Zio WLB5254AIP/X11 User Manual

Wireless broadband router
Hide thumbs
Table of Contents

Advertisement

Quick Links

X11 Wireless Broadband Router
User manual
WLB5254AIP/X11
Wireless Broadband Router
Page 1 of 69

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLB5254AIP/X11 and is the answer not in the manual?

Questions and answers

Related Manuals for Zio WLB5254AIP/X11

Summary of Contents for Zio WLB5254AIP/X11

  • Page 1 X11 Wireless Broadband Router User manual WLB5254AIP/X11 Wireless Broadband Router Page 1 of 69...

  • Page 2: Table Of Contents

    X11 Wireless Broadband Router User manual Table of Contents Quick Installation Guide …………………………………………………………….4 1 Connecting the Wireless Broadband Router ..………………………………………..5 2 Setting Up PC to Access the Router’s Web Based Management…………… 5 3 Checking PC’s IP and Connection with the Router…………………………………12 4 Accessing the Web-Based Configuration Utility…………………………………….13 5 Quick Configuration for Wireless Router ………………………………………………14 6 Checking the Connection to the Internet ……………………………………………..17...
  • Page 3 X11 Wireless Broadband Router User manual 6.6.6 WDS Set ................54 6.7 Routing ..................55 6.8 NAT ..................55 6.8.1 DMZ Host Setup ..............56 6.8.2 FTP Private Port...............56 6.8.3 Virtual Server Setup............57 6.8.4 Port Tiger ...............58 6.9 Fire Wall.................59 6.9.1 MAC Filtering ..............59 6.9.2 Access Control ..............60 6.9.3 URL Filtering ..............62 6.10 DDNS...................62...

  • Page 4: Quick Installation Guide

    X11 Wireless Broadband Router User manual Wireless Broadband Router Quick Installation Guide Page 4 of 69...

  • Page 5: Connecting The Wireless Broadband Router

    X11 Wireless Broadband Router User manual This Quick Installation Guide only provides you some basic instructions. For more detailed information, please refer to the User Manual. ○ Connecting the Wireless Broadband Router Prior to connecting the hardware, make sure to power off your ethernet device, Cable/ADSL modem and X11 Wireless Broadband Router.
  • Page 6 X11 Wireless Broadband Router User manual (or TCP/IP) address automatically from the Router by the steps below. Windows 98/Me 1. Go to Start Settings Control Panel. 2. Find and double-click the Network icon. The Network dialog box appears. 3. Click the Configuration label and ensure that you have network card. 4.
  • Page 7 X11 Wireless Broadband Router User manual Figure 3 4. Highlight Internet Protocol (TCP/IP), and then press Properties button Figure 4 5. Choose Obtain an IP address automatically and Obtain DNS server address automatically, and then press OK to close the Internet Protocol (TCP/IP) Properties window Page 7 of 69...
  • Page 8 X11 Wireless Broadband Router User manual Figure 5 6. Press OK to close the Local Area Connection Properties window Figure 6 Windows XP Please follow the steps below to setup your computer: 1. Go to Start Settings Control Panel 2. Click Network and Internet Connections Page 8 of 69...
  • Page 9 X11 Wireless Broadband Router User manual Figure 7 3. Click Network Connections Figure 8 Page 9 of 69...
  • Page 10 X11 Wireless Broadband Router User manual 4. Highlight the icon Local Area Connection, right click your mouse, Click Properties Figure 9 5. Highlight Internet Protocol (TCP/IP), and then press Properties button Figure 10 6. Choose Obtain an IP address automatically and Obtain DNS server address automatically, and then press OK to close the Internet Protocol (TCP/IP) Properties window Page 10 of 69...
  • Page 11 X11 Wireless Broadband Router User manual Figure 11 7. Press OK to close the Local Area Connection Properties window Figure 12 Page 11 of 69...

  • Page 12: Checking Pc's Ip And Connection With The Router

    X11 Wireless Broadband Router User manual ○ 3 Checking PC’s IP and Connection with the Router After configuring the TCP/IP protocol, use the ping command to verify if the computer can communicate with the Router. To execute the ping command, open the DOS window and ping the IP address of the Wireless Broadband Router at the DOS prompt: To execute ping command, open the DOS window by clicking on Start ->...

  • Page 13: Accessing The Web-Based Configuration Utility

    X11 Wireless Broadband Router User manual Verify your computer's network settings are correct and check the cable connection between the router and the computer. ○ 4 Accessing the Web-Based Configuration Utility Step 1 Launch the Web browser and type http://192.168.10.1 in the Address field and click Enter.

  • Page 14: Quick Configuration For Wireless Router

    X11 Wireless Broadband Router User manual ○ 5 Quick Configuration for Wireless Router After login, the Wireless Broadband Router’s web-based management is accessible. Step 1 Click the WAN Setup page link to configure the WAN interface. Figure 16 Step 2. Select the Internet connection type The WAN Setup page configures the Internet connection of the Wireless Broadband Router.
  • Page 15 X11 Wireless Broadband Router User manual Figure 17 PPPoE Figure 18 Static IP Page 15 of 69...
  • Page 16 X11 Wireless Broadband Router User manual Figure 19 Step 3.After selecting the proper WAN connection setting, click Apply to save And enable these settings with the Router. Step 4.Setting the wireless ith the default values, the router (Access Point) can be easily associated by a wireless client. For For more detailed security concern, you should modify the basic Wireless LAN security settings.

  • Page 17: Checking The Connection To The Internet

    X11 Wireless Broadband Router User manual Wireless Router’s Default Values LAN IP 192.168.10.1 Subnet Mask 255.255.255.0 DHCP Server Enable IP Lease Range 192.168.10.2 ~ 192.168.10.128 User Name admin Password SSID default Channel Authentication Disabled Encryption Radio Band 802.11B/G ○ 6 Checking the Connection to the Internet To check the connection to the Internet, you can open the Web browser and go to a website.

  • Page 18: User's Manual

    X11 Wireless Broadband Router User manual Wireless Broadband Router User’s Manual Page 18 of 69...

  • Page 19: Chapter 1 Introduction

    User manual Chapter 1 Introduction 1.1 Welcome Congratulations on purchasing ZIO X11 Wireless Broadband Router. ZIO X11 is a cost-effective IP Sharing Router that enables multiple users to share the Internet through an ADSL or cable modem. Simply configure your Internet connection settings in the Wireless Broadband Router and plug your PC to the LAN port and you're ready to share files and access the Internet.

  • Page 20: Chapter 2 Designing Your Wireless Network

    X11 Wireless Broadband Router User manual Chapter 2 Designing Your Wireless Network 2.1 System Requirements Cable/ADSL modem and an Internet access account for Internet connection One computer with 10/100Base-T Ethernet card and TCP/IP protocol installed for initial setup Internet Explorer 5.0 or higher for Web configuration 802.11g or 802.11b compliant wireless adapters (for wireless connection) Figure 1 below shows a typical setup for a Local Area Network (LAN).

  • Page 21: Chapter 3 Getting To Know The Wireless-G Broadband Router

    X11 Wireless Broadband Router User manual Chapter 3 Getting to Know the Wireless-G Broadband Router The following sections describe the physical characteristics of your router. 3.1 Back Panel The following illustration shows the X11 back panel: Figure 2 back panel Power: The receptacle where you plug in the power adapter.

  • Page 22: Led Description

    X11 Wireless Broadband Router User manual 3.2 LED Description The following illustration shows the X11 front panel: Figure 3 front panel Number Light Status Description Power This indicator lights when the Wireless Router is receiving power; otherwise, it is off. Status The LED will be dark for a few seconds when the system is started.

  • Page 23: Chapter 4 Hardware Connection

    X11 Wireless Broadband Router User manual Chapter 4 hardware connection Begin by finding a good place to set up your wireless broadband. Some things to consider: Keep the access point as central in your work area as possible. Signal strength and speed fall off with distance. Higher is often better.

  • Page 24: Chapter 5 Configuring Local Pc To Access The Wireless Router

    X11 Wireless Broadband Router User manual Chapter 5 Configuring Local PC to Access the Wireless Router You can manage the Wireless Broadband Router through the Web browser-based configuration utility. To configure the device via Web browser, at least one properly configured computer must be connected to the device via Ethernet or wireless network.
  • Page 25 X11 Wireless Broadband Router User manual Figure 4 Step 2: Double click the icon Network and Dial-up Connections Step 3: Highlight the icon Local Area Connection, right click your mouse, Click Properties Figure 5 Step 4: Highlight Internet Protocol (TCP/IP), then press Properties button Page 25 of 69...
  • Page 26 X11 Wireless Broadband Router User manual Figure 6 Step 5: Choose Obtain an IP address automatically and Obtain DNS Server Address automatically, and then press OK to close the Internet Protocol (TCP/IP) Properties window. Figure 7 Page 26 of 69...

  • Page 27: Windows Xp

    X11 Wireless Broadband Router User manual Step 6: Press OK to close the Local Area Connection Properties window Figure 8 5.1.3 Windows XP Please follow the steps below to setup your computer: Step 1: Go to Start Settings Control Panel Step 2: Click Network and Internet Connections Figure 9 Page 27 of 69...
  • Page 28 X11 Wireless Broadband Router User manual Step 3: Click Network Connections Figure 10 Step 4: Highlight the icon Local Area Connection, right click your mouse, Click Properties Figure 11 Step 5: Highlight Internet Protocol (TCP/IP), then press Properties button Page 28 of 69...
  • Page 29 X11 Wireless Broadband Router User manual Figure 12 Step 6: Choose Obtain an IP address automatically and Obtain DNS Server address automatically, and then press OK to close the Internet Protocol (TCP/IP) Properties window Figure 13 Page 29 of 69...

  • Page 30: Additional Settings For Wireless Client

    X11 Wireless Broadband Router User manual Step 7: Press OK to close the Local Area Connection Properties window Figure 14 5.2 Additional Settings for Wireless Client If you chose to access the router via a wireless client, also verify the following: Step 1: Make sure your PC is equipped with 802.11g or 802.11b wireless adapter and has appropriate WLAN card driver/utility and TCP/IP installed.

  • Page 31: Checking Pc's Ip And Connection With The Router

    X11 Wireless Broadband Router User manual 5.3 Checking PC’s IP and Connection with the Router After configuring the TCP/IP protocol, use the ping command to verify if the computer can communicate with the Router. To execute the ping command, open the DOS window and PING the IP address of the Wireless Broadband Router at the DOS prompt: For Windows 98/Me: Start ->...
  • Page 32 X11 Wireless Broadband Router User manual Figure 16 Verify your computer's network settings are correct and check the cable connection between the router and the computer. Page 32 of 69...

  • Page 33: Chapter 6 Web Configuration

    X11 Wireless Broadband Router User manual Chapter 6 Web Configuration 6.1 Logging In In order to make the whole network operate successfully, it is necessary to configure the Wireless Router through your computer has a WEB browser installed. Please follow up the steps listed below. Step 1: Start your Web browser and type http://192.168.10.1 in the Address field.

  • Page 34: Quick Setup Wizard

    X11 Wireless Broadband Router User manual options to configure the system. In the right navigation screen is the summary of system status for viewing the configurations. You can usually get context sensitive help by clicking on the Help link at the top right of the page. Figure 18 To apply any settings you’ve altered on any page, click the Save button.
  • Page 35 X11 Wireless Broadband Router User manual then click on “Start”. Figure 19 Step 2: Select your Internet connection type and then input the configurations needed to connect to your Internet Service Provider (ISP) Figure 20 For Dynamic IP Address Choose DHCP if your ISP will automatically give you an IP address. And then click on “Next”.
  • Page 36 X11 Wireless Broadband Router User manual Internet. Your ISP should provide all the information required in this section. Enter the User Name and Password provided by your ISP for the PPPoE connection then click on “Next”. Figure 21 For Static IP Select Static IP if your ISP has given you a specific IP address for you to use.

  • Page 37: Status

    X11 Wireless Broadband Router User manual Click “Apply” to save these settings with the Router. The System will apply the new settings and start rebooting right away. Figure 23 After reboot, the Wireless Router will enable these settings with the Router. 6.3 Status 6.3.1 System Status This page shows most of the basic configuration parameters of the Router.
  • Page 38 X11 Wireless Broadband Router User manual Figure 24 WAN Status: This section shows the WAN interface parameters of the wireless router. This includes information such as: Connection type (DHCP, PPPoE or Static IP), The MAC address of LAN interface, IP/Subnet Mask, Default Gateway, Primary DNS, Backup DNS.
  • Page 39 X11 Wireless Broadband Router User manual Figure 25 To terminate the connection, click on the “Disconnect” button. Figure 26 DHCP: In DHCP mode, press "Disconnect" button to release IP address and press "Connect" button to renew IP address. Figure 27 Page 39 of 69...
  • Page 40 X11 Wireless Broadband Router User manual LAN Status: This section shows the LAN interface parameters of the wireless router. This includes information such as: The MAC address of LAN interface, IP/Subnet Mask, DHCP Server (whether the DHCP Server is Enables or disables, and display address pool). Figure 28 Wireless Status: This section shows the WLAN interface parameters of the wireless router.

  • Page 41: Statistics

    X11 Wireless Broadband Router User manual 6.3.2 Statistics The statistics tab main contains several of the following items for you to monitor network traffic between interface of types external (WAN) and internal (LAN and WLAN). And display System Run Time. Figure 31 System Run Time: Display System Run Time.

  • Page 42: Pppoe

    X11 Wireless Broadband Router User manual Figure 32 Physical Address Clone: Your ISP may require a particular MAC address in order for you to connect to the Internet. This MAC address is the PC’s MAC address that your ISP had originally connected your Internet connection to.
  • Page 43 X11 Wireless Broadband Router User manual Figure 33 PPPoE Account: Enter the User Name provided by your ISP for the PPPoE connection PPPoE Password: Enter the Password provided by your ISP for the PPPoE connection Physical Address Clone: Your ISP may require a particular MAC address in order for you to connect to the Internet.

  • Page 44: Static Ip

    X11 Wireless Broadband Router User manual automatically disconnects the PPPoE session after the WAN connection has been idle for the amount of time you specified in the timeout box. If your Internet account is billed based on the amount of time of your Internet connection, you probably want to enable this option and enter an idle time value best suitable for your network.

  • Page 45: Lan Setup

    X11 Wireless Broadband Router User manual Physical Address Clone: Your ISP may require a particular MAC address in order for you to connect to the Internet. This MAC address is the PC’s MAC address that your ISP had originally connected your Internet connection to.

  • Page 46: Dhcp Info

    X11 Wireless Broadband Router User manual Click “Apply” when you have finished the configuration above. And the wireless router will be automatically restarted if you change the LAN IP address. If you change the private IP address and apply the changes, the PC from which you configure the router will lose the communication to the router.

  • Page 47: Advanced Wireless Settings

    X11 Wireless Broadband Router User manual Figure 37 Radio Band: The default setting is mixed mode [802.11B/G]. If you do not know or have both 11g and 11b devices in your network, then keep the default in mixed mode. From the drop-down manual, you can select 802.11G if you have only 11G card.

  • Page 48: Wireless Security

    X11 Wireless Broadband Router User manual Figure 38 Beacon Interval: This value indicates the frequency interval of the beacon. A beacon is a packet broadcast by the wireless router to keep the network synchronized. A beacon includes the wireless LAN service area, a time stamp, Delivery Traffic Indicator Maps, and the Traffic Indicator Message (TIM).
  • Page 49 X11 Wireless Broadband Router User manual 6.6.3.1 None Transmit data without encryption and authentication. This is the default option. Figure 39 Click “Apply” when you have selected the “None”. If you select none, any data will be transmitted without Encryption and any station can access the wireless router.
  • Page 50 X11 Wireless Broadband Router User manual Open-System: No authentication is used. But uses WEP encrypt data packets. Share-keys: Authentication is a process in which the AP validates whether the wireless client is qualified to access the AP’s service. You must enable WEP function and define your WEP keys.
  • Page 51 X11 Wireless Broadband Router User manual Figure 41 TKIP: Temporal Key Integrity Protocol (TKIP) utilizes a stronger encryption algorithm and includes Message Integrity Code (MIC) to provide protection against hackers. AES: Advanced Encryption System (AES) utilizes a symmetric 128-Bit block data encryption. It’s the strongest encryption currently available. WPA Pass Phrase: The WPA Pass Phrase is used to authenticate and encrypt data transmitted in the wireless network.
  • Page 52 X11 Wireless Broadband Router User manual Figure 42 AES: Advanced Encryption System (AES) utilizes a symmetric 128-Bit block data encryption. It’s the strongest encryption currently available. WPA Pass Phrase: The WPA Pass Phrase is used to authenticate and encrypt data transmitted in the wireless network. The input format is in character style and key size should be in the range between 8 and 63 characters.

  • Page 53: Wireless Mac Filter

    X11 Wireless Broadband Router User manual Figure 43 Click “Apply” at the bottom of the screen to save the above configurations. 6.6.4 Wireless MAC Filter This Wireless router has the capability to control the wireless client access based on the MAC address of the wireless client. The user has the flexibility to customize your own control policy based on these options: Figure 44 Enable Wireless Access Control: To enable Wireless MAC Filter, click the...

  • Page 54: Association Table

    X11 Wireless Broadband Router User manual MAC: Enter the MAC Address of a station. Description: Enter the Comment of station. Click "Add”. Then this wireless station will be added into the” Current Access Control List" below. Figure 45 If you want to remove some MAC address from the "Current Access Control List ", select the MAC addresses you want to remove in the list and then click "Delete ".

  • Page 55: Routing

    X11 Wireless Broadband Router User manual Figure 47 6.7 Routing If the Router is connected to more than one network, it may be necessary to set up a static route between them. A static route is a pre-determined pathway that network information must travel to reach a specific host or network.

  • Page 56: Dmz Host Setup

    X11 Wireless Broadband Router User manual protection from hacker attacks and has the flexibility to allow you to map Private IP Addresses to Public IP Addresses for key services such as Websites and FTP. 6.8.1 DMZ Host Setup If you have a local client PC that cannot run an Internet application (e.g. Games) properly from behind the NAT firewall, then you can open the client up to unrestricted two-way Internet access by defining a DMZ Host.

  • Page 57: Virtual Server Setup

    X11 Wireless Broadband Router User manual Check port number and enter the number and then press the "Apply" button to setup Private FTP port. The default Value is 1025. 6.8.3 Virtual Server Setup Use the Virtual Server function when you want different servers/clients in your LAN to handle different service/Internet application type (e.g.

  • Page 58: Port Trigger

    X11 Wireless Broadband Router User manual The diagram below demonstrates one of the ways you can use the Virtual Server function. Use the Virtual Server when you want the FTP server located in your private LAN to be accessible to Internet users. The configuration below means that any request coming form the Internet to access your web server will be translated to your LAN’s FTP server (192.168.10.6).

  • Page 59: Fire Wall

    X11 Wireless Broadband Router User manual Figure 54 Rule Name: You can enter whatever you want. It's just a string. Trigger Protocol: Chose TCP/UDP type for the packet you want to trigger. If the rule existed in predefined virtual server rule, you can choose the rule. Trigger Port: Enter the port number (The value's range is 1 to 65535) from which the packet will be on WAN.

  • Page 60: Access Control

    X11 Wireless Broadband Router User manual Figure 56 Enable MAC Filtering: To enable MAC Filtering, click the check box. The default is “disable”. You can choose a default operation for your factual security or management consideration: Defined items in MAC list are DENIED to access internet, others are PERMIT Defined items in MAC list are PERMIT to access internet, others are DENIED...
  • Page 61 X11 Wireless Broadband Router User manual Figure 58 Enable Access Control: To filter the outgoing packets for security or management consideration by IP Address, either permitting or blocking access, Enable Access Control is checked. You can choose a default operation for your factual security or management consideration: The Undefined items beside the Rule list are PERMIT to access internet DENIED to access internet.

  • Page 62: Url Filtering

    X11 Wireless Broadband Router User manual 6.9.3 URL Filtering URL (Uniform Resource Locator – e.g. an address in the form of http://www.abcde.com or http://www.example.com) filter rules allow you to prevent users on your network from accessing particular websites by their URL. There are no pre-defined URL filter rules;...

  • Page 63: Misc

    X11 Wireless Broadband Router User manual Figure 62 User ID/Password/Host Name: Enter your registered domain name and your username and password for this service. Information: The status of the DDNS service connection is displayed here. To see the latest DDNS status, click Refresh button. 6.11 MISC 6.11.1 Login ID &...

  • Page 64: Remote Mgmt

    X11 Wireless Broadband Router User manual 6.11.2 Remote Mgmt This feature allows you to manage the Router from a remote location, via the Internet. To enable this feature, check the “Management Port” checkbox, and click the Apply button. Figure 64 Management Port: Enter the port number.

  • Page 65: Firmware Upgrade

    X11 Wireless Broadband Router User manual Restore the Router’s configuration to its factory default settings. Restore Factory Defaults. To clear all of the Router’s settings and reset them to its factory defaults. Click the Restore Default button. Router will restart automatically. Restart System Click "Restart System"...

  • Page 66: Appendix Ⅰ: Troubleshooting

    X11 Wireless Broadband Router User manual Appendix Ⅰ: Troubleshooting 1. I cannot access the Web-based Configuration Utility from the Ethernet computer used to configure the router. Check that the LAN LED is on. If the LED is not on, verify that the cable for the LAN connection is firmly connected.

  • Page 67: Cannot Access The Internet

    X11 Wireless Broadband Router User manual light should be solid; the WAN light should be blinking. If you use your computer, the corresponding LAN port light should be blinking too. If not, please check whether the cables work or not. Repeat the steps in WAN Setup Connect with Internet through DSL Modem.

  • Page 68: Fcc Compliance Statement

    X11 Wireless Broadband Router User manual FCC Compliance Statement CAUTION: Any changes or modifications in construction of this device which are not expressly approved the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 69: Appendix Ⅱ: Specification

    X11 Wireless Broadband Router User manual Appendix Ⅱ: Specification LAN - IEEE802.3, IEEE802.3u, IEEE802.3x Standard Wireless –2.4GHz to 2.462GHz, IEEE802.11b, 11g WLAN WAN 1 – 10/100Mbps TP Type (Auto MDI-X) Port LAN 4 – 10/100Mbps N-way Switch TP Type (Auto MDI-X) Flash Rom –...
