Related Manuals for Trantec S-D7802

Summary of Contents for Trantec S-D7802

  • Page 2: Table Of Contents

    Table of Contents 1. Safety Precautions 2. General Description 3. Features 4. Items and Functions 5. Connection Examples 6. Menu Operation 7. Sharing An Antenna Between Two Receivers 8. Sharing An Antenna Among Three Or More Receivers 9. About The Antenna Mounting Kit 10.

  • Page 3: Safety Precautions

    The Trantec SD-7802 Receiver represents our commitment to our customers by providing high quality, reliable wireless audio links, using our considerable design expertise gained over many years as a leading edge manufacturer. Thank you for purchasing this product and please study this manual, especially the safety instructions before installing and using this equipment.
  • Page 4 DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead within a triangle is intended to tell the user that parts inside the product are a risk of electric shock to persons. The exclamation point within a triangle is intended to tell the user that important operating and servicing instructions are in the manual provided with the equipment.

  • Page 5: General Description

    2. General Description The S-D7802 is a dual UHF wireless receiver that employs a digital diversity system and supports digital audio transmission. 3. Features • High quality 32kHz/24-bit digital audio data reception • Digital audio transmission capability eliminates the need for an analog compander, thus...

  • Page 6: Menu Operation

    Channel Indicator Displays the received channel number. Note: • A dot located at the lower right of both the group and channel indicators flashes if the “CH IDENTITY” function is set to OFF • The “CH.S.” indication is displayed while scanning channels. If another indication is displayed or the indicator flashes, refer to “Network Function Manual”...
  • Page 7 Remote Indicator [REMOTE] Lights when the receiver is in remote operation mode. Refer to Section 6.1 for more information. Flashes when a PC uses the equipment verification function. Refer to Section 1.1 of the SD7000 Digital Microphone Software Manual for more information.

  • Page 8: Sharing An Antenna Between Two Receivers

    [Rear Panel] To next receiver’s antenna input Antenna Antenna Other receiver’s mixing output SIGNAL DIGITAL WIRELESS TUNER S-D7802 JAB 1 2 0 - 2 3 0 V•` 400mA 50/60H z BBM Electronics MADE IN JAPAN TERM ANTENNA CASCADE CASCADE ANTENNA...
  • Page 9 Audio Output Jacks (Unbalanced) [AF OUT] Connect to the microphone input jack or line input jack of the device being connected. Audio Output XLRs (Balanced) [AF OUT] Provide balanced outputs.

  • Page 10: Menu Operation

    6. Menu Operation Receiver Settings Screen Menu Configuration U 1 : T O P U 2 : T O P U 1 G R U 2 G R U 1 C H U 2 C H & N E L U1 ID U2 ID T O P...
  • Page 11 6.1 Receiver Settings Changes and Confirmation Two operation modes are available for receiver settings: Local mode: Change and confirm settings using the receiver’s LCD screen and keys. Remote mode: Change and confirm settings using dedicated software installed on a PC connected to the receiver via a network. (See the SD7000 Digital Microphone Monitor Software Manual).
  • Page 12 6.3. Settings Item Details 6.3.1 Receiver Operation Mode Refer to the above items 6.1 and 6.2 for explanation of menu navigation and selection. S E L 6.3.2 Frequency Settings 6.3.2.1 Band Settings Set each module unit’s band. Press the Right key, then Up and Down keys to navigate to “Top Menu 2 Frequency. Press the Right key then Up or Down keys to go to “Frequency Menu 1 Band”, and Right key again to go to the screen shown below.
  • Page 13 6.3.3 ID Number Settings Set each module unit’s ID number. From the “Top Menu 3 ID”, press the Right key to go to the ID selection screen. Using the Left and Right keys, align the cursor with the module unit for which the ID is to be changed and display the desired ID number using the Up and Down keys.
  • Page 14 desired source is displayed, press the Set key to change the setting. If the Word Clock signal is not correctly supplied when set to “External,” the band indicator, antenna attenuator indicator and RF cascade indicator flash to indicate a signal supply error.
  • Page 15 6.3.9 Global Save of Receiver Settings Current receiver settings can be globally saved in 3 steps. From “Top Menu 8 Store Setting” press the Right key then Up or Down keys to show “1 Save Setting”. Press the Right key to show the screen below. Display the setting number to be saved using the Up and Down keys.
  • Page 16 6.3.11 IP Address Confirmation Confirm the receiver’s IP address. From “Top Menu 9 Network” press the Right key then Up or Down keys to show “1 IP Address”. Press the Right key to show the screen below. R E S S 1 0 .
  • Page 17 6.4 Functions Adjustable for Operating Environment 6.4.1 Channel Scan This function checks for idle channels that are free of interference. From “Top Menu 6 Utility”, press the Right key the Up or Down keys to go to “Utility Menu 1 Channel Scan”.

  • Page 18: Sharing An Antenna Between Two Receivers

    When an antenna is shared, the RF Cascade indicator lights are lit on the receiver where the antenna is mounted. [Rear view] Antenna B Antenna A SIGNAL DIGITAL WIRELESS TUNER S-D7802 JAB 120-230V•`400mA 50/60Hz BBM Electronics MADE IN JAPAN TERM ANTENNA...

  • Page 19: About The Antenna Mounting Kit

    9. About The Antenna Mounting Kit Use the antenna mounting kit when front-mounted antennas are required. Fix the rack ears to the mounting holes, then connect the antennas and antenna distribution cables. Front Dotted line: Normal antenna View connection position Antenna distribution cable Side...

  • Page 20: Monitoring With Headphones

    10. Monitoring With Headphones Select the module unit to Confirmation of the audio output level. be monitored. Volume control Connect headphones Press the button for Unit 1 or Unit 2 to select the module to monitor. Pressing both keys allows mixed audio from both modules to be heard. 11.

  • Page 21: About The Network Function

    Parameter check and adjustment during installation Remote audio monitoring Refer to the SD7000 Digital Microphone Monitor Software Manual for more information. 13. Specifications S-D7802 Dual Channel Receiver Frequency Response: 20 Hz – 15 kHz Audio Connector: XLR ~ Analog, balanced 1/4”...

  • Page 22: Accessories Included

    UNIT 1 UNIT 2 LAN RESET REMOTE LINK/ACT PHONES DIGITAL WIRELESS TUNER S-D7802 14. Accessories Included AC Power Cord (UK use only) 2 x Antenna (direct-mount type) Antenna mounting kit: 2 x MB-15B brackets (fitted) 8 x M3x8 screws (fitted)
