  • Page 1 Atrie WireSpan 3000/3000E MODEM User's Manual...
  • Page 2 WireSpan 3000/3000E USER'S MANUAL...
  • Page 3 ATRIE WireSpan 3000/3000E USER'S MANUAL (Version 3) ATRIE TECHNOLOGY INC. Floor,14 , Lane 609, Sec.5, Chung Hsin Rd., San Chung City, Taipei Hsien, Taiwan 241, R.O.C. TEL:+886-2-29995155 FAX:+886-2-29994960 Web:www.atrie.com.tw Mail:contact@mail.atrie.com.tw (C) Copyright 2001 ATRIE TECHNOLOGY INC.

  • Page 4: Table Of Contents

    TABLE OF CONTENT CHAPTER 1 INTRODUCTION O v e r v i e w ..........1 - 1 A p p l i c a t i o n s .

  • Page 5: Overview

    ("transceiver"), each connected by a two-wire CSA(Carrier Serving Area) compatible loop. WireSpan 3000 supports data rates of Nx64 Kbps up to 2.048 Mbps. The DTE interface supported are EIA RS-530/V.35/RS-449/X.21. DTE interface for data transmission support drop & insert functions.
  • Page 6 Loop2 Circuit 2.048Mbps T 1/E1 Interface T 1/E1 Interface RS-530/V.35 RS-530/V.35 RS-449/X.21 RS-449/X.21 DT E DT E Figure 1-1 WireSpan 3000 HT U-C HT U -R Loop1 T 1/E 1 1.544Mbps T 1/E 1 1.544Mbps Interface Interface T ransceiver T ransceiver...

  • Page 7: Application

    WireSpan 3000. Applications Voice Pair Gain Systems T1/E1 Extend High-Speed Digital Modems Personal Communication Systems (PCS) Wireless PBX...

  • Page 8: Package Contain

    This chapter describes how to install and connect your WireSpan 3000/3000E. Step-by-step instructions guide you through installing your WireSpan 3000/3000E. Package Contain Carefully unpacking your WireSpan 3000. The package should contain the following items: The WireSpan 3000. 2. One power cable.

  • Page 9: Led Indicators

    HDSL Termination Unit Figure 2-2 Front Panel 1. LED Indicators There are eight LEDs on the front panel of the WireSpan 3000/3000E . These LEDs display the real-time status of the WireSpan 3000/3000E. Table 2-1 lists the LEDs and describes their function.

  • Page 10: Rear Panel

    Select next right menu 3. LCD Display The front panel LCD display is a 2*16 alphanumerical display. It displays the status and configurations of the WireSpan 3000. Please refer to Chapter 3 for detail operation of the LCD display. Rear Panel Figure 2-3 shows the rear panel of the WireSpan 3000.
  • Page 11 T1/E1 T1/E1 T1/E1 HDSL Figure 2-4 rear panel WireSpan 3000E (AC POWER) Figure 2-5 shows the rear panel of the WireSpan 3000. FG DC-48V T1/E1 T1/E1 T1/E1 HDSL Figure 2-5 rear panel WireSpan 3000 (DC POWER) Figure 2-6 shows the rear panel of the WireSpan 3000E...

  • Page 12: Cabling Wirespan 3000

    7: Ground 8: Ground Figure 2-6 RJ-48 C for E1 Line Interface Cabling Your WireSpan 3000 This section describes how to connect your WireSpan 3000 to: (1) A personal computer (PC) or data terminal equipment (2) HDSL Line (3) E1 equipment...
  • Page 13 To Other HDSL To E1 interface To DTE To Console To AC Power 90 260 V Figure 2-9 Connecting WireSpan 3000 (AC POWER) To Other HDSL To E1 interface To DTE To Console To DC Power -72 V Figure 2-10 Connecting WireSpan 3000 (DC POWER)

  • Page 14: Cabling Wirespan 3000E

    Cabling Your WireSpan 3000E This section describes how to connect your WireSpan 3000E to: (1) Personal computer (PC) or data terminal equipment (2) HDSL Line (3) E1 equipment Instructions for installing each cable shown in Figure2-6 To Other HDSL To E1 interface To Console To AC Power 90 260 V...
  • Page 15 To Other HDSL To E1 interface To Console To DC Power -72 V Figure 2-12 Connecting WireSpan 3000E (DC POWER)

  • Page 16: The Front Panel Lcd Controller;

    CHAPTER 3 GETTING START There are two methods to control the WireSpan 3000/3000E ,one is using the front panel LCD controller; the other is using the console port on the rear panel. The Front Panel LCD Controller The front panel LCD controller consists of the LCD display and front panel switches.

  • Page 17: Status

    This category shows the Loop Status, E1 Status, Monitor and Rest. Loop Status : Displays the current HDSL loop status of the WireSpan 3000/3000E. The status includes: signal in sync/out of sync,CRC error, far end block error, input signal level, input DC offset level, far end signal attenuation, noise margin,LOS condition and LOST condition.

  • Page 18: Menu Tree Operation

    Note : you must choose ”E1 Terminal” mode when you use DTE Port and don't use E1 port in HTU-R side Profile The WireSpan 3000/3000E supports 5 user profiles to save for future use. Also provide 10 factory default profiles to load. Menu Tree Operation...

  • Page 19: Diagnostic/Profile/Status Menu

    DIAGNOSTIC MENU [MAIN] DIAGNOSTIC This menu provide self-test,helping user to find out the problem and fix it. PROFILE MENU [MAIN] PROFILE This menu provides the user 5 user profile to save or load,also provide the factary setting. STATUS MENU [MAIN] STATUS Press ENTER key to enter loop status Menu.
  • Page 20 <<HTU STATUS >> CERR Press ENTER to display the Loop1,Loop2 CRC ERROR count. CERR: CRC ERROR COUNT L1:*** CERR L2:*** Press EXIT to return to CERR STATUS screen,Press Right key to enter FEBE STATUS screen. FAR END BLOCK ERROR COUNT DISPLAY SCREEN <<HTU STATUS >>...
  • Page 21 <<DC OFFSET >> L1:***L2:***dB This screen shows the HDSL Loop1, Loop2 DC OFFSET level. Press Right key shows the FESA STATUS. FAR-END SIGNAL ATTENUATION DISPLAY << FESA >> L1:***L2:***dB FESA=Far-End Signal Attenuation This screen shows the HDSL Loop1, Loop2 FAR-END SIGNAL ATTENUATION.
  • Page 22 DTE STATUS MENU <STATUS> This screen displays WireSpan 3000's DTE interface signal status and timeslot status. Press ENTER to show the signal status. THE DTE CONTROL SIGNAL STATUS SCREEN 1:CTS_ DSR_ 1:RTS_ DTR_ This status screen shows the CTS,DSR,RTS,DTR status of the DTE interface.
  • Page 23 E1 LOCAL RECEIVING RLOS* LOF* AIS_ YEL_ RLOS = Receive Loss Signal LOF = Loss Frame AIS = Alarm Indication Signal YEL = Yellow There will be * mark shown beside each alarm if present. LOCAL LINE STATUS BPV:_ TSHORT:_ BPV = Bipolar Violation TSHORT = Transmit Short There will be * mark shown beside each alarm if present.
  • Page 24 LCV = Line Code Violation count FEBE = Far-End Block Error count PERFORMANCE MONITOR <STATUS> PERF MONITOR E1 OR HDSL PERFORMANCE MONITOR <<PERF>> HDSL The performance monitor shows the E1 and HDSL Receiving signal performance. Due to the size of the LCD display, the result will be shown on the CONSOLE port.
  • Page 25 15M ES-CRC: 15 MINUTES SEVERELY ERROR SECOND-CRC The second count of CRC error more than 30% in each second during last 15 minutes.Press ENTER key to show Loop1,Loop2 performance selecting screen. <<<<15M SES>>>> L1:* L2:* Select the desire Loop1 or Loop2. Press ENTER key to get the performance screen from console port.
  • Page 26 Select the desire Loop1 or Loop2 to get the performance screen from CONSOLE port. E1 PERFORMANCE MONITOR (15 MINUTES) <<<E1 PERF>>> 15M ES-CRC 15M ES-CRC:15 MINUTES ERROR SECOND-CRC E1 SEVERELY PERFORMANCE MONITOR (15 MINUTES) <<<E1 PERF>>> 15M SES-CRC 15M SES-CRC:15 MINUTES SEVERELY ERROR SECOND-E1 E1 PERFORMANCE MONITOR (24 HOURS) <<<E1 PERF>>>...

  • Page 27: Configure Menu

    <<CLS CNTR>> YES* Slect YES and press ENTER key will clear all the error counter. CONFIGURE MENU [ MAIN MENU ] CONFIGURE DTE CONFIGURE MENU (THIS MENU EFFECT ONLY IN WireSpan 3000 MODEL) <CONFIGURE> This Menu can activate, configure the DTE port. DTE PORT ACTIVATE <<SETUP DTE>>...
  • Page 28 <<<CLKO INV>>> NORM* INV* Select the Normal or Inverse output of clock signal. DATA OUTPUT POLARITY <<SETUP DTE>> DATO POLARITY This screen selects the polarity of data output. <<<DATO INV>>> NORM* INV* Select the Normal or Inverse output of data signal. DCD OPTION <<SETUP DTE>>...
  • Page 29 ON* OFF Select the desire option(ON or OFF) for DSR signal. CTS OPTION <<SETUP DTE>> OPTION Press ENTER key to select CTS option. <<<CTS>>> ON* OFF Select the desire option (ON or OFF) for CTS signal. DTE INTERFACE SELECT <<SETUP DTE>> INF TYPE There are EIA530 or V.35 for Interface selection.
  • Page 30 E1 INTERFACE SELECT <<E1 SETUP>> INTERFACE Select the desire Interface for E1. The WireSpan 3000 provide RJ45 with 120 Ohm or BNC connector with 75 Ohm. Press ENTER to select. Use the Left or Right key to select then press ENRER to confirm.
  • Page 31 <<<INTERFACE>>> 75 OHM COAXIAL <<<INTERFACE>>> DISABLE E1 HTU TYPE SELECT <<E1 SETUP>> HTU TYPE Use this screen to select central or remote. Two connecting modems must be set to one central and the other remote, otherwise it will not connect. Press ENTER key to select. Use the Left or Right key to select then press ENTER to confirm.
  • Page 32 IDLE CODE There are two idle codes for selection. Press ENTER to select. <<<E1 SETUP>>> Use Left or Right key to select "7F" or "FF" idle code. E1 LINE CODING SELECT <<E1 SETUP>> LINE CODING There are two methods of line coding. Press ENTER to select. <<<CODING>>>...
  • Page 33 <<<CLK SRC>>> <<<CLK SRC>>> INTERNAL <<<CLK SRC>>> KEYLOCK SETTING <<AUX>> SET KEYLOCK This screen allows user to lock the four front panel keys. You must key in password before activate, the keylock function. Use Left or Right key to select keylock ON/OFF. <<<KEYLOCK>>>...
  • Page 34 TIMESLOT MAPPING (WireSpan 3000 ONLY) <CONFIGURE> TS MAPPING The WireSpan 3000 provides drop & insert function. In this function , it allows user to asign every 64 kpps bandwidth to be used in DTE port. Please note that each HTU-C and HTU-R to be connected must be asigned in same Timeslot Mapping.
  • Page 35 <<SYS RST>> YES* NO Use Left or Right key to select YES then press ENTER. DIAGANOSTIC MENU <DIAGNOSTIC> TEST MODE Through the diagnostic, the user can separate and fix the communication problem. There are three loopback test. Detail test description will be found on Chapter 4. Local E1 and HDSL LOOP BACK <<TEST MODE>>...
  • Page 36 << TEST MODE >> DISABLE PROFILE MENU [MAIN] PROFILE There are ten preset profiles for user to load, and five user profiles can be saved by user for later load. LOCAL PROFILE < PROFILE > LOAD <<LOAD>> 3 * 4 Use Left or Right key to select profile and press ENTER to load.

  • Page 37: The Console Port Operation

    There are ten factary default for user to load. Use Left or Right key to select and ENTER to load. <<1:HTU-C>> CAS+CRC 120 <<2:HTU-R>> CAS+CRC 120 <<3:HTU-C>> CAS+CRC 75 <<4:HTU-R>> CAS+CRC 75 <<5:HTU-C>> CAS+CRC 120 <<6:HTU-C>> CRC4 <<7:HTU-C>> UNFRAME 120 <<8:HTU-R>>...
  • Page 38 polling status, etc. Table 3-1 lists and describes the function of each key. Keys Functions Exit to upper menu DOWN Enter menu or confirm your choice LEFT Select next left menu RIGHT Select next right menu ENTER Refresh console screen and exit to upper menu (RETURN) Table 3-1 the function of each key Table 3-4 lists and describes the parameter of the console port.
  • Page 39 Equipment HDSL HDSL Local HDSL Device Remote HDSL Device The data block will go through remote WireSpan 3000/3000E (HTU-R) and loop back at local HDSL end of the WireSpan 3000/3000E (HTU-C) to verify the remote circuit and the HDSL line.
  • Page 40 HTU-R and the HDSL loop. HDSL HDSL HTU-C HTU-R The data block will go through local WireSpan 3000/3000E (HTU-C) and loop back at remote HDSL end of the WireSpan 3000/3000E (HTU-R) to verify the local circuit and the HDSL line.
  • Page 41 APPENDIX A SPECIFICATION HDSL LOOP INTERFACE Line Rate: 1168Kbps +/- 32ppm Line Code: 2B1Q Line Type: unconditional twisted pair Line Impedance: 135 Ohm Transmit Line: 13.5 +/- 0.5dB Range: 3.7Km for 26AWG 4.5Km for 24AWG Bit Error Rate: 1x10E7,or Better Connect: Rj-48C NETWORK INTERFACE Line Rate: 2.048Mbps +/- 32ppm...
  • Page 42 PHYSICAL DIMENSIONS Physical dimensions: 257mm in W x 266mm in L x 60mm in H POWER REQUIREMENT Input Voltage: 90 ~ 260 VAC 47~63 HZ(AC POWER) -36 ~ -72 VDC (DC POWER) ENVIRONMENT Temperature: 0 ° ° Humidity: 0% ~ 95% non-condensing...

  • Page 43: Dte Interface

    APPENDIX B DTE INTERFACE V.24 V.35 EIA530 EIA449 X.21 V.24 V.35 EIA530 EIA449 X.21 (DB25) (M34F) (DB25) (DB37) (DB15) (DB25) (M34P) (DB25) (DB37) (DB15) SHIELD(1) SHIELD(A) SHIELD(1) SHIELD(1) SHIELD(1) DSRB(22) DSRB(29) RxDB(T) RxDB(16) RxDB(24) RB(11) DSRA(6) DSRA(11) RxDA(R) RxDA(3) RxDA(6) RA(4) CTSB(13) CTSB(27)
  • Page 44 DTE CABLE (M:Male F:Female): (1)SCSI(M) →V.24(F):1&7,2&3,4&5,6&20,8&24,15&17. (2)SCSI(M)→V.35(F):A&B,P&S,R&T,C&D,E&H,F&K,X&V, W&U,AA&Y,J&BB. (3)SCSI(M)→EIA530(F):1&7,3&16,2&14,12&15,9&17,4&19, 5&13,11&24,20&23,6&22,8&10,18&21,25. (4)SCSI(M)→EIA449(F):1&19,6&24,4&22,5&23,8&26,7&25, 9&27,17&35,12&30,11&29,13&31,10&14,18 (5)SCSI(M)→X.21(F):1&8,4&11,2&9,6&13,3&10,5&12 *CABLE:28AWG,Braid and foil shielding,500mm...
