LG LY76 Series Owner's Manual
Hide thumbs
Also See for LY76 Series:
- Owner's manual (58 pages) ,
- Installation manual (40 pages) ,
- Installation manual (36 pages)
Related Manuals for LG LY76 Series
Summary of Contents for LG LY76 Series
- Page 1 OWNER’S MANUAL LED TV* *LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. LY75** LY76** www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS TROUBLESHOOTING LICENSES SPECIFICATIONS OPEN SOURCE SOFTWARE NOTICE IR CODES ASSEMBLING AND PREPARING Unpacking EXTERNAL CONTROL DEVICE Separate Purchase SETUP Parts and Button Using the Joystick Button RS-232C Setup Lifting and Moving the TV Type of Connector: Setting up the TV D-Sub 9-Pin Male - Attaching the Stand... -
Page 3: Licenses
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. -
Page 4: Assembling And Preparing
ASSEMBLING AND PREPARING NOTE Image shown may differ from your TV. Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. The available menus and options may differ from the input source or product model that you are using. -
Page 5: Separate Purchase
Separate Purchase Separate purchase items can be changed or modified for quality improvement without any notification. Contact your dealer to buy these items. These devices only work with certain models. LG Audio Device Magic Remote LED Clock AN-MR300 (Only LY75**) - Page 6 ASSEMBLING AND PREPARING NOTE Antenna Isolator Installation Guide - Use this to install TV in a place where there is a voltage difference between TV Set and GND of antenna signal. » If there is a voltage difference between TV Set and GND of antenna signal, the antenna contact might be heated and excessive heat might cause an accident.
-
Page 7: Parts And Button
ASSEMBLING AND PREPARING Parts and Button Screen Speakers Remote control sensor Power Indicator Joystick button (* This button is located below the TV screen.) NOTE You can set the power indicator light to on or off by selecting OPTION in the main menus. -
Page 8: Using The Joystick Button
ASSEMBLING AND PREPARING Using the Joystick Button You can simply operate the TV functions, pressing or moving the joystick button up, down, left or right. Basic Functions When the TV is turned off, place your finger on the joystick Power On button and press it once and release it. -
Page 9: Lifting And Moving The Tv
ASSEMBLING AND PREPARING Lifting and Moving the TV y When transporting a large TV, there should be at least 2 people. Please note the following advice to prevent the y When transporting the TV by hand, hold the TV from being scratched or damaged and for safe TV as shown in the following illustration. -
Page 10: Setting Up The Tv
ASSEMBLING AND PREPARING Setting up the TV Attaching the Stand * Image shown may differ from your TV. M4 x L14 (Except for 32LY76**, 32LY75**) M4 x L20 (Only 32LY76**, 32LY75**) A Stand Base CAUTION When attaching the stand to the TV, place B Stand Base the screen facing down on a cushioned table or flat surface to protect the screen... -
Page 11: Tidying Cables
ASSEMBLING AND PREPARING Tidying Cables * Image shown may differ from your TV. Gather and bind the cables with the cable Holder and the cable Managements. Fix the cable Managements firmly to the TV. Cable Holder Cable Management CAUTION Do not move the TV by holding the cable holders, as the cable holders may break, and injuries and damage to the TV may occur. -
Page 12: Mounting On A Table
ASSEMBLING AND PREPARING Mounting on a Table Securing the TV to a Wall (This feature is not available for all models.) Lift and tilt the TV into its upright position on a table. - Leave a 10 cm (minimum) space from the wall for proper ventilation. -
Page 13: Mounting On A Wall
When you attach the TV to other building wall, it may fall and result in severe injury. materials, please contact qualified personnel. Use an authorized LG wall mount and LG recommends that wall mounting be performed contact the local dealer or qualified by a qualified professional installer. -
Page 14: How To Use Dual Lock
ASSEMBLING AND PREPARING How to use Dual Lock™ NOTE Only 42LY76**, 42LY75** (Depending on model) Fix the set-top box to the TV and use it when you Wall Mount Spacers want to. After removing the protection paper from the Dual Lock, stick it to the TV and the set-top box as shown. -
Page 15: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS Antenna Connection Connect the TV to a wall antenna socket with an * Image shown may differ from your TV. RF cable (75 Ω). * Any separate cable is not provided. This section on MAKING CONNECTIONS mainly uses diagrams for the LY75** models. -
Page 16: Satellite Dish Connection
MAKING CONNECTIONS Satellite Dish Connection Euro Scart Connection /DVI IN (Only satellite models) Transmits the video and audio signals from an external device to the TV set. Connect the Connect the TV to a satellite dish to a satellite external device and the TV set with the euro scart socket with a satellite RF cable (75 Ω). -
Page 17: Hdmi Connection
MAKING CONNECTIONS HDMI Connection PCMCIA Card (Only LY76**) Transmits the digital video and audio signals from your PC to the TV. Connect the PC and the TV with the HDMI cable as shown. Choose any HDMI input port to connect. It does not matter which port you use. -
Page 18: Network Setup
MAKING CONNECTIONS Network Setup NOTE Wired network Connection It is recommended to use the TV with This TV can be connected to a Pro:Centric server the HDMI connection for the best image via the LAN port. After making the physical con- quality. -
Page 19: Speaker Output Setup
MAKING CONNECTIONS Audio Connection Speaker Output Setup You may use an optional external audio system Connect the external speaker to the SPEAKER instead of the built-in speaker. OUT jack on the TV. Digital Optical Audio Connection Transmits a digital audio signal from the TV to an external device. -
Page 20: Ci Module Connection
MAKING CONNECTIONS PCMCIA Card PCMCIA Card Headphone Connection CI module Connection Transmits the headphone signal from the TV to View the encrypted (pay) services in digital an external device. Connect the external device TV mode. This feature is not available in all and the TV with the headphone as shown. -
Page 21: Remote Control
REMOTE CONTROL REMOTE CONTROL This item is not included for all models. The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover. - Page 22 REMOTE CONTROL (Only LY76**) (POWER) Turns the TV on or off. ꕊ ENERGY SAVING Adjusts the brightness of the screen to reduce energy consumption. AV MODE Selects an AV mode. ENERGY AV MODE INPUT INPUT Changes the input source. SAVING TV/RAD Selects Radio, TV and DTV programme.
-
Page 23: Maintenance
MAINTENANCE MAINTENANCE Cleaning your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges. -
Page 24: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING The software version can be updated for improvement in performance.Customer needs to ensure the compatibility of customer’s equipment with LGE software. If needed, please consult with LGE and upload revised software version according to the guidance provided by LGE. Problem Solution Cannot control the... -
Page 25: Specifications
SPECIFICATIONS SPECIFICATIONS Product specifications may be changed without prior notice due to upgrade of product functions. 32LY76** 39LY76** 42LY76** MODELS 32LY760H-ZA 39LY760H-ZA 42LY760H-ZA Dimensions With stand (mm) 732 x 481 x 207 885 x 567 x 218 961 x 612 x 218 (W x H x D) Without stand (mm) 732 x 431 x 55.5... - Page 26 SPECIFICATIONS CI Module Size 100.0 mm x 55.0 mm x 5.0 mm (W x H x D) Operating Temperature 0 °C to 40 °C Operating Humidity Less than 80 % Environment condition Storage Temperature -20 °C to 60 °C Storage Humidity Less than 85 % Satellite Digital TV Digital TV...
- Page 27 SPECIFICATIONS (Only LY75**) Wireless LAN module(TWFM-B006D) specification Standard IEEE802.11a/b/g/n 2400 to 2483.5 MHz Frequency Range 5150 to 5250 MHz 5725 to 5850 MHz (for Non EU) 802.11a: 11 dBm 802.11b: 14 dBm Output Power 802.11g: 10.5 dBm (Max.) 802.11n - 2.4GHz: 11 dBm 802.11n - 5GHz: 12.5 dBm Because band channel used by the country could be different, the user can not change or adjust the operating frequency and this product is set for the regional frequency table.
-
Page 28: Ir Codes
IR CODES IR CODES *This feature is not available for all models. Code (Hexa) Function Note Remote control Button (Power On/Off) (POWER) ENERGY SAVING Remote control Button AV MODE Remote control Button INPUT Remote control Button RATIO Remote control Button INPUT Remote control Button TV/RAD... -
Page 29: External Control Device Setup
EXTERNAL CONTROL DEVICE SETUP EXTERNAL CONTROL DEVICE SETUP RS-232C Setup RS-232C Configurations Connect the RS-232C (serial port) input jack to an external control device (such as a computer or an A/V 7-Wire Configurations control system) to control the product’s functions exter- (Standard RS-232C cable) nally. -
Page 30: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP Communication Parameters y Baud rate: 9600 bps (UART) y Stop bit: 1 bit y Data length: 8 bits y Communication code: ASCII code y Parity : None y Use a crossed (reverse) cable. Command Reference List (Depending on Model) DATA DATA... -
Page 31: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV.(j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the set ID to choose desired monitor ID number in option menu. Adjustment range is 1 to 99. - Page 32 EXTERNAL CONTROL DEVICE SETUP 01. Power (Command: k a) 04. Volume Mute (Command: k e) ▶ To control Power On/Off of the set. ▶ To control volume mute on/off. You can also adjust mute using the MUTE button Transmission[k][a][ ][Set ID][ ][Data][Cr] on remote control.
- Page 33 EXTERNAL CONTROL DEVICE SETUP 13. Balance (Command: k t) 09. Tint (Command: k j) ▶ To adjust the screen tint. ▶ To adjust balance. You can also adjust tint in the PICTURE menu. You can also adjust balance in the AUDIO menu. Transmission [k][j][ ][Set ID][ ][Data][Cr] Transmission [k][t][ ][Set ID][ ][Data][Cr] Data Red : 00 to Green : 64...
- Page 34 EXTERNAL CONTROL DEVICE SETUP 18. Tune Command (Command: m a) 16. Auto Configure(Command: j u) (Only RGB support model) ▶ Select channel to following physical number. ▶ To adjust picture position and minimize image shaking automatically. It works only in RGB (PC) mode. Transmission [m][a][ ][Set ID][ ][Data0][ ][Data1][ ][Data2][Cr] Transmission [j][u][ ][Set ID][ ][Data][Cr] Data00 : High channel data...
- Page 35 EXTERNAL CONTROL DEVICE SETUP 22. Input select (Command: x b) (Main Picture Input) ▶ To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data Structure External Input Input Number External Input Data Analogue Component HDMI Input Number Data Input1 Input2...
- Page 36 Record the model number and serial number of the TV. Refer to the label on the back cover and quote this information to your dealer when requiring any service. MODEL SERIAL...
