- Page 1 THE SUPER CUB OWNER’S MANUAL...
-
Page 2: Table Of Contents
CONTENTS Read First ------------------------------------------------------------------Page 2 General Overview & Introduction-------------------------------------Page 3 Panel Overview------------------------------------------------------------Page 4 Panel Description---------------------------------------------------------Page 5 Transporting and storing ----------------------------------------------Page 7 Specifications--------------------------------------------------------------Page8 Service/Warranty information-----------------------------------------Page 9... -
Page 3: Read First
Thank you for purchasing the AAD SUPER CUB Guitar Amplifier. A great deal of dedication and passion went into designing and building this no compromise, high performance compact-combo amplifier. It was conceived to be a dedicated amplifier for the “connoisseur” guitarist. Reading this manual will enable you to get the best performance from it so that you may enjoy many years of service. -
Page 4: General Overview & Introduction
OVERVIEW OF THE SUPER CUB The SUPER CUB is not your usual combo amp. On first appearance it may be mistaken for what it is because of its diminutive size. Don’t let this fool you, this is a very high performance amplifier designed to give the utmost fidelity for acoustic guitar or any other lead musical instrument where clean sound and absolute fidelity are paramount. -
Page 5: Panel Overview
FRONT PANEL OVERVIEW INPUT A POWER CLIP INPUT LEVEL BASS TREBLE FX SEND FX RETURN MUTE CH 1 HIGH -18dB -18dB +18dB -18dB +18dB -18dB +18dB INPUT B CLIP INPUT LEVEL BASS TREBLE FX BLEND MASTER VOL MUTE CH 2 HIGH -18dB -18dB... -
Page 6: Panel Description
FRONT PANEL DESCRIPTION 1. POWER INDICATOR 2. INSTRUMENT INPUT JACK CHANNEL ONE. This is a standard ¼ inch mono jack socket. 3. INPUT GAIN SWITCH CHANNEL ONE. High: Higher sensitivity, high impedance input (80mV/4.7MΩ). Low: Lower sensitivity input setting (250mV) for guitars with onboard electronics. Mute: mute the input stage, when switch on, the clip LED will light up with green. -
Page 7: Back Panel Description
18. ROTARY ENCODER FOR EFFECTS SELECTION 19. EFFECTS BLEND CONTROL 20. MASTER VOUME CONTROL This is the master volume control and it controls how much power you send to your speakers as well as the line out socket on the back of the amp. When setting up your tone or plugging in your instrument, you should keep this control at a low level. -
Page 8: Transporting And Storing
• Do not store the SUPER CUB in temperatures below -20 Degrees C or above 40 Degrees C. • Do not allow it to get wet. If this occurs, never turn it on in this condition. • Do not leave the SUPER CUB connected to a power source for long periods of time. -
Page 9: Specifications
SPECIFICATIONS Speaker Computer Optimized Enclosure Speaker Frequency Response: 80Hz –15KHz Speaker Compliment: 6 x 5inch proprietary NEO-POWER, extended-range drivers Speaker Sensitivity: 97dB/W/M Internal Speaker Impedance: 6 Ohms Dimensions: Inches 12.5W x 13.75D x 14.75H mm 320 W x 350 D x 375 H Speaker Net Weight: 27.5 Lbs / 12.5Kg Amplifier 250watt Solid State class AB amplifier with digital switch mode power supply. -
Page 10: Service/Warranty Information
PJB-ST001 tripod stand SERVICE/WARRANTY INFORMATION The SUPER CUB has a warranty period of 2 years, starting from the date of purchase. The buyer must complete and return the enclosed warranty card within 14 days of purchase. This warranty covers defect in materials or workmanship that occurs in normal use. Within warranty period AAD will repair or replace the defect unit free of labor and parts charge.
