Snapper LT14H331KV Parts Manual

Snapper LT14H331KV Parts Manual

Lawn tractor manual clutch hydro drive (1991) series 1
Hide thumbs
Table of Contents

Advertisement

Quick Links

LAWN TRACTOR MANUAL CLUTCH
COPYRIGHT © 2006
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
HYDRO DRIVE (1991)
McDonough, GA, 30253 U.S.A.
Revision 2,
7/14/2006
Parts Manual for
SERIES 1
MODEL
LT14H331KV
LT14H411KV
Manual No.
TP 400-5217-2-TC-N
7006425

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT14H331KV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snapper LT14H331KV

Summary of Contents for Snapper LT14H331KV

  • Page 1 LAWN TRACTOR MANUAL CLUTCH COPYRIGHT © 2006 SNAPPER PRODUCTS, INC. ALL RIGHTS RESERVED. Parts Manual for HYDRO DRIVE (1991) McDonough, GA, 30253 U.S.A. Revision 2, 7/14/2006 SERIES 1 MODEL LT14H331KV LT14H411KV Manual No. 7006425 TP 400-5217-2-TC-N...

  • Page 3: Table Of Contents

    PAGE GROUP Hood, Bumper, Headlights Wheels - Front Wheels - Rear Engine Base & Drive Parts Transmission Support & Components Transmission Components Dash Panel Steering & Front Axles Seat, Rear Fender Clutch, Brake & Transmission Controls Transmission Group Implement Lift Parts Blade Engagement 33"...

  • Page 4: Hood, Bumper, Headlights

    Hood, Bumper, Headlights Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 5 Part No Description 7063298 KIT, Hood Assembly, Sloped Mozart HOOD (No longer available) 7016766 ROD, Hood Latch 7024980 LOGO-SNAPPER, Molded 7019397 DECAL, Stripe (R.H.) 7019398 DECAL, Stripe (L.H. Shown) 7076978 LOCKNUT, 1/4-20 Hex 7090999 SCREW, 1/4-20 x 5/8 Torx, Truss Head BUMPER (R.H.)(No longer available)

  • Page 6: Wheels - Front

    Wheels - Front Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 7 Wheels - Front Item Part No Description 7058517 ASSEMBLY, Front Tire & Rim 15x5.50-6.00 7022772 RIM, 6 x 4.50 7072704 TIRE, 15-5.50 x 6 7012234 VALVE, Air (Snap-in) 7014483 BEARING, Wheel Flanged PM .758 ID x 1.38 OD x 1.0 L 7032027 WASHER .77 x 1.5 x .06 7019417...

  • Page 8: Wheels - Rear

    Wheels - Rear Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 9 Wheels - Rear Item Part No Description 7052187 ASSEMBLY, Rear Tire & Rim (41" Deck) (No longer available) 7052186 ASSEMBLY, Rear Tire & Rim (33" Deck) (No longer available) 7016744 TIRE, 18x8.504 7036488 TIRE, 18x6.504 7016742 RIM, 8x7 7016741 RIM, 8x5.375 7012234 VALVE, Air (Snap-In) 7091502...

  • Page 10: Engine Base & Drive Parts

    Engine Base & Drive Parts Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 11 Engine Base & Drive Parts Item Part No Description 7017358 DECAL, Engine 14 HP OHV 7017313 MUFFLER, Exhaust ENGINE, Kohler Model CV14S, Spec. PS1431 7091585 NUT, 3/8-16 Hex Center Lock 7033145 BASE, Engine 7091508 BOLT, 5/16-18 x 3/4" Short Neck Carriage 7090595 BOLT, 5/16-18 x 3/4"...
  • Page 12 Engine Base & Drive Parts Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 13 Engine Base & Drive Parts Item Part No Description 7091580 BOLT, 3/8-16 x 1-3/4" Hex Flange Lock Footnotes: LAWN TRACTOR MANUAL CLUTCH SERIES 1 Note Was 90701 Manual No. 7006425 TP 400-5217-2-TC-N...

  • Page 14: Transmission Support & Components

    Transmission Support & Components Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 15 Transmission Support & Components Item Part No Description TRANSMISSION SUPPORT, R.H. (No longer available) BRACKET, Transmission Mount (No longer available) 7016360 WASHER .406 x 1.38 x .25 7017164 ROD, Release 7033061 BRACE, Torque 7016116 NUT, 5/16 Push-On 7090361 SCREW, 5/16-18x5/8" Self-Tapping TRANSMISSION SUPPORT, L.H.

  • Page 16: Transmission Components

    Transmission Components Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 17 Transmission Components Item Part No Description 7090361 SCREW, 5/16-18x5/8" Self-Tapping 7033068 COVER, Rear 7017209 DECAL, Roll 7016863 COVER, Transmission Oil Access (No longer available) 7017327 SCREW, Expansion Footnotes: LAWN TRACTOR MANUAL CLUTCH SERIES 1 Note Was 16863 Manual No. 7006425 TP 400-5217-2-TC-N...

  • Page 18: Dash Panel

    Dash Panel Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...

  • Page 19: Dash Panel

    Dash Panel Item Part No Description 7052685 PANEL, Dash 7090996 SCREW, 1/4-20x1" Phillips 7040734 SUPPORT, Steering Shaft 7051915 CHANNEL, Foot Rest 7091000 SCREW, 5/16-18x7/8" Torx, S.T. 7019400 TREAD, Left Side (Non-Skid) 7019399 TREAD, Right Side (Non-Skid) 7090361 SCREW, 5/16-18x5/8" H.C.S.T. 7033073 MOUNT, Fuel Tank/Battery 7026196...

  • Page 20: Steering & Front Axles

    Steering & Front Axles Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 21 Steering & Front Axles Item Part No Description 7017040 STEERING WHEEL 7012765 ROLL-PIN Spiral .26 x 2.25 7040610 SHAFT, Steering 7091313 PIN, Cotter 3/32 x 1.0 YZ 7014296 WASHER, Shim .5 x .75 x .03 7091584 LOCKNUT, 1/4-20 Hex Flange 7052562 ADJUSTER, Steering 7011071...

  • Page 22: Seat, Rear Fender

    Seat, Rear Fender Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 23 KNOB, 3 Prong 5/16-18 x 3/4 7011763 WASHER 5/16" 7023190 SPRING 7033085 SUPPORT, Seat 7038536 BRACKET, Seat Support, L.H. 7017149 DECAL, SNAPPER Molded Logo 7091000 SCREW, 5/16-18x7/8" Torx. Hd., S.T. 7033049 FENDER, Rear 7012431 PIN, Hair 1.12" 7023193 RIV-NUT, 5/16-18 7090799 BOLT, 5/16-18x5/8"...

  • Page 24: Clutch, Brake & Transmission Controls

    Clutch, Brake & Transmission Controls Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 25 Clutch, Brake & Transmission Controls Item Part No Description 7023656 KNOB, Shifter (Elongated) 7040716 SHIFTER, Transmission 7091597 PIN, 3/32 x 3/4" Cotter 7022182 PIN, Shifter 7033159 EXTENSION, Hub 7090112 SCREW, 1/4-28 x 2" Hex Head Cap 7090303 NUT, 1/4-28 Hex Lock 7052346 ASSEMBLY, Rub Plate 7052274...
  • Page 26 Clutch, Brake & Transmission Controls Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 27 Clutch, Brake & Transmission Controls Item Part No Description 7091530 BOLT, 1/4-20 x 3/4" Short Neck Carriage 7023182 SPOOL, Bracket 7012715 PIN, 3/8 x 1 9/32" Clevis 7091809 PIN, 1/8 x 1 1/4" Cotter BRACKET, Spool (No longer available, try modifying 7033328 to fit) 7090858 SCREW, 5/16-18 x 1/2"...

  • Page 28: Transmission Group

    Transmission Group Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 29 Transmission Group Item Part No Description 7026084 TRANSAXLE ASSEMBLY (HG, 215-1000) 7034133 LEVER, Release 7076978 NUT, 1/4-20 Hex Lock 7017166 SPACER .37 OD x .271 ID x .120 L 7016927 SPRING, Brake Return 7091511 NUT, 5/16-18 Hex 7090187 WASHER, 5/16 Split Lock 7052281 TORQUE BRACKET ASSEMBLY 7017121...
  • Page 30 Transmission Group Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 31 Transmission Group Item Part No Description 7091130 WASHER, Flat .327 x .875 x .09 7011968 ROLLER 7033054 PLATE, Speed Control NUT, Special 3/4 Hex Stock/5/16-24 Thru/9/16-18x1.0 Deep (No longer available) 7076940 SCREW, 5/16-18 x 4-1/2, Hex Head Cap 7090924 SCREW, 5/16-18 x 4-1/8" Hex Head Cap 7016716 PULLEY, Drive 7090322...

  • Page 32: Implement Lift Parts

    Implement Lift Parts Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...

  • Page 33: Implement Lift Parts

    Implement Lift Parts Item Part No Description 7040698 ARM, Implement Lift Lever 7034041 ROD, Lift Lever 7019363 GRIP, Lift Lever 7014361 CAP, Lift Release 7047961 ARM, Rear Lift 7091503 PIN, Hair, 3/32x1-1/2" 7090122 WASHER, 3/8 SAE Flat 7032789 SPACER 7032898 BRACKET, Arm 7090369 SCREW, 5/16-18x1 H.W.H.S.T.

  • Page 34: Blade Engagement

    Blade Engagement Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...

  • Page 35: Blade Engagement

    Blade Engagement Item Part No Description 7016356 KNOB, Handle 7/16" 7040674 HANDLE, Blade Engagement 7013321 BUSHING BRACKET, Handle (No longer available) 7090122 WASHER, 3/8 SAE YZ 7091597 COTTER-PIN, 3/32 x 3/4" 7090803 BOLT, 1/4-20 x 5/8" Flat Head Carriage 7091584 LOCKNUT, 1/4-20 Hex Flange 7023206 SPACER .625 OD x .380 ID x .560 L...

  • Page 36: Cutting Deck, Belts, Brakes

    33" Cutting Deck, Belts, Brakes Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 37 33" Cutting Deck, Belts, Brakes Item Part No Description 7023710 BELT, 33" Drive Kevlar (A-59 61" OD) 7018581 PULLEY, 8" O.D. 7074467 NUT, 3/4-16 Hex Jam 7052886 BAND, Brake Assembly 7032169 DRUM, Brake 7010740 RING, 2” External Retaining 7047961 ARM, Idler 7014304 PIN, 1/4x1-1/4 Clevis 7014302...
  • Page 38 33" Cutting Deck, Belts, Brakes Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 39 33" Cutting Deck, Belts, Brakes Item Part No Description 7038453 RAIL, Side 7091304 SCREW, 3/6-16x1" Hex Head Cap 7015012 ECCENTRIC, Leveling 7091302 NUT, 3/8-18 Hex 7090118 LOCKWASHER, 3/8 Split 7032432 LINK, Adjustment 7091547 BOLT, 3/8-16x3/4" Carriage 7059784 ASSEMBLY, Spindle 7052294 HOUSING, Spindle 5.575"...
  • Page 40 33" Cutting Deck, Belts, Brakes Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 41 33" Cutting Deck, Belts, Brakes Item Part No Description 7033570 BRACKET, Gage Wheel (Front) 7033571 BRACKET, Gage Wheel (Rear) 7090731 BOLT, 5/16-18x1/2" Short Neck Carriage 7091601 NUT, 5/16-18 Hex Flange Lock 7015272 SPACER .625 OD x .423 ID x 3" L 7091532 SCREW, 3/8-24x3-3/4 H.H.C.

  • Page 42: Cutting Deck

    41" Cutting Deck Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 43 41" Cutting Deck Item Part No Description 7051916 DECK, Mower 41" 7051914 ASSEMBLY, Spindle 7027668 SPINDLE 7051918 HOUSING, Spindle 7013313 BEARING, Spindle 7012491 RING, Retaining 7014407 WASHER, Spindle 7032294 HOLDER, Blade 7010817 FITTING, Lube 7019795 BLADE, 21" Cutter 7052487 ASSEMBLY, Rear Support 7042469 ASSEMBLY, Front Hanger 7034409...
  • Page 44 41" Cutting Deck Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 45 41" Cutting Deck Item Part No Description 7074467 NUT, 3/4-16 Hex Jam 7027198 BOLT, 3/8-16x1" Hex Flange Lock 7023606 CAP, Vinyl 7090517 WASHER, 7/16 Flat 7091547 BOLT, 3/8-16x3/4" Carriage 7091508 BOLT, 5/16-18x3/4 Carriage 7012063 WASHER, 13/32x1-13/32" Dia. Cone 7090824 SCREW, 3/8-24x1-1/4" Hex Cap 7090595 BOLT, 5/16-18x3/4"...

  • Page 46: Belt, Blade Brake, 41" Deck

    Belt, Blade Brake, 41" Deck Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 47 Belt, Blade Brake, 41" Deck Item Part No Description 7015724 PULLEY, Drive 7014799 BELT, Drive 7052886 BAND, Brake Assembly 7032169 DRUM, Brake 7047912 ASSEMBLY, Brake Arm 7018574 PULLEY, Idler 7032587 ANCHOR, Brake 7014303 NUT, 1/4-20 Tec. 7014302 BOLT, 1/4-20 Eye 7011021 PIN, Clevis, 1/4x1-1/4"...

  • Page 48: Fuel Tank, Battery

    Fuel Tank, Battery Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 49 Fuel Tank, Battery Item Part No Description 7014475 CABLE, Negative Terminal 15" 8 AWG Black 7091568 WING-NUT, 1/4-20 7091294 WASHER, 1/4 SAE 7091530 BOLT, 1/4-20x3/4" Short Neck Carr. 7012444 COVER, Positive Terminal 7014434 CLAMP, Battery 7014476 CABLE, Positive Terminal 11" 8 AWG Red 7060618 KIT, Battery, 12 Volt 7023194...

  • Page 50: Electrical System

    Electrical System Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...

  • Page 51: Electrical System

    Electrical System Item Part No Description 7022699 HARNESS, Wiring (KOHLER) 7019043 HARNESS, Interlock 7023355 SWITCH, Clutch & PTO 7023354 SWITCH, Seat NC 7075622 SOLENOID 7023187 SWITCH, Light 7014562 SWITCH, Key 7073406 KEY, Switch (With Cover) 7012685 NUT, 5/8-32 Hex 7012444 COVER, Positive Terminal 7014475 CABLE, Negative 15"...

  • Page 52: Schematic Electrical System (Kohler Engines Only

    Schematic Electrical System (Kohler Engines Only) Manual No. 7006425 LAWN TRACTOR MANUAL CLUTCH TP 400-5217-2-TC-N SERIES 1...
  • Page 53 Schematic Electrical System (Kohler Engines Only) Item Part No Description Wiring schematic includes harness #'s 7022699 & 7024126 Footnotes: LAWN TRACTOR MANUAL CLUTCH SERIES 1 Note Manual No. 7006425 TP 400-5217-2-TC-N...
  • Page 56 LAWN TRACTOR MANUAL CLUTCH HYDRO DRIVE (1991) SERIES 1 IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.

This manual is also suitable for:

Lt14h411kv
