Andis PMC-2 Parts List

ITEM
NO. PART NO. DESCRIPTION

Upper Housing Assy - Black

1 69036
(Includes Upper Housing and Switch
Actuator

Pivot Assembly

2 69037
(Includes Pivot Assembly and Pin)

PCB/Field Assembly

3 73024

Cord Assembly

4 73027

Lower Housing Assy - Black

5 69038
(Includes Lower Housing, Screws,
and Hanger Hook)

IMPORTANT INFORMATION

When ordering repair parts, include part number, part name and model of trimmer. For best performance, trimmer blades should be CLEANED and OILED with Andis
Clipper Oil before and after use, If repair is necessary, return to any Andis Authorized Repair Service Station, or to Andis Company, 1800 Renaissance Blvd.,
Sturtevant, Wisconsin, 53177 U.S.A.. Pack carefully, mail either Insured Parcel Post, or U.P.S. , attach a letter to outside of package explaining difficulty.
FORM 69039 Rev-A PMC-2.xls
QTY. ITEM
REQ'D NO. PART NO. DESCRIPTION
1
1
1
1
1
Rev-A 4-24-06
QTY.
REQ'D
SERVICE CENTER
