User Guide
Water Heater
HSE-SBS-006 / HSE-SBS-010
SUPERIOR QUALITY
Get the best quality that
ensures you have a water
heater that works in
Indian water conditions.
MADE BETTER
Made in India's most
modern and advanced
water heater factory.
EXPERT SERVICE
Guaranteed* A. O. Smith
Service within 24 hours.
Call: 1.800.103.2468
Advertisement
Table of Contents
Related Manuals for A.O. Smith Fit it & Forget it HSE-SBS-006
Summary of Contents for A.O. Smith Fit it & Forget it HSE-SBS-006
-
Page 1: User Guide
Fit it & Water Heater HSE-SBS-006 / HSE-SBS-010 Forget it Why people prefer an A. O. Smith water heater... ADVANCED SUPERIOR QUALITY EXPERT SERVICE TECHNOLOGY Get the best quality that Guaranteed* A. O. Smith ensures you have a water Service within 24 hours. ®... - Page 2 Congratulations! And welcome to the A. O. Smith family. We would like to thank you for the trust you have shown in choosing an A. O. Smith water heater. You can be sure it will live up to your expectations. Thousands of delighted users all over the world trust A.
-
Page 3: Table Of Contents
What's in the box? User Guide Electric Wall Mounting Discharge Tube Water Heater Accessories Contents Specifications ..................1 Key Features ................... 2 Installation....................3 Directions for use ................... 5 ® A. O. Smith ColourMatch System ............6 Changing the Decorative Front Panel ........... 6 Troubleshooting .................. -
Page 4: Specifications
Specifications Model HSE-SBS-006 HSE-SBS-010 Volume [L] Power [W] 3000 2000 Voltage/Frequency [V/Hz] ~230/50 ~230/50 Actual Stdg. Loss [kWh/24h/45°C diff.] 0.390 0.490 Max. Stdg. Loss [kWh/24h/45 C diff.] [as per IS 2082:1993 amended in 2002] 0.792 0.990 Reheating Time for 35°C rise [in min] Temperature range [°C] 25-75 25-75... -
Page 5: Key Features
Key Features Glass Coated Heating Element Scale and sediment build-up on the surface of the element can lead to premature failure. A. O. Smith Glass Coating helps to prevent scale formation and extends the life of the heating element. ® Blue Diamond Glass Lining ®... -
Page 6: Installation
Installation Mounting Fig. 1 Position for installation Fig. 2 Wall mounting bracket Wall Ceiling Water heater Make sure that the wall can withstand at least twice the weight of the water heater when completely filled with water. Before locating the position for installation of the water heater, make sure that there is sufficient clearance between the ceiling and the side wall. -
Page 7: Electrical Connections
Plumbing Make necessary plumbing with reference to the installation diagram. (Fig. 5) A. O. Smith recommends nylon/SS braided hoses having a minimum pressure rating of 8 Bar and hoses should be compatible for hot water applications. Connect the cold water pipe to the inlet [Blue Cap]. Connect the hot water pipe to the outlet [Red Cap]. -
Page 8: Directions For Use
Draining Fig. 6 Safety valve For draining water from the water heater, following steps needs to be followed: Safety Valve Switch off the electric supply to the water heater. Port Open the hot water taps until the water is not hot any more. -
Page 9: A. O. Smith Colourmatch System
® A. O. Smith ColourMatch System Attention: The product of your choice comes with either white or ivory as a front panel of the same colour. You have the option of changing this panel to match your bathroom décor. ® A. -
Page 10: Troubleshooting
Troubleshooting Problem Possible Cause(s) Solution • Green and Red No power to heater Turn on electrical switch. Check for light off blown fuses or tripped breaker • No hot water Thermal cutout switch open Call Customer Care Centre Control circuit or internal Call Customer Care Centre wiring error •... -
Page 11: Warranty
Warranty Product warranty Your A. O. Smith water heater is warranted against defects arising from faulty design, workmanship and materials for a period of 24 months from the date of the invoice, subject to the following conditions: The customer will notify the Company promptly about Warranty defects noticed and give the Company or its Authorised on tank... -
Page 12: Jurisdiction
General Terms of Warranty The “goods” shall mean the goods described in the purchase agreement. “The customer” shall mean the original purchaser under the purchase agreement. “The Company” shall mean A. O. Smith India Water Heating Pvt. Ltd. The “Purchase Agreement” shall mean the General Terms and Conditions of Sale agreed upon by the customer and the Company as printed on the Invoice. -
Page 13: Warranty Card
Warranty Card Warranty Card (Customer Copy) (To be retained by the Customer) Unit Serial Number: Invoice Number: Dated: Customer's Name and Address: Model: Capacity: Dealer’s Stamp and Signature Warranty Card Warranty Card (Company Copy) (To be sent back to the Company) Unit Serial Number: Invoice Number: Dated:... -
Page 14: Service And Maintenance
Service and Maintenance For Service needs: Please contact our A. O. Smith Toll Free Number : 1.800.103.2468 SMS us : +91770.292.8887 Email us : aosmithcs@hotwater.com For grievances please contact : wecare@hotwater.com Registered Office A. O. Smith India Water Heating Private Limited Plot No. - Page 16 Manufactured by A. O. Smith India Water Heating Private Limited Plot No. 300, Phase - 2, KIADB Industrial Area, Harohalli, Kanakapura Taluk, Ramanagara District - 562 112, Karnataka, India. Toll Free: 1.800.103.2468 Website: www.aosmithindia.com...
