  • Page 1 Atrie WireSpan 600/610 MODEM User's Manual...
  • Page 2 WireSpan 600 / 610 Fractional E1 Access Unit Installation and Operation manual...
  • Page 3 CONTENTS CHAPTER 1 Interduction………………………….. 1-1 CHAPTER 2 Installation and Setup……………….. CHAPTER 3 Operation……………………………. 3-1 CHAPTER 4 Troubleshooting & Diagnostics…….. APPENDIX A Interface Specification………………. A-1 MENU TREE ………………………………………. B-1...
  • Page 4 CHAPTER 1 Introduction 1.1 Overview WireSpan 600 is a cost-effective, single-port fractional E1 access unit. The fractional E1 service makes unused time slots on long-range E1 trunks available for other users. WireSpan 600 provides a synchronous data channel that supports user-selectable transmission rates.

  • Page 5: Installation And Setup

    DTE or DCE data port changeable cable WireSpan 610 is simple version with unframed mode Physical Description WireSpan 600 / 610 are designed for desktop installation. Installation procedures for the WireSpan 600 / 610 models and respective versions are provided in Chapter 2, Installation and Setup.

  • Page 6: Functional Description

    Figure 1-2. General View Connectors The power and interface connectors are located on the lateral panel of WireSpan 600 / 610. A description of the lateral panel can be found in interfaces and connectors. Functional Description WireSpan 600 / 610 has a synchronous user’s data port interface. The electrical interface is user-selectable.
  • Page 7 DCE mode. WireSpan 600/610 Figure 1-3 DCE Description DTE – WireSpan 600 sends the receive data accompanied by the receive clock to the user’s equipment connected to the data port, and accepts data from the equipment according to the equipment transmit clock.

  • Page 8: Operation

    The user can select the number of main link time slots used to carry the payload data. The timing of the receive path of the Wirespan 600 / 610 E1 link interface is always locked to the clock signal recovered from the received line signal.
  • Page 9 WireSpan 600 / 610 must provide the timing reference for the link. In this case, one WireSpan 600 / 610 must use the internal oscillator, and other must operate on the recovered clock signal.

  • Page 10: Technical Specifications

    E1-Mux. application. E1 Timing DTE/DCE Timing EIA-530 V.35 E1 M UX. Converte Converte DTE/DCE WireSpan 600 WireSpan 600 Figure 1-7 DTE/DCE timing mode 1.4 Technical Specifications E1 Link Interface Framing Unframed mode PCM31 without CRC-4...
  • Page 11 Connectors Balanced interface RJ-48 eight-pin connector Unbalanced interface Two BNC coaxial connectors Transmit timing Internal- ±30 ppm oscillator E1- Locked to the recovered E1 receive clock, tracking range ±130 ppm DTE/DCE-Locked to the recovered DTE or DCE receive clock, tracking range ±100 ppm Connector 50-pin, SCSI-type female User’s Data port...
  • Page 12 power indicator SYNC E1 sync Indicators loss indicator BPV alarm indicator AIS alarm indicator Mechanical Characteristics Use external power adapter Power Requirements Support voltage: 90-120 VAC±10%, 47 to 63 Hz 230 VAC±10%, 47 to 63 Hz Power consumption 5Watt Temperature 0 to 50°C Environmental Humidity...

  • Page 13: Troubleshooting & Diagnostics

    AC outlet capable of furnishing the nominal supply voltage (100-115 or 230 VAC, in accordance with your order). The ambient operating temperature of WireSpan 600 / 610 is 0 to 50°C at a relative humidity of up to 90%, non-condensing 2.3 Package Contents...

  • Page 14: Equipment Needed

    X.21 interface: the interface adapter cable ends in a 15-pin D-type connector The required cables are available from ATRIE, or can be prepared in accordance with the port connector wiring information given in Appendix A, Interface Specifications. The available cable and their respective uses are listed in Table 2-1 Table 2-1.
  • Page 15 WireSpan 600 / 610 frame. E1 Link Connections WireSpan 600 / 610 E1 link has an RJ-48C eight-pin connector for the balanced interface, and two BNC connectors for the unbalanced interface. Appendix A, E1 Balanced Port Connector provides the pin allocation for the RJ-48C connector.

  • Page 16: Connecting The Power

    1000 Ft / 26AWG in general case. Data Port Connections The Wirespan 600 / 610 user data port has a 50-pin SCSI-type female connector. Connect the DTE / DCE link cable to the SCSI connector after setting pin-out configuration corresponding to the interface in use.
  • Page 17 Figure 2-1. WireSpan 600 / 610 Top Panel View Table 2-2 Settings Identification Function Settings Factory of Setting Setting Main→ E1 SETUP Select E1 Frame PCM31 - CCS PCM31 → Framing operating mode without CRC4 PCM31+CRC - CCS with CRC4...
  • Page 18 Main→ E1 SETUP Selects the idle 7F – Symbol in HEX. Pass → Idle Code code transmission FF – Symbol in HEX. Pass –Pass through E1 Rx timeslot data to Tx. Main→ E1 SETUP Select E1 port HDB3 → Line Coding coding, frame HDB3 structure...
  • Page 19 INV – Invert data port receive clock or Main→ DTE/DCE transmit data SETUP→ Data Polarity After setting any configuration with WireSpan 600 /610, the internal NVRAM will save setting immediately. When occur power down-to–up process, the Wirespan 600 / 610 will recover setting automatically.
  • Page 20 The information presented in this chapter includes: Description of indicators and LCD screens. Operating procedures Refer to Chapter 4, Troubleshooting & Diagnostic and troubleshooting instructions. 3.2 Indicators Figure 3-1 and Figure 3-2 illustrates the top panel of WireSpan 600 / 610. Figure 3-1 WireSpan 600 panel...
  • Page 21 Figure 3-2 WireSpan 610 panel Table 3-1 lists the functions of the controls and indicators located on the top panel of the WireSpan 600 / 610. The index number in Table 3-1 correspond to the item numbers in Figure 3-1 and Figure 3-2.

  • Page 22: Menu Tree

    WireSpan 600 / 610 are designed for unattended operation. After settings are completed, WireSpan 600 / 610 operates automatically. Connect the AC power adapter to the mains outlet, the WireSpan 600 / 610 powered on automatically. Initially, WireSpan 600 / 610 performs a self-test.
  • Page 23 Main Menu E1-E1 PCM31 RJ48C V35T 1984K E1: First E1 indicates the operate mode. Other includes LL or DL When operates loopback function. E1: Second E1 indicates reference clock sources such as INT or DTE. PCM31: To indicate the E1 link framing type RJ48C: To indicate the E1 link interface type such as BNC.
  • Page 24 means TS 0 cannot be assigned by user. When framing is PCM30, the timeslot 0 and 16 are inhibited. When unframed mode, all timeslot can assigned by user. F: Inhibited timeslot (Framing Used ) *: user assign carry data timeslots 01: To indicate the cursor position timeslot number E1 Link port alarm status E1 STATUS...

  • Page 25: Digital Loopback

    CHAPTER 4 Troubleshooting & Diagnostics 4.1 General This chapter presents information related to the Wirespan 600 / 610 diagnostics functions. The information presented in this chapter include: User-controlled test functions Troubleshooting 4.2 User-Controlled Test Functions Loopback Function The user-controlled test functions are activated by means of the buttons and LCD screen.

  • Page 26: Local Loopback

    Local Loopback Pressing Loopback button on top panel of WireSpan 610 or find the function in Menu-tree of WireSpan 600. The local lopback returns the data sent by the local user’s equipment towards the local user’s equipment. The loopback is performed by connecting the data port transmit signal to the input of the data port receive path, within the data port interface of the local Wirespan 600 / 610.

  • Page 27: Troubleshooting

    Measures in the order given until the problem is corrected. If the problem cannot be corrected by carrying out the listed actions, have the Wirespan 600 / 610 check by the technical support personnel. Table 4-1 Troubleshooting Chart Trouble Symptoms...
  • Page 28 1. Defective Activate the local loopback. Check local Wirespan 600 / Wirespan 600 / that the local WireSpan 600 / 610 610 blinks SYN indicator is On. If indicator off, turn the local Wirespan 600 / 610 on with the local loopback activated.

  • Page 29: Interface Specifications

    APPENDIX A Interface Specifications A.1 E1 Balanced Port connector The E1 balanced port interface is terminated in an eight-pin RJ-48C connector, designated E1 LINK, and wired in accordance with Table A-1 Table A-1. E1 LINK Connector, Pin Allocation Function Transmit Data Out (tip) Transmit Data Out (ring) Not Connected Receive Data In (tip)
  • Page 30 TxC (A) TX CLK – A wire N / A Not Connected DCE_TxC (B) TX CLK from DCE – B wire DCE_TxC (A) TX CLK from DCE – A wire Test mode N / A Not Connected Data transfer request Request to send Remote loopbak Local loopbak...
  • Page 31 Adapter Cables for WireSpan 600 / 610 Data Port ATRIE offers adapter cables data equipment to the 50-pin SCSI-type connector of WireSpan 600 / 610 wiring and the pin allocations in the user side connectors are given in Table A-3 and Table A-4.
  • Page 32 DTR (A) N / A N / A RTS (B) RTS (A) N / A TxD (B) TxD (A) Tabel A-4. Wirespan 600 / 610 Channel Interface Adapter Cable – DTE Clock Mode Direction Designation V.35 EIA-530 RS-449 X.21 FGND...
  • Page 33 N / A N / A TxC (B) TxC (A) N / A N / A RxC (B) RxC (A) ID (3) ID (2) DTR (B) DTR (A) RTS (B) RTS (A) N / A N / A ID (1) ID (0) N / A N / A...
  • Page 34 RxD (B) RxD (A)
  • Page 35 WireSpan 600 WireSpan 600 MENU TREE Ver1.0 MU:1.0 ROM:1.0 Control Signals Control Signals E1-E1 PCM31 E1 STATUS CTS RTS DCD RJ48C V35T LOF YEL CRC <DIAGNOSTIC> <CONFIGURATION> <CONFIGURATION> <CONFIGURATION> <DEFAULT SETUP> LOOPBACK DTE/DCE SETUP E1/T1 SETUP TS MAPPING Load Default ? <<LOOPBACK>>...
