MA1004-EA
Your watch may differ somewhat from the one shown in the illustration.
[Module 5171]
To set the time
1.
When the second hand is at
12 o'clock, pull out the crown to the
second click to stop it.
2.
Set the hands by rotating the crown.
Move the minute hand four or five
minutes past the setting you want, and
then back them up to the setting.
3.
Push the crown back in on a time
signal to resume timekeeping.
To set the day
Avoid setting the day between 9:00
p.m. and 1:00 a.m. The day may not
change in the following day if you do.
1.
Pull out the crown to the first click.
2.
Set the day by rotating the crown.
3.
Push the crown back in to its normal
position.
24-hour hand
The 24-hour hand indicates the current hour of the day, making one complete
rotation every 24 hours.
[Module 5172]
To set the time
1.
When the second hand is at 12 o'clock, pull out
the crown to stop it.
2.
Set the hands by rotating the crown. Move
the minute hand four or five minutes past the
setting you want, and then back them up to
the setting.
3.
Push the crown back in on a time signal to
resume timekeeping.
24-hour hand
The 24-hour hand indicates the current hour of
the day, making one complete rotation every 24
hours.
For a watch with an elapsed time bezel
Rotate the elapsed time bezel to align the
minute hand.
After certain amount of time elapsed, read the graduation on
the elapsed time bezel which the minute hand points to.
The elapsed time is indicated.
Some water resistant models are equipped with a screw lock
crown.
With such models, you must unscrew the crown in the
direction noted in the illustration to loosen it before you can
pull it out. Do not pull too forcibly on such crowns.
Also note that such watches are not water resistant while their
crowns are loosened. Be sure to screw the crowns back in as
far as they will go after making any setting.
Module No.
5171/5172
Operation Guide 5171/5172
Crown
(Normal position)
Day
24-hour hand
24-hour hand
mark with the
Elapsed time bezel

Specifications

Accuracy at normal
temperature
Battery type
(per month)
±20 seconds
SR621SW
First click
(Day setting)
Second click
(Time setting)
Crown
Battery life
Approx. 3 years
1
