INVENTOR H3TBI-100 Owner's Manual

INVENTOR H3TBI-100 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Thank you for selecting INVENTOR
air conditioners.Please read this manual
carefully before operation and keep it for
1
66129905484
further reference.
Models
H3TBO-100
H3TBI-100
H3TBI-120
H3TBO-120
Owner's Manual
Ducted unit
