LAWN TRACTORS MANUAL CLUTCH
COPYRIGHT © 2006
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
McDonough, GA, 30253 U.S.A.
Revision 4,
2/24/2006
Parts Manual for
HYDRO DRIVE
SERIES "G"
MODEL
ELT145H33GBV
LT145H33GBV
LT145H38GBV
LT150H38GKV
WLT145H38GKV
Manual No.
TP 400-5170-4-TC-N
7006448

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLT145H38GKV and is the answer not in the manual?

Questions and answers

Related Manuals for Snapper WLT145H38GKV

Summary of Contents for Snapper WLT145H38GKV

  • Page 1 LAWN TRACTORS MANUAL CLUTCH COPYRIGHT © 2006 SNAPPER PRODUCTS, INC. ALL RIGHTS RESERVED. Parts Manual for McDonough, GA, 30253 U.S.A. Revision 4, 2/24/2006 HYDRO DRIVE SERIES "G" MODEL ELT145H33GBV LT145H33GBV LT145H38GBV LT150H38GKV WLT145H38GKV Manual No. 7006448 TP 400-5170-4-TC-N...

  • Page 3: Table Of Contents

    PAGE GROUP Wheels, Front & Rear Hood, Bumper, Headlights & Components Steering Wheel, Console, Fuel Tank Cast Front Axle Frame, Clutch, Brake & Steering Components Blade Engagement & Transmission Controls Implement Lift Parts Transmission Group (Hydro Drive) Hydro Reservoir Assembly Engine Components Belt Guide Assembly Seat, Rear Fender &...

  • Page 4: Wheels, Front & Rear

    Wheels, Front & Rear Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 5 Wheels, Front & Rear Item Part No Description 7058515 ASSEMBLY, Front Tire & Rim 7058517 ASSEMBLY, Front Tire & Rim 7072702 TIRE, 13 x 5.00 7072704 TIRE, 15 x 6.00 7022772 RIM, 6.00 x 3.50 7014483 BEARING, Wheel 7012234 VALVE, Air (Snap-in) 7076998 FITTING, Lube 1/4-28 Tapered Thread 7034453...

  • Page 6: Hood, Bumper, Headlights & Components

    Hood, Bumper, Headlights & Components Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 7 7026180 DECAL, Reflect (Left Hand) 7026179 DECAL, Reflect (Right Hand) 7022968 DECAL - SNAPPER, 4" Molded Logo (Silver Letters - Blue Stripe) 7090858 SCREW, 5/16-18 x 1/2" Self-Tapping, Grade 5 7024061 BOLT, Shoulder, 3/8-16 x 1-1/4" Hex Socket, Torx 7034324...

  • Page 8: Steering Wheel, Console, Fuel Tank

    Steering Wheel, Console, Fuel Tank Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...

  • Page 9: Key Switch

    Steering Wheel, Console, Fuel Tank Item Part No Description 7053746 ASSEMBLY, Console 7028565 CONSOLE 7011791 RETAINER 7091495 SCREW, 1/4-20 x 3/4" Hex Head Cap, Grade 5 7052891 ASSEMBLY, Strap-Clinch Stud 7076978 NUT, 1/4-20 Hex Nyloc 7026196 ASSEMBLY, Flange Bearing 7091575 NUT, 5/16-18 Hex Center Lock, Grade 5 7022368 GEAR, Pinion, Steering Shaft...

  • Page 10: Cast Front Axle

    Cast Front Axle Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...

  • Page 11: Cast Front Axle

    Cast Front Axle Item Part No Description 7010746 RING, 5/8 External Retaining 7010935 WASHER, 49/64 x 1-1/8 x 1/16" Flat 7014669 FITTING, 3/16 Lube 7019034 ARM, Steering 7072411 AXLE, Cast 7028666 SPACER, 25/64 x 1/2 x 1-13/16" 7028689 SPACER, Center 7031036 WASHER, Thrust 7033383...

  • Page 12: Frame, Clutch, Brake & Steering Components

    Frame, Clutch, Brake & Steering Components Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 13 Frame, Clutch, Brake & Steering Components Item Part No Description 7073345 FRAME, Tractor (1 piece) 7014451 TIE, Wire 7027936 ROD END 7090482 NUT, 3/8-24 Hex Jam 7090163 SCREW, 3/8-24 x 1-1/4" Hex Cap 7028420 LINK, Drag 7024180 SPACER 7091619 NUT, 3/8-16 Hex Flange Lock 7053568 ASSEMBLY, Sector Gear 7012706...
  • Page 14 Frame, Clutch, Brake & Steering Components Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 15 Frame, Clutch, Brake & Steering Components Item Part No Description 7013864 LUBE FITTING, Straight (press-fit for .187 dia. Hole) 7090509 WASHER, 1/2" Internal Tooth Lock 7090619 NUT, 1/2-13 Hex Flange Lock 7027344 WASHER, 5/8" Flat 7023645 PIN, 3/16 x 1-1/2" Clevis 7022742 BEARING, Flange 7041236...
  • Page 16 Frame, Clutch, Brake & Steering Components Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 17 Frame, Clutch, Brake & Steering Components Item Part No Description 7047072 BRACKET, Frame Brace 7090731 BOLT, 5/16-18 x 5/8" Short Neck Carriage, Grade 5 7091541 SCREW, 5/16-18 x 3/4" Self-Tap 7091593 COTTER PIN, 1/16 x 1-7/32" Self Lock 7072598 BRACKET, Mounting Brace 7090316 BOLT, 5/16-18 x 3/4"...

  • Page 18: Blade Engagement & Transmission Controls

    Blade Engagement & Transmission Controls Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 19 Blade Engagement & Transmission Controls Item Part No Description 7073345 FRAME, Tractor (1 Piece) 7024616 BUSHING, Flange 7033488 BRACKET, Hood Pivot 7028630 CLIP, Wire 7091598 PIN, 1/8 x 3/4" Cotter 7014296 WASHER, 1/2 Shim 7091573 BOLT, 1/4-20 x 5/8" Short Neck Carriage, Grade 5 7052562 ASSEMBLY, Steering Adjuster 7091584...
  • Page 20 Blade Engagement & Transmission Controls Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 21 Blade Engagement & Transmission Controls Item Part No Description 7041238 WELDMENT, Bellcrank PTO 7031036 WASHER, Thrust 7090509 WASHER, 1/2" Internal Tooth Lock 7041237 WELDMENT, PTO Link 7042598 WELDMENT, PTO Lever 7029152 CABLE, 33 Blade (33" Deck) 7046896 CABLE, PTO (38" Deck) 7090500 WASHER, 7/16"...

  • Page 22: Implement Lift Parts

    Implement Lift Parts Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 23 Implement Lift Parts Item Part No Description 7041655 LEVER, Implement Lift (33" Decks) 7041015 LEVER, Implement Lift (38" Decks) 7022565 ROD, Lift Lever 7019363 KNOB, Lift Lever 7014361 CAP, Lift Lever Rod 7033449 QUADRANT, Lift Lever 7091001 SCREW, 5/16-18 x 5/8" Truss Head (Torx) 7091000 SCREW, 5/16-18 x 7/8"...

  • Page 24: Transmission Group (Hydro Drive)

    Transmission Group (Hydro Drive) Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 25 Transmission Group (Hydro Drive) Item Part No Description 7074398 ASSEMBLY, Transaxle, Tuff Torq 7072387 ROD, Roll Release (K46) 7091708 PIN, Clevis 1/4" x 5/8" 7091294 WASHER, 1/4 x 5/8 x 1/16" Flat 7091597 PIN, 3/32" x 1/2" Cotter 7072601 BRACKET, Torque 7091497 SCREW, 3/8-16 x 1-1/2"...

  • Page 26: Hydro Reservoir Assembly

    Hydro Reservoir Assembly Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...

  • Page 27: Cable Tie

    Hydro Reservoir Assembly Item Part No Description 7072739 BRACKET, Reservoir Mounting 7072736 RESERVOIR, Expansion 7016130 CLAMP, 13/16" 7072901 HOSE, Hydraulic 4-1/2" Long 7091431 VALVE, Vent 7090858 BOLT, 5/16-18 x 1/2" Hex Washer Self-Tap 7072914 CABLE TIE, 9" Footnotes: LAWN TRACTORS MANUAL CLUTCH SERIES "G"...

  • Page 28: Engine Components

    Engine Components Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...

  • Page 29: Engine Components

    Engine Components Item Part No Description * ENGINE, B & S 14.5 HP, Model 287707-1250-E1 * ENGINE, Kohler 15.0 HP, Model CV15S, PS-41603 7090391 WASHER, 5/16 Internal Tooth Lock 7072905 ASSEMBLY, Engine Pulley (LT145H33GBV & ELT145H33GBV) 7073804 ASSEMBLY, Engine Pulley (LT145H38GBV & LT150H38GBV) 7091301 WASHER, 7/16 Split Lock 7091579...

  • Page 30: Belt Guide Assembly

    Belt Guide Assembly Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...

  • Page 31: Belt Guide Assembly

    Belt Guide Assembly Item Part No Description 7035963 BRACKET, Belt Guide 7091575 NUT, 5/16-18 Hex Center Lock, Grade B or 5 7028303 2 or 4 STUD, Belt Guide 7035528 STUD, Belt Guide 38" Dual Brake Deck 7072924 STUD, Belt Guide 7028304 STUD, Belt Guide 33"...

  • Page 32: Seat, Rear Fender & Components

    Seat, Rear Fender & Components Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 33 7091819 SCREW, 1/4-20 x 5/8" Hex Washer Head, Self-Tapping 7073346 PAN, Seat (Fender) 7091761 RIV-NUT, 5/16-18 Round 7022971 DECAL - SNAPPER, 7.28" Molded Logo, Silver Letters & Blue Stripe 7026415 DECAL - CAUTION, Battery Location 7073344 SUPPORT, Fender 7091523 SCREW, 5/16-18 x 5/8" Hex Washer Head 7091524 SCREW, 5/16-18 x 1-1/4"...

  • Page 34: Decals (Part 1)

    Decals (Part 1) Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 35 Decals (Part 1) Item Part No Description 7026154 DECAL, 38 Inch 7022991 DECAL, 33 Inch Hi-Vac 7014852 DECAL, Caution, Rotating Blades 7014852 DECAL, Caution, Rotating Blades 7026415 DECAL, Caution, Battery Location 7029784 DECAL, Deck/Chute International Warning 7013010 DECAL, Danger, Cut-Finger 7013010 DECAL, Danger, Cut-Finger (Heavy Adhesive Version) 7022841...

  • Page 36: Decals (Part 2)

    Decals (Part 2) Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 37 Decals (Part 2) Item Part No Description 7073433 DECAL, 2001 Year of Manufacture 7072820 DECAL, 2000 Yr. of Mfr. 7072404 DECAL, 1999 Yr. of Mfr. 7028561 DECAL, Console, Basic 7073579 DECAL, Console (2001 Model Year) 7023009 DECAL, Noise Control, Euro 7026377 LOGO, Convert- Blue/Silver 7029776...

  • Page 38: 33" Cutting Deck, Belts, Brakes

    33" Cutting Deck, Belts, Brakes Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 39 33" Cutting Deck, Belts, Brakes Item Part No Description 7061956 ASSEMBLY, Deck 33" Cutting 7026558 PULLEY, Spindle, 7" O.D. 7074467 NUT, 3/4-16 Hex Jam 7014304 PIN, 1/4 x 1-1/4" Clevis 7052886 ASSEMBLY, Brake Band 7032169 DRUM, Brake 7024192 ROD, Link, Clutch/Brake 7010740 RING, 2”...
  • Page 40 33" Cutting Deck, Belts, Brakes Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 41 33" Cutting Deck, Belts, Brakes Item Part No Description 7091532 SCREW, 3/8-24 x 3-3/4" Cap, Gr. 5 7052555 ASSEMBLY, Deflector 7026483 PALNUT, 1/4 Hex 7026234 PIN, Hinge 7091588 BOLT, 3/8-16 x 3/4" Flange Lock, Gr. 5 7033780 HINGE, Deflector 7026233 DEFLECTOR, Discharge 7013010 DECAL, Danger (Cut Finger)
  • Page 42 33" Cutting Deck, Belts, Brakes Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 43 33" Cutting Deck, Belts, Brakes Item Part No Description 7019523 ASSEMBLY, Blade & Air Lift 7019523 BLADE, 33" Cutting Deck Euro 7037723 AIR-LIFT 7034468 AIR-LIFT (European) 7090228 SCREW, 5/16-24 x 11/16" Machine 7090391 WASHER, 5/16 Int. Tooth Lock 7091297 NUT, 5/16-24 Hex, Grade 5 7033571 BRACKET, Gage Wheel (Rear) 7042608...

  • Page 44: Spindle - 33" Cutting Deck

    Spindle - 33" Cutting Deck Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 45 Spindle - 33" Cutting Deck Item Part No Description 7052917 ASSEMBLY, Spindle Housing, 33" Cutting Deck (Not shown, includes items 2 thru 11) 7012491 RING, Retaining 7013313 BEARING, Spindle 7052294 HOUSING, Spindle 7010817 FITTING, Lube 7090491 SCREW, 1/2-20 x 1-1/4" Hex Head Cap, Grade 5 7091939 NUT, 1/2-20 Hex Jam 7090356...

  • Page 46: 38" Cutting Deck Assembly (Part 1)

    38" Cutting Deck Assembly (Part 1) Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 47 38" Cutting Deck Assembly (Part 1) Item Part No Description 7061960 DECK, 38" 7028365 BRACKET, Front Linkage 7033756 BRACKET, LH Front Gage Wheel 7033891 BRACKET, LH Rear Wheel 7034875 ANGLE, Front 7035494 BRACKET, RH Front Gage Wheel 7035505 CRADLE, Spring 7035506 GUIDE, Belt Dual Spindle Brake 7035577...

  • Page 48: 38" Cutting Deck Assembly (Part 2)

    38" Cutting Deck Assembly (Part 2) Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 49 38" Cutting Deck Assembly (Part 2) Item Part No Description 7013847 RETAINER, 3/8" Bolt 7018574 IDLER, 4-1/8" Flat 7024604 BOLT, 3/4" Dia. X 3.01 Shoulder; 1/2-13 Thread 7024607 SWIVEL, Brake Link 7026122 WHEEL, Gage 38" Deck 7013010 DECAL, CPSC Cut Finger 7027168 SCREW, 5/16-18 x 1"...
  • Page 50 38" Cutting Deck Assembly (Part 2) Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 51 38" Cutting Deck Assembly (Part 2) Item Part No Description 7091675 WASHER, 11/32" I.D. Flat 7091775 WASHER, 1/2" I.D. x 2-1/2" O.D. Special "D" 7091619 NUT, 3/8-16 Hex Flange Lock 7012264 SPRING 7029025 SPRING, Extension 7091732 SCREW, 1/4-20 x 2-3/4" Hex Head Cap, Grade 5 7091576 NUT, 1/4-20 Hex, Grade 5 7091545...

  • Page 52: 38" Cutting Deck, Belts, Brakes

    38" Cutting Deck, Belts, Brakes Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 53 38" Cutting Deck, Belts, Brakes Item Part No Description 7013847 RETAINER, 3/8" Bolt 7018574 IDLER, 4-1/8" Flat 7024604 BOLT, 3/4" Dia. X 3.01 Shoulder; 1/2-13 Thread 7024607 SWIVEL, Brake Link 7026122 WHEEL, Gage 38" Deck 7013010 DECAL, CPSC Cut Finger 7027168 SCREW, 5/16-18 x 1"...
  • Page 54 38" Cutting Deck, Belts, Brakes Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 55 38" Cutting Deck, Belts, Brakes Item Part No Description 7091675 WASHER, 11/32" I.D. Flat 7091775 WASHER, 1/2" I.D. x 2-1/2" O.D. Special "D" 7091619 NUT, 3/8-16 Hex Flange Lock 7012264 SPRING 7029025 SPRING, Extension 7091732 SCREW, 1/4-20 x 2-3/4" Hex Head Cap, Grade 5 7091576 NUT, 1/4-20 Hex, Grade 5 7091545...

  • Page 56: Spindle - 38" Cutting Deck

    Spindle - 38" Cutting Deck Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 57 Spindle - 38" Cutting Deck Item Part No Description 7063198 ASSEMBLY, Spindle Housing, 38" Cutting Deck 7010817 FITTING, Lube 7012491 RING, Retaining 7013313 BEARING, Spindle 7063199 HOUSING, Spindle 7072537 SHAFT, Spindle (7.181" overall length) 7072109 WASHER, Spindle 7024467 WASHER, Belleville, 19/32" I.D. x 1-3/4" O.D. 7091633 NUT, 9/16-18 Hex Jam 7042998...

  • Page 58: Electrical Components

    Electrical Components Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 59 Electrical Components Item Part No Description 7060618 KIT, Battery 7090372 NUT, 1/4-20 Hex Center Lock, Grade B or 5 7017853 TRAY, Battery 7012485 RETAINER, 1/4" Bolt 7026414 CABLE, Ground (Black) 7075622 SOLENOID 7091122 SCREW, 1/4-20 x 1/2" Self-Tapping 7090977 NUT, 1/4-20 Hex Jam 7090053 WASHER, 1/4 Internal Tooth Lock 7014476...

  • Page 60: Electrical Illustrated Diagram - Wiring Harness P/N 26616

    Electrical Illustrated Diagram - Wiring Harness P/N 26616 Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 61 Electrical Illustrated Diagram - Wiring Harness P/N 26616 Item Part No Description 26616 7026616 WIRING HARNESS Footnotes: LAWN TRACTORS MANUAL CLUTCH SERIES "G" Note Manual No. 7006448 TP 400-5170-4-TC-N...

  • Page 62: Electrical Schematic - Wiring Harness P/N 26616

    Electrical Schematic - Wiring Harness P/N 26616 Manual No. 7006448 LAWN TRACTORS MANUAL CLUTCH TP 400-5170-4-TC-N SERIES "G"...
  • Page 63 Electrical Schematic - Wiring Harness P/N 26616 Item Part No Description 26616 7026616 WIRING HARNESS Footnotes: LAWN TRACTORS MANUAL CLUTCH SERIES "G" Note Manual No. 7006448 TP 400-5170-4-TC-N...
