Technical specifications Pro-Ject Phono Box MK II

THD, MM / MC
Gain, MM / MC
Input impedance, MM / MC
Noise floor, MM / MC
Output voltage typically, MM / MC 300mV at 1kHz - 3mV (MM Input) / 0,3mV (MC input)
Max. output
RIAA-equalisation curve accuracy
Outboard power supply
Power consumption
Dimensions (H x W x D)
Weight without power supply

Potential incorrect use and fault conditions

No signal on one or both channels:
No connection between player and phono amplifier ore amplifier. This could be due to a faulty plug,
broken wire or solder joint or simply loose plug/socket connection.
Strong hum:
No earth connection from cartridge or arm or arm cable to phono amplifier, or earth loop.
Output too quiet or too loud, or distorted:
MM / MC mode incorrectly set - input overloading or insufficiently amplified.

Service

Should you encounter a problem which you are not able to alleviate or identify despite the above information,
please contact your dealer for further advice. Only when the problem cannot be resolved there should the
unit be sent to the responsible distributor in your country.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use. Modification or change to any part of the product by unauthorized persons release the
manufacturer from any liability over and above the lawful rights of the customer.
PRO-JECT is a Registered Trademark of H. Lichtenegger.
This guide was produced by: ATR-Audio Trade GmbH
Copyright © 2005
Audio Tuning GmbH. All rights reserved.
< 0,01 / < 0,05%
40dB / 60dB
47kohms/120pF / 100ohms/120pF
86dB / 68dB (94dB / 75dB - A weighted)
9,5V (1kHz)
Max. 0,5dB/20Hz - 20kHz
16V/200mA AC, suitable for your country's mains supply
16V/30mA AC
38 x 105 x 120mm
570g
© Pro-Ject Audio · Pro-Ject Phono Box MK II · Revision 10.10.05/1.12.05
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.
