Technical specifications

Power Requirements

All SnapStream servers are equipped with dual hot-swap power supplies that are both
redundant and load-balancing. A single unit may be replaced without a system power-down. They also
support auto detection of 100-240V and 50-60Hz power.
Below are the server configurations and their respective power consumption statistics.*
Storage Chassis Size
Level
3 TB 3U
6 TB 3U
9 TB 3U
12 TB 3U
18 TB 3U
24 TB 3U
27 TB 3U
36 TB 3U
Best Practices for power management
Minimal Configuration
Each system power supply unit plugged into an 'uninterrupted power supply' (UPS) or 'battery backup
unit' (BBU.) Protection provided for single system power supply unit failure and minor power outages
or failures.
Better Configuration
Each system power supply unit plugged into a separate UPS or BBU. Protection provided for single
system power supply unit failure, power outages, and single UPS/BBU failure.
Total Number Power Supply
of Drives
7 Dual 920 Watts
11 Dual 920 Watts
16 Dual 920 Watts
11 Dual 920 Watts
16 Dual 920 Watts
11 Dual 920 Watts
16 Dual 920 Watts
16 Dual 920 Watts
Idle Idle Load
Draw Draw Draw
Watts Amps Watts
116 .96 193
154 1.28 222
184 1.54 251
165 1.38 231
202 1.69 265
179 1.49 248
224 1.85 293
224 1.85 293
Load Power
Draw Off
Amps Draw
1.59 11 W
1.88 11 W
2.1 11 W
1.93 11 W
2.2 11 W
2.08 11 W
2.5 11 W
2.5 11 W
11
