- Page 1 PORTABLE PA USER’S GUIDE For: Français, Deutsch, Español, visit www.jblpro.com...
-
Page 2: Table Of Contents
Contents Section 1: Important Safety Instructions ......3 - 4 Section 2: Precautions ............Section 3: Declaration of Conformity ........Section 4: Introduction To The EON 206P PA System 7 - 11 Section 5: System Specifications ........Section 6: Cables and Connectors ........ -
Page 3: Section 1: Important Safety Instructions
Section 1: Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. -
Page 4: Care And Cleaning
Care and Cleaning EON 206P systems may be cleaned with a dry cloth. Do not get moisture into any of the openings in the system. Ensure that the system is unplugged from the AC outlet before cleaning. THIS APPARATUS CONTAINS POTENTIALLY LETHAL VOLTAGES. TO PREVENT ELECTRIC SHOCK OR HAZARD, DO NOT REMOVE CHASSIS, MIXER MODULE OR AC INPUT COVERS. -
Page 5: Section 2: Precautions
Section 2: Precautions The EON 206P PA system covered by this manual is not intended for use in high moisture environments. Moisture can damage the speaker cone and surround and cause corrosion of electrical contacts and metal parts. Avoid exposing the speakers to direct moisture. -
Page 6: Section 3: Declaration Of Conformity
Section 3: EON 206P PA System Declaration of Conformity This equipment complies with the EMC directive 89/336/EEC Modified by 92/31/EEC 93/68/EEC 98/13/EEC and LVD 73/23/EEC modified by 93/68/EEC This product meets safety standards: EN60065:2002 UL6500 7th Edition: 2003 UL 60065 - STANDARD FOR AUDIO, VIDEO AND SIMILAR ELECTRONIC APPARATUS - SAFETY EQUIREMENTS - Edition 7 - Revision Date 2007/12/11 CSA C22.2 NO 60065-03 - AUDIO, VIDEO AND SIMILAR ELECTRONIC APPARATUS –... -
Page 7: Section 4: Introduction To The Eon 206P Pa System
Section 4: Introduction To The EON 206P PA System Thank you for choosing the JBL EON 206P PA system. The EON 206P is a self-contained, portable PA system featuring multiple input channels with individual tone controls, reverb and convenient output routing capabilities that allow the user to integrate the system into any number of audio environments. - Page 8 4. Connect the Mixer Module to the Speakers On the back side of the mixer you will notice two ¼" phone jacks – these are your speaker output jacks. Take the speaker cables and connect them from these jacks to the jacks on the back of the speakers. To Left speaker To Right speaker 5) Connecting the AC Power Cable...
- Page 9 CH 3/4 CH 5/6 MONITOR VOLUME VOLUME VOLUME VOLUME LINE LINE JBL PROFESSIONAL NORTHRIDGE, CA. USA A HARMAN INTERNATIONAL COMPANY SERIAL NO: CH 1 CH 2 CH 3/4 CH 5/6 MONITOR D E S I G N E D A N D E N G I N E E R E D I N T H E U S A Let’s look at the “inputs”...
- Page 10 The input labeled “CH 5/6” is a 3.5 mm stereo input of the type typically found on personal music players. This input does not have a volume control as personal music players usually have a JBL PROFESSIONAL NORTHRIDGE, CA. USA “volume control”...
-
Page 11: Master Volume
STEREO OUTPUTS: We’ve brought signals into the mixer now let’s send them somewhere…The EON 206P has Left and Right 1/4" outputs: 1. LEFT/RIGHT speaker outputs - These outputs should only be connected to the EON 206P speakers and under no condition should they be connected to the input of another electronic device. -
Page 12: Section 5: System Specifications
Individual channel Bass and Treble controls, center detent, +/-12 dB cut and boost System Limiter: On Board DSP Limiting and Tuning Speaker LF Driver: 1 x JBL 326G 165 mm (6.5 in) woofer HF Driver: 1" neodymium black mylar dome tweeter Coverage Pattern: 100º x 80º nominal Crossover Frequency: 2.2 kHz... -
Page 13: Section 6: Cables And Connectors
Section 6: Cables and Connectors The standard cable for interconnection of microphone and XLR/F to XLR/M Microphone Cable line level signal in professional audio systems. • Microphone to mixer For connecting balanced devices with 1/4 inch phone and TRS (balanced) 1/4 inch phone jack to XLR/M maybe used interchangeably. -
Page 14: Section 7: Contact Information
On The World Wide Web: www.jblpro.com Professional Contacts, Outside the USA: Contact the JBL Professional Distributor in your area. A complete list of JBL Professional international distributors is provided at our U.S.A. website: www.jblpro.com Product Registration: Register your product online at www.jblpro.com... -
Page 15: Section 8: Warranty Information
Department), 8500 Balboa Boulevard, PO. Box 2200, Northridge, California 91329 (818-893-8411). We may direct you to an authorized JBL Service Agency or ask you to send your unit to the factory for repair. Either way, you’ll need to present the original bill of sale to establish the date of purchase. Please do not ship your JBL product to the factory without prior authorization. - Page 16 Part Number: 5001426...
