailed notes describing how to connect sensors to the terminal blocks are provided in
the setup section of this manual.
Terminal
Block
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Description Notes
AGND Analog ground
Analog 0-5V 'A' Voltage input for sensors with
Analog 0-5V 'B' Voltage input for sensors with
AGND Analog ground
2.5V output (turned on during
VREF
measurement)
DIFF 'C' (+) Differential voltage
DIFF 'C' (- )
DIFF 'D' (+) Differential voltage
DIFF 'D' (- )
24V (4-20ma) 24 Volt output for 2 wire
I-Input (4-20ma) Current input for 2 wire
Counter Input Frequency/period
Gnd Digital ground
Switched battery (turned on during
SW'D Batt
measurement)
Connect 2 wire 'VOLTAGE' wire here (eq. 24 Volts) – not
4-20ma Output (+)
used by MONITOR
4-20ma Output (-) Connect 2 wire '-' terminal here – not used by MONITOR
GND Digital ground
input for bridge type sensors
input for bridge type sensors
4-20ma sensor
4-20ma sensor
measurements
7
0-5V output
0-5V output
warmup and analog sensor
warmup and analog sensor
