- Page 1 CONTINUOUS FLOW ICEMAKER WCC1401-A / WCF1411-A Series Service Manual Release Date: October 26, 2006 Publication Number: 630460324SER Revision Date: March 18, 2014 Revision: E Visit the Cornelius web site at www.cornelius.com for all your Literature needs.
-
Page 2: Contact Information
Commercial Warranty. Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage resulting from any of the following occurrences, including but not limited to, (1) other than normal and proper use and normal... -
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Instructions ..............1 Read and Follow ALL Safety Instructions . - Page 4 To Replace Bearing ............16 Electrical Checkout .
-
Page 5: Safety Instructions
Only trained and certified electrical, plumbing and refrigeration technicians should service this unit. ALL WIRING AND PLUMBING MUST CONFORM TO NATIONAL AND LOCAL CODES. FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT DAMAGE. © 2006-2014 Cornelius Inc. - 1 - Publication Number: 630460324SER... -
Page 6: Safety Precautions
NOTE: Many units incorporate the use of additional equipment such as icemakers. When any addition equipment is used you must check with the equipment manufacturer to determine the additional weight the counter will need to support to ensure a safe installation. Publication Number: 630460324SER - 2 - © 2006-2014 Cornelius Inc. -
Page 7: General Information
This section gives the Unit description, theory of operation, and design data for continuous flow icemaker series WCC1401-A. PECIFICATION HART Refrigerant Comp. GRMTR Circuit Models Description PH Wire Amps Amps Fuse Type WCC1401-A Ice Maker 208/230 12.2 1.2 (2) 2.0 (2) 404A © 2006-2014 Cornelius Inc. - 3 - Publication Number: 630460324SER... - Page 8 Continuous Flow Icemaker Service Manual Figure 1. Series WCC1401-A/WCF1411-A Dimension Drawing Publication Number: 630460324SER - 4 - © 2006-2014 Cornelius Inc.
-
Page 9: Electrical
Continuous Flow Icemaker Service Manual ELECTRICAL Figure 2. Schematic WCC1401-A/WCF1411-A © 2006-2014 Cornelius Inc. - 5 - Publication Number: 630460324SER... -
Page 10: Refrigeration Schematic
Continuous Flow Icemaker Service Manual REFRIGERATION SCHEMATIC Figure 3. WCC1401 - A Publication Number: 630460324SER - 6 - © 2006-2014 Cornelius Inc. - Page 11 Continuous Flow Icemaker Service Manual Figure 4. WCC2001QTR Refrigeration Diagram © 2006-2014 Cornelius Inc. - 7 - Publication Number: 630460324SER...
-
Page 12: Cleaning And Sanitizing
This is the maximum period of time between cleaning and sanitizing the icemaker. In addition to recommended monthly procedure, and if a more frequent cleaning and sanitizing pattern has not been established, unit must be cleaned and sanitized. Publication Number: 630460324SER - 8 - © 2006-2014 Cornelius Inc. -
Page 13: Semi-Annually
6. Check unit for abnormal noise. Tighten machine and cabinet screws if necessary. 7. Check white upper bearing on auger assembly. If bearings are less than 1/16” thick, replace. Figure 5. Upper Nut and Bearing Assembly © 2006-2014 Cornelius Inc. - 9 - Publication Number: 630460324SER... -
Page 14: Refrigeration System
Sensing bulb is located on top refrigerant line. WARNING: Very high discharge pressure is present in system. Quick disconnects on your gages will minimize Danger and loss of refrigerant. Comply with federal regulations for reclaiming refrigerant. Publication Number: 630460324SER - 10 - © 2006-2014 Cornelius Inc. -
Page 15: Water Level Control
1. Unplug Molex connector connecting switch to electrical box. 2. Remove the 2 screws anchoring the water level safety switch to the bottom of the water level control mounting bracket. © 2006-2014 Cornelius Inc. - 11 - Publication Number: 630460324SER... -
Page 16: Bin Control
The reaction time depends upon the amperage to which it is subjected. The overloads to each motor are connected in series; if either overload trips both gear motors and the liquid line solenoid are shut off. Publication Number: 630460324SER - 12 - © 2006-2014 Cornelius Inc. - Page 17 Continuous Flow Icemaker Service Manual © 2006-2014 Cornelius Inc. - 13 - Publication Number: 630460324SER...
-
Page 18: Motor Check
Remove the transmission from the unit. 4. When replacing the transmission, it may be necessary to rotate the auger back and forth to align the motor shaft and auger. Publication Number: 630460324SER - 14 - © 2006-2014 Cornelius Inc. -
Page 19: Auger And Extruding Head Removal
While holding the seals (down) in place slide the E–ring into the groove on the out- put shaft Figure 8. Shaft Seal 700 and 1000 © 2006-2014 Cornelius Inc. - 15 - Publication Number: 630460324SER... -
Page 20: Upper Nut And Bearing Assembly
#1 and #3. If none, wait for unit to cool down and try again. If still no continuity, the overload protector is defective and should be replaced. Figure 9. Overload Check Publication Number: 630460324SER - 16 - © 2006-2014 Cornelius Inc. -
Page 21: Compressor Check
4. Anti–freeze relay and associated circuit. See wiring diagrams. 5. Main service switch located on top of the control box. 6. Bin Control. 7. High pressure cut out (water cooled only). © 2006-2014 Cornelius Inc. - 17 - Publication Number: 630460324SER... -
Page 22: Guide To Good Ice
Continuous Flow Icemaker Service Manual GUIDE TO GOOD ICE Publication Number: 630460324SER - 18 - © 2006-2014 Cornelius Inc. - Page 23 Continuous Flow Icemaker Service Manual © 2006-2014 Cornelius Inc. - 19 - Publication Number: 630460324SER...
- Page 24 Continuous Flow Icemaker Service Manual Publication Number: 630460324SER - 20 - © 2006-2014 Cornelius Inc.
- Page 26 Cornelius Inc. www.cornelius.com...
