BX-4
MK Diamond Products, Inc.
BRICK SAW WITH OR WITHOUT
MISTING DUST CONTROL
OWNER'S MANUAL & OPERATING INSTRUCTIONS
Revision 110
Enter the Serial Number of your new saw in the space below.
The Serial Number is located on the left side of the blade guard.
SERIAL NUMBER:
CAUTION:
Read all safety and operating instructions
before using this equipment
NOTE:
For your (1) one year warranty to be effective, complete the warranty card
(including the Serial Number) and mail it in as soon as possible.
06.2014
14
U.S. Patent No. 7,284,547,
7,159,586 and 6,687,972
