Technical specifications PRO-JECT HEAD BOX MK II

Power output
Headphone connection
THD (IMD)
Gain
Signal to noise
Frequency response
Headphone jack
Outboard power supply
Power consumption
Dimensions (H x W x D)
Weight without power supply

Potential incorrect use and fault conditions

No signal on one or both channels:
No connection between headphone and Head Box ore amplifier. This could be due
to a faulty plug, broken wire or solder joint or simply loose plug/socket connection.
Headphone does not work:
Headphone volume control is at minimum.
Amplifier Tape-Monitor circuit is not activated.

Service

Should you encounter a problem which you are not able to alleviate or identify despite the above information,
please contact your dealer for further advice. Only when the problem cannot be resolved there should the
unit be sent to the responsible distributor in your country.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use. Modification or change to any part of the product by unauthorized persons release the
manufacturer from any liability over and above the lawful rights of the customer.
PRO-JECT is a Registered Trademark of H. Lichtenegger.
This guide was produced by: ATR-Audio Trade GmbH
Copyright © 2005
Audio Tuning GmbH. All rights reserved.
330mW/30ohms, 60mW/300ohms
Min. 30ohms
0,005% (0,001%)
11dB
94dB ref. full output (112dB - A weighted ref. full output)
30Hz – 20kHz/-0,05dB (10Hz – 120kHz/-1dB)
3-pole ¼" (6,3mm ∅) phono jack
16V/200mA AC, suitable for your country's mains supply
16V/120mA AC
38 x 105 x 120mm
600g
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.
© Pro-Ject Audio · Pro-Ject Head Box · Revision 10.10.05/1.12.05
