Page 1 Wi-Fi Personal Bridge 150 Wireless Portable AP Router User Manual HNW150APBR www.hamletcom.com...
Page 2: Table Of Contents
Wi-Fi Personal Bridge 150 User Manual Table of Contents 1 Introduction 8 Features ..........................8 Device Requirements ......................8 Using this Document ......................8 Notational conventions ....................8 Typographical conventions ..................9 Special messages ......................
Page 3 Wi-Fi Personal Bridge 150 User Manual Internet/WAN access is the Static IP ................57 Internet/WAN access is the PPPoE client ............... 58 7 Getting Started with the Web pages 59 Accessing the Web pages ....................59 ...
Page 4 Wi-Fi Personal Bridge 150 User Manual Access Control ......................100 Allow Listed ......................100 Deny Listed ......................102 WDS settings ......................... 103 Configure WDS (Wireless Distribution System) only ..........104 Configure AP (Access Point) + WDS (Wireless Distribution System) ....108 ...
Page 5 Wi-Fi Personal Bridge 150 User Manual IP filtering for UDP with specified IP ................162 IP filtering for both TCP and UDP with specified IP ............. 164 14 MAC Filtering 166 MAC filtering for specified MAC Address ..............167 15 ...
Page 6 Wi-Fi Personal Bridge 150 User Manual Configuring Ethernet PCs ..................... 202 Before you begin ...................... 202 Windows® XP PCs ....................202 Windows 2000 PCs ....................202 Windows Me PCs ....................203 Windows 95, 98 PCs ....................203 ...
Page 7 Hamlet assumes no liability resulting from errors or omissions in this document, or from the use of the information contained herein. Hamlet reserves the right to make changes or revisions in the product design or the product manual without reservation and without obligation...
Page 8: Introduction
Wi-Fi Personal Bridge 150 User Manual Introduction Congratulations on becoming the owner of the Wireless Gateway. You will now be able to access the Internet using your high-speed xDSL/Cable modem connection. This User Guide will show you how to connect your Wireless Gateway, and how to customize its configuration to get the most out of your new product.
Page 9: Typographical Conventions
Wi-Fi Personal Bridge 150 User Manual For brevity, the Wireless Gateway is referred to as “the device”. • The term LAN refers to a group of Ethernet-connected computers at one site. • Typographical conventions Italic text is used for items you select from menus and drop-down lists and the names of •...
Page 10: Getting To Know The Device
Wi-Fi Personal Bridge 150 User Manual Getting to know the device Computer / System requirements Pentium 200MHZ processor or above • Windows 98SE, Windows Me, Windows 2000, Windows XP, Windows Vista and Windows 7 • 64MB of RAM or above •...
Page 11: Rear And Left Panel And Bottom Side
Wi-Fi Personal Bridge 150 User Manual Blink: Valid Ethernet packet being transferred WLAN green On: WLAN link established and active Blink: Valid Wireless packet being transferred green Off: WPS link isn’t established and active Blink: Valid WPS packet being transferred green On: LAN link established and active Off: No LAN link...
Page 12 Wi-Fi Personal Bridge 150 User Manual Label Function DC 5V Connects to the supplied power adaptor Connects the device via LAN Ethernet to a Connects the device via WAN Ethernet to xDSL / Cable Modem Press this button for at least 3 full seconds and the WPS LED will flash to start WPS.
Page 13: Computer Configurations Under Different Os, To Obtain Ip Address Automatically
Wi-Fi Personal Bridge 150 User Manual Computer configurations under different OS, to obtain IP address automatically Before starting the 802.11n Pocket AP configuration, please kindly configure the PC computer as below, to have automatic IP address / DNS Server. For Windows 98SE / ME / 2000 / XP 1.
Page 14 Wi-Fi Personal Bridge 150 User Manual 3. Double click on "Internet Protocol (TCP/IP)". 4. Check "Obtain an IP address automatically" and "Obtain DNS server address automatically" then click on "OK" to continue. 5. Click "Show icon in notification area when connected" (see screen image in 3. above) then Click on "OK"...
Page 15: For Windows Vista-32/64
Wi-Fi Personal Bridge 150 User Manual For Windows Vista-32/64 1. Click on “Start” -> “Control Panel” -> “View network status and tasks”. 2. In the Manage network connections, click on “Manage network connections” to continue.
Page 16 Wi-Fi Personal Bridge 150 User Manual 3. Single RIGHT click on "Local Area connection", then click "Properties". 4. The screen will display the information "User Account Control" and click "Continue" to continue. 5. Double click on "Internet Protocol Version 4 (TCP/IPv4)".
Page 17 Wi-Fi Personal Bridge 150 User Manual 6. Check "Obtain an IP address automatically" and "Obtain DNS server address automatically" then click on "OK" to continue.
Page 18: For Windows 7-32/64
Wi-Fi Personal Bridge 150 User Manual For Windows 7-32/64 1. Click on “Start” -> “Control Panel” (in Category View) -> “View network status and tasks”. 2. In the Control Panel Home, click on “Change adapter settings” to continue.
Page 19 Wi-Fi Personal Bridge 150 User Manual 3. Single RIGHT click on “Local Area Connection”, then click “Properties”. 4. Double click on "Internet Protocol Version 4 (TCP/IPv4)".
Page 20 Wi-Fi Personal Bridge 150 User Manual 5. Check "Obtain an IP address automatically" and "Obtain DNS server address automatically" then click on "OK" to continue.
Page 21: Connecting Your Device
Wi-Fi Personal Bridge 150 User Manual Connecting your device This chapter provides basic instructions for connecting the Wireless Gateway to a computer or LAN and to the Internet. In addition to configuring the device, you need to configure the Internet properties of your computer(s).
Page 22: Client Mode (Wan Interface Is Wlan Interface Through Wlan Router, Xdsl Or Cable Modem To Internet)
Wi-Fi Personal Bridge 150 User Manual 1. Switch the switch to Router Mode 2. Connect the Ethernet cable to WAN Port Connect the RJ45 Ethernet cable from your xDSL/Cable Modem's Ethernet port to 802.11n Pocket AP 's WAN Port. 3. Connect the Ethernet cable to LAN Port Connect the supplied RJ45 Ethernet cable from your PC's Ethernet port to any of the 802.11n Pocket AP Router's LAN Port.
Page 23: Wifi-Ap Mode (Wan Interface Is Wan, Lan Port Or Wlan Interface Through Wlan Router, Xdsl Or Cable Modem To Internet)
Wi-Fi Personal Bridge 150 User Manual WiFi-AP Mode (WAN interface is WAN, LAN Port or WLAN interface through WLAN Router, xDSL or Cable modem to Internet): In this mode, the device acts as an AP for xDSL or cable connection. (In this mode, the WAN Port acts as a second LAN port) 1.
Page 24: Wifi-Ap Mode (Wan Interface Is Wan, Lan Port Or Wlan Interface Through Wlan Router, Xdsl Or Cable Modem To Internet)
Wi-Fi Personal Bridge 150 User Manual WiFi-AP Mode (WAN interface is WAN, LAN Port or WLAN interface through WLAN Router, xDSL or Cable modem to Internet): In this mode, the device acts as an AP for xDSL or cable connection. (In this mode, the WAN Port acts as a second LAN port) 1.
Page 25: Utility Cd Execution
Windows Explorer, Select your CD drive and double click “autorun.exe”. 3. To configure the device, please click “Advanced Configuration”. 4. Please enter the Login User Name: admin and Login Password: hamlet and then click on OK button.
Page 26 Wi-Fi Personal Bridge 150 User Manual 5. Click on Quick Setup menu. 6. Select the WAN Access Type DHCP Client, Static IP, PPPoE, PPTP or L2TP and enter related parameters that your ISP (Internet Services Provider) or Network Administrator provided and then click on Next>>...
Page 27 Wi-Fi Personal Bridge 150 User Manual Examples 6-1. DHCP Client Select DHCP Client Mode from WAN Access Type drop-down list Click on Next>> button 6-2. PPPoE Select PPPoE Mode from WAN Access Type drop-down list Enter Username and Password offered by the ISP Click on Next>>...
Page 28 Wi-Fi Personal Bridge 150 User Manual 6-3. Static IP Select Static IP Mode from WAN Access Type drop-down list Config IP Address, Subnet mask, Default Gateway and DNS Server offered by ISP (Internet Services Provider) or Network Administrator Click on Next>> button 7.
Page 29 Wi-Fi Personal Bridge 150 User Manual 9. Choose the Encryption type if necessary, as None – No Encryption / 64 Bit Encryption / 128 Bit Encryption / Wi-Fi Protected Access (AES-CCMP) / Wi-Fi Protected Access2 (AES-CCMP) and WPA2 Mixed Mode. For example, you choose None. 10.
Page 30: Advanced Configuration With Client Mode
Windows Explorer, Select your CD drive and double click “autorun.exe”. 3. To configure the device, please click “Advanced Configuration”. 4. Please enter the Login User Name: admin and Login Password: hamlet and then click on OK button.
Page 31 Wi-Fi Personal Bridge 150 User Manual 5. Click on Quick Setup menu. 6. Select the WAN Access Type DHCP Client, Static IP, PPPoE, PPTP or L2TP and enter related parameters that your ISP (Internet Services Provider) or Network Administrator provided and then click on Next>>...
Page 32 Wi-Fi Personal Bridge 150 User Manual Examples 6-1. DHCP Client Select DHCP Client Mode from WAN Access Type drop-down list Click on Next>> button 6-2. PPPoE Select PPPoE Mode from WAN Access Type drop-down list Enter Username and Password offered by the ISP Click on Next>>...
Page 33 Wi-Fi Personal Bridge 150 User Manual 6-3. Static IP Select Static IP Mode from WAN Access Type drop-down list Config IP Address, Subnet mask, Default Gateway and DNS Server offered by ISP (Internet Services Provider) or Network Administrator Click on Next>> button 7.
Page 34 Wi-Fi Personal Bridge 150 User Manual 9. Click on Next>> button 10. Choose the Encryption type if necessary, as None – No Encryption / 64 Bit Encryption / 128 Bit Encryption / Wi-Fi Protected Access (AES-CCMP) / Wi-Fi Protected Access2 (AES-CCMP) and WPA2 Mixed Mode.
Page 35 Wi-Fi Personal Bridge 150 User Manual 13. Click on " Exit " to exit this program. 14. Now, the 802.11n Pocket AP has been configured completed, and suitable for Internet Connections.
Page 36: Advanced Configuration With Wifi-Ap Mode 1
Windows Explorer, Select your CD drive and double click “autorun.exe”. 4. To configure the device, please click “Advanced Configuration”. 5. Please enter the Login User Name: admin and Login Password: hamlet and then click on OK button.
Page 37 Wi-Fi Personal Bridge 150 User Manual 6. Click on Quick Setup menu. 7. Select Client from Mode drop-down list 8. Click on Next>> button 9. Choose the Encryption type if necessary, as None – No Encryption / 64 Bit Encryption / 128 Bit Encryption / Wi-Fi Protected Access (AES-CCMP) / Wi-Fi Protected Access2 (AES-CCMP) and WPA2 Mixed Mode.
Page 38 Wi-Fi Personal Bridge 150 User Manual 10. Click on Finished button 11. Change setting successfully! Please wait for a moment while rebooting ... 12. Click on Site Survey...
Page 39 Wi-Fi Personal Bridge 150 User Manual 13. Click on Site Survey button 14. Select the SSID of the AP that Hamlet_Mini_AP is going to connect to. 15. Click on Next>> button 16. Choose the Encryption type if necessary, as None – No Encryption / 64 Bit Encryption / 128 Bit Encryption / Wi-Fi Protected Access (AES-CCMP) / Wi-Fi Protected Access2 (AES-CCMP) and WPA2 Mixed Mode.
Page 40 Wi-Fi Personal Bridge 150 User Manual 18. Please wait… 19. Connect successfully! The device is booting. Do not turn off or reboot the Device during this time. Please wait 65 seconds ... 20. Click on " Exit " to exit this program. 21.
Page 41: Advanced Configuration With Wifi-Ap Mode 2 - Universal Repeater Mode (Acting As Ap And Client Simultaneouly)
Windows Explorer, Select your CD drive and double click “autorun.exe”. 4. To configure the device, please click “Advanced Configuration”. 5. Please enter the Login User Name: admin and Login Password: hamlet and then click on OK button.
Page 42 Wi-Fi Personal Bridge 150 User Manual 6. Click on Wireless -> Basic Settings menu. 7. Select Client from Mode drop-down list 8. Check on Enable Universal Repeater Mode (Acting as AP and client simultaneouly) ratio 9. Enter the SSID in SSID of Extended Interface field 10.
Page 43 Wi-Fi Personal Bridge 150 User Manual 11. Click on Reboot Later button 12. Click on Wireless -> Site Survey menu. 13. Click on Site Survey button...
Page 44 Wi-Fi Personal Bridge 150 User Manual 14. Select the SSID of the AP that Hamlet_Mini_AP is going to connect to. 15. Click on Next>> button 16. Choose the Encryption type if necessary, as None – No Encryption / 64 Bit Encryption / 128 Bit Encryption / Wi-Fi Protected Access (AES-CCMP) / Wi-Fi Protected Access2 (AES-CCMP) and WPA2 Mixed Mode.
Page 45 Wi-Fi Personal Bridge 150 User Manual 19. Connect successfully! The device is booting. Do not turn off or reboot the Device during this time. Please wait 65 seconds ... 20. Click on " Exit " to exit this program. 21. Now, the 802.11n Pocket AP has been configured completed, and suitable for Wireless and Internet Connections.
Page 46: Advanced Configuration With Wifi-Ap Mode 3 - Wds
Windows Explorer, Select your CD drive and double click “autorun.exe”. 4. To configure the device, please click “Advanced Configuration”. 5. Please enter the Login User Name: admin and Login Password: hamlet and then click on OK button.
Page 47 Wi-Fi Personal Bridge 150 User Manual 6. Click on Wireless -> Basic Settings menu. 7. Select WDS from Mode drop-down list 8. Select Channel Width 9. Select Control Sideband 10. Select Channel Number 11. Click on Apply Changes button...
Page 48 Wi-Fi Personal Bridge 150 User Manual 12. Click on Reboot Later button 13. Click on Wireless -> WDS settings menu. 14. Check on the option Enable WDS. 15. Enter the MAC Address of peer AP 16. Enter the Comment 17. If you need to configure the security, please click on Set Security button to configure in detail. 18.
Page 49 Wi-Fi Personal Bridge 150 User Manual 19. Click on Reboot Now button 20. Change setting successfully! Do not turn off or reboot the Device during this time. Please wait 20 seconds ... 21. Click on " Exit " to exit this program. 22.
Page 50: Advanced Configuration With Wifi-Ap Mode 3 - Wds + Ap
Windows Explorer, Select your CD drive and double click “autorun.exe”. 4. To configure the device, please click “Advanced Configuration”. 5. Please enter the Login User Name: admin and Login Password: hamlet and then click on OK button.
Page 51 Wi-Fi Personal Bridge 150 User Manual 6. Click on Wireless -> Basic Settings menu. 7. Select AP+WDS from Mode drop-down list 8. Select Channel Width 9. Select Control Sideband 10. Select Channel Number 11. Click on Apply Changes button...
Page 52 Wi-Fi Personal Bridge 150 User Manual 12. Click on Reboot Later button 13. Click on Wireless -> WDS settings menu. 14. Check on the option Enable WDS. 15. Enter the MAC Address of peer AP 16. Enter the Comment 17. If you need to configure the security, please click on Set Security button to configure in detail. 18.
Page 53 Wi-Fi Personal Bridge 150 User Manual 19. Click on Reboot Now button 20. Change setting successfully! Do not turn off or reboot the Device during this time. Please wait 20 seconds ... 21. Click on " Exit " to exit this program. 22.
Page 54: Wireless Connection (Router Mode Only)
Wi-Fi Personal Bridge 150 User Manual Wireless Connection (Router Mode Only) For easy installation it is saved to keep the settings. You can later change the wireless settings via the wireless configuration menu. (see user manual on the CD – Chapter 9). 1.
Page 55 Wi-Fi Personal Bridge 150 User Manual 3. If the wireless network isn’t encrypted, click on "Connect Anyway" to connect. 4. If the wireless network is encrypted, enter the network key that belongs to your authentication type and key. You can later change this network key via the wireless configuration menu. (see user manual on the CD –...
Page 56: What The Internet/Wan Access Of Your Own Network Now Is
Wi-Fi Personal Bridge 150 User Manual What the Internet/WAN access of your own Network now is Now you could check what the Internet/WAN access of your network is to know how to configure the WAN port of Wireless Gateway. Please follow steps below to check what the Internet/WAN access if your own Network is DHCP Client, Static IP or PPPoE Client.
Page 57: Internet/Wan Access Is The Dhcp Client
Wi-Fi Personal Bridge 150 User Manual Internet/WAN access is the DHCP client If you cannot see any Broadband Adapter in the Network Connections, your Internet/WAN access is DHCP Client or Static IP. 1. Click Local Area Connection in LAN or High-Speed Internet and you could see string Assigned by DHCP in Details.
Page 58: Internet/Wan Access Is The Pppoe Client
Wi-Fi Personal Bridge 150 User Manual Default gateway: 192.168.10.100 Preferred DNS server: 192.168.10.100 Alternate DNS Server: If you have it, please also write it down. Internet/WAN access is the PPPoE client If you can see any Broadband Adapter in the Network Connections, your Internet/WAN access is PPPoE Client.
Page 59: Getting Started With The Web Pages
Wi-Fi Personal Bridge 150 User Manual Getting Started with the Web pages The Wireless Gateway includes a series of Web pages that provide an interface to the software installed on the device. It enables you to configure the device settings to meet the needs of your network.
Page 60 1. Enter your user name and password. The first time you log into the program, use these defaults: User Name: admin Password: hamlet You can change the password at any time or you can configure your device so that you do not need to enter a password. See Password. Note 2.
Page 61: Testing Your Setup
Wi-Fi Personal Bridge 150 User Manual Testing your Setup Once you have connected your hardware and configured your PCs, any computer on your LAN should be able to use the DSL /Cable connection to access the Internet. To test the connection, turn on the device, wait for 30 seconds and then verify that the LEDs are illuminated as follows: Table 1.
Page 62 Wi-Fi Personal Bridge 150 User Manual Option Default Setting Explanation/Instructions LAN Port Assigned static IP address: This is the IP address of the LAN port on the device. IP Address 10.0.0.2 The LAN port connects the device to your Ethernet network.
Page 63: Quick Setup (This Function May Vary Depending On Router, Client Or Wifi-Ap Mode)
Wi-Fi Personal Bridge 150 User Manual Quick Setup (This function may vary depending on Router, Client or WiFi-AP mode) The Quick Setup page displays useful information about the setup of your device, including: details of the device’s Internet access settings •...
Page 64: Operation Mode Setup
Wi-Fi Personal Bridge 150 User Manual Operation Mode Setup You can setup different modes to LAN and WLAN interface for NAT function. Gateway In this mode, the device is supposed to connect to internet via ADSL/Cable Modem. The NAT is enabled and PCs in four LAN ports share the same IP to ISP through WAN port.
Page 65: Wireless Isp
Wi-Fi Personal Bridge 150 User Manual Wireless ISP In this mode, all ethernet ports are bridged together and the wireless client will connect to ISP access point. The NAT is enabled and PCs in ethernet ports share the same IP to ISP through wireless LAN.
Page 66: Wan Interface Setup
Wi-Fi Personal Bridge 150 User Manual WAN Interface Setup This page is used to configure the parameters for Internet network which connects to the WAN port of your Access Point. Here you may change the access method to static IP, DHCP, PPPoE, PPTP or L2TP by click the item value of WAN Access type.
Page 67: Dhcp Client
Wi-Fi Personal Bridge 150 User Manual DHCP Client In this mode, the device is supposed to connect to internet via ADSL/Cable Modem. The NAT is enabled and PCs in four LAN ports share the same IP to ISP through WAN port. The connection type can be setup in WAN page by using static IP.
Page 68: Pppoe
Wi-Fi Personal Bridge 150 User Manual PPPoE In this mode, the device is supposed to connect to internet via ADSL/Cable Modem. The NAT is enabled and PCs in four LAN ports share the same IP to ISP through WAN port. The connection type can be setup in WAN page by using static IP.
Page 69: Pptp
Wi-Fi Personal Bridge 150 User Manual PPTP In this mode, the device is supposed to connect to internet via ADSL/Cable Modem. The NAT is enabled and PCs in four LAN ports share the same IP to ISP through WAN port. The connection type can be setup in WAN page by using static IP.
Page 70: L2Tp
Wi-Fi Personal Bridge 150 User Manual L2TP In this mode, the device is supposed to connect to internet via ADSL/Cable Modem. The NAT is enabled and PCs in four LAN ports share the same IP to ISP through WAN port. The connection type can be setup in WAN page by using static IP.
Page 71: Wireless Basic Setup
Wi-Fi Personal Bridge 150 User Manual Wireless Basic Setup This page is used to configure the parameters for wireless LAN clients which may connect to your Access Point.
Page 72: Ap (Access Point)
Wi-Fi Personal Bridge 150 User Manual AP (Access Point) Access Point is used to configure the parameters for wireless LAN clients who may connect to your Access Point. 1. From the Band drop-down list, select a Band. 2. From the Mode drop-down list, select AP setting. 3.
Page 73: Client
Wi-Fi Personal Bridge 150 User Manual Client This page is used to configure the parameters for wireless LAN clients which may connect to your Access Point. 1. From the Band drop-down list, select a Band. 2. From the Mode drop-down list, select Client setting. 3.
Page 74: Wds (Wireless Distribution System)
Wi-Fi Personal Bridge 150 User Manual WDS (Wireless Distribution System) WDS stands for Wireless Distribution System. It enables the access points (APs) to be connected wirelessly. Integrated Access Device can also provide you services of WDS. Integrated Access Device that supports WDS does not support security systems like WEP, WPA or WPA-Enterprise on a WDS Note network.
Page 75 Wi-Fi Personal Bridge 150 User Manual function that changes channels based on network conditions, be sure to disable this feature. If your main WDS station is also your network’s router, make sure it’s set up to distribute IP addresses in the network.
Page 76: Wds (Wireless Distribution System) Only
Wi-Fi Personal Bridge 150 User Manual WDS (Wireless Distribution System) only 1. From the Band drop-down list, select a Band. 2. From the Mode drop-down list, select WDS setting. 3. From the Channel Width drop-down list, select a Channel Width. 4.
Page 77: Ap (Access Point) + Wds (Wireless Distribution System)
Wi-Fi Personal Bridge 150 User Manual AP (Access Point) + WDS (Wireless Distribution System) Access Point is used to configure the parameters for wireless LAN clients which may connect to your Access Point. 1. From the Band drop-down list, select a Band. 2.
Page 78: Wireless Security Setup
Wi-Fi Personal Bridge 150 User Manual Wireless Security Setup This page allows you setup the wireless security. Turn on WEP or WPA by using Encryption Keys could prevent any unauthorized access to your wireless network. You can protect your wireless data from potential eavesdroppers by encrypting wireless data transmissions.
Page 79 Wi-Fi Personal Bridge 150 User Manual If you want to use WPA (AES) - Wi-Fi Protected Access (AES) HEX (64 characters) encryption, • follow the instructions in Configuring WPA2 (AES) HEX (64 characters) security. If you want to use WPA2 (AES) - Wi-Fi Protected Access 2 (AES) Passphrase encryption, follow •...
Page 80: Configuring Wep 64Bit Ascii (5 Characters) Security
Wi-Fi Personal Bridge 150 User Manual Configuring WEP 64bit ASCII (5 characters) security The example set in this section is for 64bit encryption. 1. From the Encryption drop-down list, select WEP setting. 2. From the Key Length drop-down list, select 64-bit setting. 3.
Page 81: Configuring Wep 64Bit Hex (10 Characters) Security
Wi-Fi Personal Bridge 150 User Manual Configuring WEP 64bit Hex (10 characters) security The example set in this section is for 64bit encryption. 1. From the Encryption drop-down list, select WEP setting. 2. From the Key Length drop-down list, select 64-bit setting. 3.
Page 82: Configuring Wep 128Bit Ascii (13 Characters) Security
Wi-Fi Personal Bridge 150 User Manual Configuring WEP 128bit ASCII (13 characters) security The example set in this section is for 128bit encryption. 1. From the Encryption drop-down list, select WEP setting. 2. From the Key Length drop-down list, select 128-bit setting. 3.
Page 83: Configuring Wep 128Bit Hex (26 Characters) Security
Wi-Fi Personal Bridge 150 User Manual Configuring WEP 128bit Hex (26 characters) security The example set in this section is for 128bit encryption. 1. From the Encryption drop-down list, select WEP setting. 2. From the Key Length drop-down list, select 128-bit setting. 3.
Page 84 Wi-Fi Personal Bridge 150 User Manual Configuring WPA (AES) Passphrase security The example set in this section is for WPA (AES) Passphrase encryption. 1. From the Encryption drop-down list, select WPA (AES) setting. 2. From the Pre-Shared Key Format drop-down list, select Passphrase setting. 3.
Page 85: Configuring Wpa (Aes) Hex (64 Characters) Security
Wi-Fi Personal Bridge 150 User Manual Configuring WPA (AES) HEX (64 characters) security The example set in this section is for WPA (AES) HEX (64 characters) encryption. 1. From the Encryption drop-down list, select WPA (AES) setting. 2. From the Pre-Shared Key Format drop-down list, select HEX (64 characters) setting. 3.
Page 86 Wi-Fi Personal Bridge 150 User Manual Configuring WPA2 (AES) Passphrase security The example set in this section is for WPA2 (AES) Passphrase encryption. 1. From the Encryption drop-down list, select WPA2 (AES) setting. 2. From the Pre-Shared Key Format drop-down list, select Passphrase setting. 3.
Page 87: Configuring Wpa2 (Aes) Hex (64 Characters) Security
Wi-Fi Personal Bridge 150 User Manual Configuring WPA2 (AES) HEX (64 characters) security The example set in this section is for WPA2 (AES) HEX (64 characters) encryption. 1. From the Encryption drop-down list, select WPA2 (AES) setting. 2. From the Pre-Shared Key Format drop-down list, select HEX (64 characters) setting. 3.
Page 88: Configuring Wpa2 (Mixed) Passphrase Security
Wi-Fi Personal Bridge 150 User Manual Configuring WPA2 (Mixed) Passphrase security The example set in this section is for WPA2 (Mixed) Passphrase encryption. The WPA2 (Mixed) Passphrase encryption supports both WPA (AES) and WPA2 (AES). 1. From the Encryption drop-down list, select WPA2 (Mixed) setting. 2.
Page 89: Configuring Wpa2 (Mixed) Hex (64 Characters) Security
Wi-Fi Personal Bridge 150 User Manual Configuring WPA2 (Mixed) HEX (64 characters) security The example set in this section is for WPA2 (Mixed) HEX (64 characters) encryption. The WPA2 (Mixed) HEX (64 characters) encryption supports both WPA (AES) and WPA2 (AES). 1.
Page 90: Wireless Network
Wi-Fi Personal Bridge 150 User Manual Wireless Network This chapter assumes that you have already set up your Wireless PCs and installed a compatible Wireless card on your device. See Configuring Wireless PCs. Basic Settings The Wireless Network page allows you to configure the Wireless features of your device. To access the Wireless Network Basic Settings page: From the left-hand Wireless menu, click on Basic Settings.
Page 91 Wi-Fi Personal Bridge 150 User Manual Network Type Configure the Network Type to Infrastructure or Ad hoc. SSID Specify the network name. Each Wireless LAN network uses a unique Network Name to identify the network. This name is called the Service Set Identifier (SSID). When you set up your wireless adapter, you specify the SSID.
Page 92: Advanced Settings
Wi-Fi Personal Bridge 150 User Manual Advanced Settings These settings are only for more technically advanced users who have a sufficient knowledge about wireless LAN. These settings should not be changed unless you know what effect the changes will have on your Access Point. To access the Wireless Network Advanced Settings page: From the left-hand Wireless menu, click on Advanced Settings.
Page 93: Security
Wi-Fi Personal Bridge 150 User Manual Short GI Disable or Enable Short GI WLAN Partition Disable or Enable WLAN Partition STBC Disable or Enable STBC 20/40MHz Disable or Enable 20/40MHz Coexist Coexist RF Output Power TX Power measurement. Security This page allows you setup the wireless security. Turn on WEP or WPA by using Encryption Keys could prevent any unauthorized access to your wireless network.
Page 94 Wi-Fi Personal Bridge 150 User Manual WPA Cipher Configure the WPA Cipher Suite to AES Suite Field Description WPA2 Cipher Configure the WPA2 Cipher Suite to AES Suite Pre-Shared Key Configure the Pre-Shared Key Format to Passphrase or HEX (64 characters) Format Pre-Shared Key Type the Pre-Shared Key...
Page 95: Wep + Encryption Key
Wi-Fi Personal Bridge 150 User Manual WEP + Encryption Key WEP aims to provide security by encrypting data over radio waves so that it is protected as it is transmitted from one end point to another. However, it has been found that WEP is not as secure as once believed.
Page 96: Wep + Use 802.1X Authentication
Wi-Fi Personal Bridge 150 User Manual WEP + Use 802.1x Authentication WEP aims to provide security by encrypting data over radio waves so that it is protected as it is transmitted from one end point to another. However, it has been found that WEP is not as secure as once believed.
Page 97: Wpa/Wpa2/Wpa2 Mixed + Personal (Pre-Shared Key)
Wi-Fi Personal Bridge 150 User Manual WPA/WPA2/WPA2 Mixed + Personal (Pre-Shared Key) Wi-Fi Protected Access (WPA and WPA2) is a class of systems to secure wireless (Wi-Fi) computer networks. WPA is designed to work with all wireless network interface cards, but not necessarily with first generation wireless access points.
Page 98: Wpa/Wpa2/Wpa2 Mixed + Enterprise (Radius)
Wi-Fi Personal Bridge 150 User Manual 8. Click on Apply Changes button to confirm and return. 9. Change setting successfully! Click on Reboot Now button to confirm. WPA/WPA2/WPA2 Mixed + Enterprise (RADIUS) Wi-Fi Protected Access (WPA and WPA2) is a class of systems to secure wireless (Wi-Fi) computer networks.
Page 99 Wi-Fi Personal Bridge 150 User Manual 5. Check the option of TKIP and/or AES in WPA/WPA2 Cipher Suite if your Encryption is WPA2 Mixed: 6. Enter the Port, IP Address and Password of RADIUS Server: 7. Change setting successfully! Click on Reboot Now button to confirm.
Page 100: Access Control
Wi-Fi Personal Bridge 150 User Manual Access Control For security reason, using MAC ACL's (MAC Address Access List) creates another level of difficulty to hacking a network. A MAC ACL is created and distributed to AP so that only authorized NIC's can connect to the network.
Page 101 Wi-Fi Personal Bridge 150 User Manual 5. Change setting successfully! Click on Reboot Now button to confirm. 6. The MAC Address that you created has been added in the Current Access Control List.
Page 102: Deny Listed
Wi-Fi Personal Bridge 150 User Manual Deny Listed When 'Deny Listed' is selected, these wireless clients on the list will not be able to connect the Access Point. 1. From the Wireless Access Control Mode drop-down list, select Deny Listed setting. 2.
Page 103: Wds Settings
Wi-Fi Personal Bridge 150 User Manual WDS settings Wireless Distribution System uses wireless media to communicate with other APs, like the Ethernet does. To do this, you must set these APs in the same channel and set MAC address of other APs which you want to communicate with in the table and then enable the WDS.
Page 104: Configure Wds (Wireless Distribution System) Only
Wi-Fi Personal Bridge 150 User Manual Configure WDS (Wireless Distribution System) only 1. From the left-hand Wireless menu, click on Basic Settings. 2. From the Mode drop-down list, select WDS. 3. From the Channel Number drop-down list, select a Channel. 4.
Page 105 Wi-Fi Personal Bridge 150 User Manual 6. From the left-hand Wireless menu, click on WDS settings. 7. Check on the option Enable WDS. 8. Enter the MAC Address. 9. Enter the Comment. 10. Click the Set Security. 11. This page allows you setup the wireless security for WDS. When enabled, you must make sure each WDS device has adopted the same encryption algorithm and Key.
Page 106 Wi-Fi Personal Bridge 150 User Manual 14. Change setting successfully! Click on Reboot Now button to confirm. 15. Click Close button to close and exit the WDS Security Setup. 16. Change setting successfully! Click on Reboot Now button to confirm.
Page 107 Wi-Fi Personal Bridge 150 User Manual 17. Click Apply Changes button. 18. Change setting successfully! Click on Reboot Now button to confirm. 19. The MAC Address that you created has been added in the Current Access Control List.
Page 108: Configure Ap (Access Point) + Wds (Wireless Distribution System)
Wi-Fi Personal Bridge 150 User Manual Configure AP (Access Point) + WDS (Wireless Distribution System) 1. From the left-hand Wireless menu, click on Basic Settings. 2. From the Mode drop-down list, select AP+WDS. 3. Enter SSID for example 11n Pocket AP. 4.
Page 109 Wi-Fi Personal Bridge 150 User Manual 7. From the left-hand Wireless menu, click on WDS settings. 8. Check on the option Enable WDS. 9. Enter the MAC Address. 10. Enter the Comment. 11. Click the Set Security.
Page 110 Wi-Fi Personal Bridge 150 User Manual 12. This page allows you setup the wireless security for WDS. When enabled, you must make sure each WDS device has adopted the same encryption algorithm and Key. 13. Configure each field with the Encryption that you selected. 14.
Page 111 Wi-Fi Personal Bridge 150 User Manual 17. Click Apply Changes button. 18. Change setting successfully! Click on Reboot Now button to confirm. 19. The MAC Address that you created has been added in the Current Access Control List.
Page 112: Site Survey
Wi-Fi Personal Bridge 150 User Manual Site Survey This page provides tool to scan the wireless network. If any Access Point or IBSS is found, you could choose to connect it manually when client mode is enabled. To access the Wireless Network WDS settings page: From the left-hand Wireless menu, click on Site Survey.
Page 113: Configure Wireless Isp + Wireless Client + Site Survey
Wi-Fi Personal Bridge 150 User Manual Configure Wireless ISP + Wireless client + Site Survey 1. From the left-hand Operation Mode menu, click on Wireless ISP Settings. 2. Click Apply Changes button. 3. Change setting successfully! Please wait 20 seconds….
Page 114 Wi-Fi Personal Bridge 150 User Manual 4. From the left-hand Wireless menu, click on Basic Settings. 5. From the Mode drop-down list, select Client. 6. Enter SSID of the AP that you want to connect to for example 11n Pocket AP. If you don’t know what the SSID of the AP that you want to connect to, please skip this step.
Page 115 Wi-Fi Personal Bridge 150 User Manual 9. From the left-hand Wireless menu, click on Site Survey. 10. Click Site Survey button. 11. Now you could see the APs that scanned by the Wireless Gateway were listed below. 12. Click on the ratio of AP’s SSID under the item Select that you want the Wireless Gateway to connect to.
Page 116 Wi-Fi Personal Bridge 150 User Manual 14. Click Connect button. 15. Connect successfully! Click on OK button to confirm and return.
Page 117: Wps
Wi-Fi Personal Bridge 150 User Manual This page allows you to change the setting for WPS (Wi-Fi Protected Setup). Using this feature could let your wireless client automatically syncronize its setting and connect to the Access Point in a minute without any hassle. To access the Wireless Network WPS page: From the left-hand Wireless menu, click on WPS.
Page 118: Introduction Of Wps
Wi-Fi Personal Bridge 150 User Manual Reset It restores the original values of “Self-PIN Number” and “Client PIN Number”. Client PIN Number It is only used when users want their station to join AP’s network. The length of PIN is limited to four or eight numeric digits. If users enter eight digit PIN with checksum error, there will be a warning message popping If users insist on this PIN, AP will take it.
Page 119: Ap As Enrollee
Wi-Fi Personal Bridge 150 User Manual AP as Enrollee If users know AP’s PIN and enter it into external registrar, the external registrar will configure AP with a new wireless profile such as new SSID and new security settings. The external registrar does this job either utilizing the in-band EAP (wireless) or out-of-band UPnP (Ethernet).
Page 120: Wireless Advanced Settings Page
Wi-Fi Personal Bridge 150 User Manual Wireless Advanced Settings page Users need to make sure the “Broadcast SSID” file is set to “Enabled”. Otherwise, it might prevent WPS from working properly.
Page 121: Operations Of Ap - Ap Being An Enrollee
Wi-Fi Personal Bridge 150 User Manual Operations of AP - AP being an enrollee In this case, AP will be configured by any registrar either through in-band EAP or UPnP. Here, users do not need to do any action on AP side. They just need AP’s device PIN and enter it into registrar. An example from Vista WCN will be given.
Page 122 Wi-Fi Personal Bridge 150 User Manual 3. Plug the Ethernet cable into AP’s LAN port and make sure the IP connection is valid with Vista. 4. Make sure WCN is enabled. Users may need to enable it at the first time. They could open the “Control Panel”, click “Classic View“, open “Administrative Tools”, double click “Services”, ”, a User Account Control pop up and click “Continue“, edit properties of “Windows Connect Now”, choose the “Startup type”...
Page 123 Wi-Fi Personal Bridge 150 User Manual 5. If the previous steps are done, open Windows Explorer. Go to the Network section. 6. Click on “Network discovery and file sharing are turned off. Network computers and devices are not visible. Click to Change…“ 7.
Page 124 Wi-Fi Personal Bridge 150 User Manual 8. Click on “No, make the network that I am connected to a private network“ 9. AP’s icon will show up. Double click on it.
Page 125 Wi-Fi Personal Bridge 150 User Manual 10. Users could also Click “Add a wireless device” if the icon is not there. Click “next”. 11. Enter AP’s Self-PIN Number and click “next”.
Page 126 Wi-Fi Personal Bridge 150 User Manual 12. Choose a name that people who connect to your network will recognize. 13. Enter the Passphrase and then click Next.
Page 127 Wi-Fi Personal Bridge 150 User Manual 14. A User Account Control screen pops up, click Continue. 15. AP is successfully configured by WCN. 16. Finally, AP will become configured (see WPS Status). The authentication algorithm, encryption algorithm, and key assigned by WCN will be displayed below “Current Key Info”.
Page 128 Wi-Fi Personal Bridge 150 User Manual 17. The SSID field of Wireless Basic Settings page will also be modified with the value assigned by WCN.
Page 129 Wi-Fi Personal Bridge 150 User Manual 18. The security settings on the Wireless Security Page will be modified by WCN, too. The warning message will show up if users try to modify the security settings. The reason is the same as we explained in the previous section.
Page 130: Operations Of Ap - Ap Being A Registrar
Wi-Fi Personal Bridge 150 User Manual Operations of AP - AP being a registrar AP mode Whenever users enter station’s PIN into AP’s Wi-Fi Protected Setup page and click “Start PIN”, AP will become a registrar. Users must start the PIN method on the station side within two minutes. 1.
Page 131 Wi-Fi Personal Bridge 150 User Manual 6. Users must start the PIN method on the station side within two minutes. 7. If the device PIN is correct and the WPS handshake is successfully done on the station side, User’s Wi-Fi Protected status will be shown as below.
Page 132 Wi-Fi Personal Bridge 150 User Manual 8. If the device PIN is correct and the WPS handshake is successfully done, AP’s Wi-Fi Protected Setup page will be shown as below. Other pages such as Wireless Basic Settings page and Wireless Security Setup page will also be updated appropriately as described in previous sections.
Page 133: Push Button Method
Wi-Fi Personal Bridge 150 User Manual Push Button method Wireless Gateway supports a virtual button “Start PBC” on the Wi-Fi Protected Setup page for Push Button method. If users push a virtual button “Start PBC”, AP will initiate a WPS session and wait for any station to join.
Page 134 Wi-Fi Personal Bridge 150 User Manual 5. Users must start the PBC method on the station side within two minutes. 6. If the device PCB and the WPS handshake is successfully done on the station side, User’s Wi- Fi Protected status will be shown as below.
Page 135 Wi-Fi Personal Bridge 150 User Manual 7. If the device PIN is correct and the WPS handshake is successfully done, AP’s Wi-Fi Protected Setup page will be shown as below. Other pages such as Wireless Basic Settings page and Wireless Security Setup page will also be updated appropriately as described in previous sections.
Page 136: Wireless Schedule
Wi-Fi Personal Bridge 150 User Manual Wireless Schedule This page allows you setup the wireless schedule rule. Please do not forget to configure system time before enable this feature. To access the Wireless Schedule page: From the left-hand Wireless menu, click on Wireless Schedule. The following page is displayed:...
Page 137: Lan Interface
Wi-Fi Personal Bridge 150 User Manual LAN Interface This chapter is to configure the parameters for local area network which connects to the LAN port of your Access Point. Here you may change the setting for IP address, subnet mask, DHCP, etc... You should only change the addressing details if your ISP asks you to, or if you are familiar with network configuration.
Page 138 Wi-Fi Personal Bridge 150 User Manual Field Description IP Address The LAN IP address Default: 10.0.0.2 Subnet Mask The LAN netmask Default: 255.255.255.0 Default Gateway The LAN Gateway Default: 0.0.0.0 DHCP DHCP Type: Disable, DHCP Client or Server Default: DHCP Server DHCP Client Range Specify the starting/ending IP address of the IP address pool.
Page 139: Changing The Lan Ip Address And Subnet Mask
Wi-Fi Personal Bridge 150 User Manual Changing the LAN IP address and subnet mask To check the configuration of LAN Interface: 2. From the left-hand Network Settings -> LAN Interface menu. The following page is displayed:...
Page 140 Wi-Fi Personal Bridge 150 User Manual 3. Type IP Address and Change default LAN port IP address. 4. Click in the IP Address and Subnet Mask box and type a new IP Address and Subnet Mask. 5. Change the default DHCP Client Range. 6.
Page 141 Wi-Fi Personal Bridge 150 User Manual You may also need to renew your DHCP lease: Windows 95/98 a. Select Run... from the Start menu. b. Enter winipcfg and click OK. c. Select your ethernet adaptor from the pull-down menu d. Click Release All and then Renew All. e.
Page 142: Show Client
Wi-Fi Personal Bridge 150 User Manual Show Client To the IP Address, MAC Address, and Expired Time of the DHCP lease for each client computer/device: 1. From the left-hand Network Settings -> LAN Interface menu. The following page is displayed: 2.
Page 143: Wan Interface
Wi-Fi Personal Bridge 150 User Manual WAN Interface This chapter describes how to configure the way that your device connects to the Internet. Your ISP determines what type of Internet access you should use and provides you with any information that you need in order to configure the Internet access to your device.
Page 144 Wi-Fi Personal Bridge 150 User Manual 1. From the left-hand Network Settings -> WAN Interface menu. The following page is displayed:...
Page 145 Wi-Fi Personal Bridge 150 User Manual Option Description Static IP Choose this option if you are a leased line user with a fixed IP address. Access DHCP Client Choose this option if you are connected to the Internet Type through a Cable modem line. PPPoE Choose this option if you are connected to the Internet through a DSL line...
Page 146 Wi-Fi Personal Bridge 150 User Manual Option Description Clone MAC Address Clone MAC lets the device identify itself as another computer or device Enable uPNP Enable or Disable uPNP Enable IGMP Proxy Enable or Disable IGMP Proxy Enable Ping Access on WAN Enable or Disable Ping Access on WAN Enable Web Server Access on Enable or Disable Web Server Access on WAN...
Page 147: Configuring Static Ip Connection
Wi-Fi Personal Bridge 150 User Manual Configuring Static IP connection If you are a leased line user with a fixed IP address, enter in the IP address, subnet mask, gateway address, and DNS (domain name server) address(es) provided to you by your ISP. If your ISP wants you to connect to the Internet using Static IP, follow the instructions below.
Page 148: Configuring Dhcp Client Connection
Wi-Fi Personal Bridge 150 User Manual Configuring DHCP Client connection Dynamic Host Configuration Protocol (DHCP), Dynamic IP (Get WAN IP Address automatically). If you are connected to the Internet through a Cable modem line, then a dynamic IP will be assigned. If your ISP wants you to connect to the Internet using DHCP Client, follow the instructions below.
Page 149: Configuring Pppoe Connection
Wi-Fi Personal Bridge 150 User Manual Configuring PPPoE connection If your ISP’s Internet service uses PPPoE you need to set up a PPP login account. The first time that you login to the Internet, your ISP will ask you to enter a username and password so they can check that you are a legitimate, registered Internet service user.
Page 150: Configuring Pptp Connection
Wi-Fi Personal Bridge 150 User Manual Configuring PPTP connection If your ISP/Network Administrator wants you to connect to the Internet using PPTP, follow the instructions below. 1. From the left-hand Network Settings -> WAN Interface menu. The following page is displayed: 2.
Page 151 Wi-Fi Personal Bridge 150 User Manual 5. Change setting successfully! Click on Reboot Now button to confirm.
Page 152: Configuring L2Tp Connection
Wi-Fi Personal Bridge 150 User Manual Configuring L2TP connection If your ISP/Network Administrator wants you to connect to the Internet using L2TP, follow the instructions below. 1. From the left-hand Network Settings -> WAN Interface menu. The following page is displayed: 2.
Page 153 Wi-Fi Personal Bridge 150 User Manual 5. Change setting successfully! Click on Reboot Now button to confirm.
Page 154: Clone Mac Address
Wi-Fi Personal Bridge 150 User Manual Clone MAC Address Some particularly ISPs do not want you to have a home network and have a DSL/Cable modem that allows only 1 MAC to talk on the internet. If you change network cards, you have to call them up to change the MAC.
Page 155 Wi-Fi Personal Bridge 150 User Manual 5. Change setting successfully! Click on Reboot Now button to confirm.
Page 156: Port Filtering
Wi-Fi Personal Bridge 150 User Manual Port Filtering Entries in Current Filter Table are used to restrict certain ports and types of data packets from your local network to Internet through the Gateway. Use of such filters can be helpful in securing or restricting your local network.
Page 157: Port Filtering For Tcp Port 80
Wi-Fi Personal Bridge 150 User Manual Port filtering for TCP port 80 Please follow example below to deny the TCP port 80 for both Outbound and Inbound packet. 1. From the left-hand Firewall -> Port Filtering menu. The following page is displayed: 2.
Page 158: Port Filtering For Udp Port 53
Wi-Fi Personal Bridge 150 User Manual Port filtering for UDP port 53 Please follow example below to deny the UDP port 53 for both Outbound and Inbound packet. 1. From the left-hand Firewall -> Port Filtering menu. The following page is displayed: 2.
Page 159: Ip Filtering
Wi-Fi Personal Bridge 150 User Manual IP Filtering Entries in this table are used to restrict certain types of data packets from your local network to Internet through the Gateway. Use of such filters can be helpful in securing or restricting your local network.
Page 160: Ip Filtering For Tcp With Specified Ip
Wi-Fi Personal Bridge 150 User Manual IP filtering for TCP with specified IP Please follow example below to deny the TCP protocol for specified IP. 1. From the left-hand Firewall -> IP Filtering menu. The following page is displayed: 2. Check the option Enable IP Filtering to enable the IP Filtering. 3.
Page 161 Wi-Fi Personal Bridge 150 User Manual 7. Now the IP Filter that you created has been added and listed in the Current Filter Table. 8. Now the TCP protocol for both Outbound and Inbound packet has been denied. Now The Local IP Address for example 10.0.0.102 that listed in the Current Filter Table cannot visit any application that use TCP protocol for example web site due to the Protocol TCP has been blocked by the IP Filtering rule that created.
Page 162: Ip Filtering For Udp With Specified Ip
Wi-Fi Personal Bridge 150 User Manual IP filtering for UDP with specified IP Please follow example below to deny the UDP protocol for specified IP. 1. From the left-hand Firewall -> IP Filtering menu. The following page is displayed: 2. Check the option Enable IP Filtering to enable the IP Filtering. 3.
Page 163 Wi-Fi Personal Bridge 150 User Manual 7. Now the IP Filter that you created has been added and listed in the Current Filter Table. 8. Now the UDP protocol for both Outbound and Inbound packet has been denied. Now The Local IP Address for example 10.0.0.102 that listed in the Current Filter Table cannot visit any application that use UDP protocol for example TFTP Service due to the Protocol UDP has been blocked by the IP Filtering rule that created.
Page 164: Ip Filtering For Both Tcp And Udp With Specified Ip
Wi-Fi Personal Bridge 150 User Manual IP filtering for both TCP and UDP with specified IP Please follow example below to deny the both TCP and UDP protocol for specified IP. 1. From the left-hand Firewall -> IP Filtering menu. The following page is displayed: 2.
Page 165 Wi-Fi Personal Bridge 150 User Manual 7. Now the IP Filter that you created has been added and listed in the Current Filter Table. 8. Now the TCP and UDP protocol for both Outbound and Inbound packet has been denied.
Page 166: Mac Filtering
Wi-Fi Personal Bridge 150 User Manual MAC Filtering Entries in this table are used to restrict certain types of data packets from your local network to Internet through the Wireless Gateway. Use of such filters can be helpful in securing or restricting your local network.
Page 167: Mac Filtering For Specified Mac Address
Wi-Fi Personal Bridge 150 User Manual MAC filtering for specified MAC Address Please follow example below to deny the specified MAC Address has the Internet Access. 1. From the left-hand Firewall -> MAC Filtering menu. The following page is displayed: 2.
Page 168 Wi-Fi Personal Bridge 150 User Manual 6. Now the MAC Filter that you created has been added and listed in the Current Filter Table. 7. Now the MAC Address in the Current Filter Table cannot have the Internet Access.
Page 169: Port Forwarding
Wi-Fi Personal Bridge 150 User Manual Port Forwarding Entries in this table allow you to automatically redirect common network services to a specific machine behind the NAT firewall. These settings are only necessary if you wish to host some sort of server like a web server or mail server on the private local network behind your Gateway's NAT firewall.
Page 170: Port Forwarding For Tcp With Specified Ip
Wi-Fi Personal Bridge 150 User Manual Port Forwarding for TCP with specified IP Please follow example below to configure the Port Forwarding to Specified IP with TCP. 1. From the left-hand Firewall -> Port Forwarding menu. The following page is displayed: 2.
Page 171: Port Forwarding For Udp With Specified Ip
Wi-Fi Personal Bridge 150 User Manual Port Forwarding for UDP with specified IP Please follow example below to configure the Port Forwarding to Specified IP with UDP. 1. From the left-hand Firewall -> Port Forwarding menu. The following page is displayed: 2.
Page 172: Url Filtering
Wi-Fi Personal Bridge 150 User Manual URL Filtering URL filter is used to deny LAN users from accessing the internet. Block those URLs which contain keywords listed below. 1. From the left-hand Firewall -> URL Filtering menu. The following page is displayed: URL filtering for specified URL Address Please follow example below to deny LAN users from accessing the Internet.
Page 173 Wi-Fi Personal Bridge 150 User Manual 5. Now the URL Filter that you created has been added and listed in the Current Filter Table. 6. Now the URL Address in the Current Filter Table cannot be visited.
Page 174: Dmz
Wi-Fi Personal Bridge 150 User Manual A Demilitarized Zone is used to provide Internet services without sacrificing unauthorized access to its local private network. Typically, the DMZ host contains devices accessible to Internet traffic, such as Web (HTTP ) servers, FTP servers, SMTP (e-mail) servers and DNS servers. 1.
Page 175 Wi-Fi Personal Bridge 150 User Manual...
Page 176: Vlan
Wi-Fi Personal Bridge 150 User Manual VLAN Entries in below table are used to config vlan settings. VLANs are created to provide the segmentation services traditionally provided by routers. VLANs address issues such as scalability, security, and network management. 1. From the left-hand Firewall -> VLAN menu. The following page is displayed:...
Page 177: Qos
Wi-Fi Personal Bridge 150 User Manual Entries in this table improve your online gaming experience by ensuring that your game traffic is prioritized over other network traffic, such as FTP or Web. 1. From the left-hand Firewall -> QoS menu. The following page is displayed:...
Page 178: Route Setup
Wi-Fi Personal Bridge 150 User Manual Route Setup This page is used to setup dynamic routing protocol or edit static route entry. 1. From the left-hand Route Setup menu. The following page is displayed:...
Page 179: Status
Wi-Fi Personal Bridge 150 User Manual Status This page displays the current information for the device. It will display the LAN, WAN, and system firmware information. This page will display different information, according to WAN setting (Static IP, DHCP, or PPPoE). 1.
Page 180: Statistics
Wi-Fi Personal Bridge 150 User Manual Statistics This page shows the packet counters for transmission and reception regarding to wireless and Ethernet networks. 1. From the left-hand Management -> Statistics menu. The following page is displayed:...
Page 181: Dynamic Dns
Wi-Fi Personal Bridge 150 User Manual Dynamic DNS When you want your internal server to be accessed by using DNS name rather than using the dynamic IP address, you can use the DDNS service. The DDNS server allows to alias a dynamic IP address to a static hostname.
Page 182 Wi-Fi Personal Bridge 150 User Manual Registering With Dynamic DNS Service Provider Currently, Wireless Gateway supports two Dynamic DNS service providers, www.tzo.com and www.dyndns.com. To use their Dynamic DNS service, you first need to visit the Web site of a service provider and register.
Page 183: Configure Dyndns
Wi-Fi Personal Bridge 150 User Manual Configure DynDNS 2. From the left-hand Management -> DDNS menu. The following page is displayed: 3. Click on Enable DDNS 4. Select the DynDNS from the Service Provider drop-down list. 5. Type your own unique User Name, Password and Domain Name which you applied from www.dyndns.com in the relevant boxes.
Page 184: Configure Tzo
Wi-Fi Personal Bridge 150 User Manual Configure TZO 1. From the left-hand Management -> DDNS menu. The following page is displayed: 2. Click on Enable DDNS 3. Select the TZO from the Service Provider drop-down list. 4. Type your own unique Email, Key and Domain Name which you applied from http://www.tzo.com/MainPageWebClient/clientsignup.html in the relevant boxes.
Page 185: Time Zone Setting
Wi-Fi Personal Bridge 150 User Manual Time Zone Setting Certain systems may not have a date or time mechanism or may be using inaccurate time/day information. the Simple Network Time Protocol feature provides a way to synchronize the device’s own time of day setting with a remote time server as described in RFC 2030 (SNTP) and RFC 1305 (NTP).
Page 186 Wi-Fi Personal Bridge 150 User Manual 6. Change setting successfully! Click on Reboot Now button to confirm.
Page 187: Denial-Of-Service
Wi-Fi Personal Bridge 150 User Manual Denial-of-Service A "denial-of-service" (DoS) attack is characterized by an explicit attempt by hackers to prevent legitimate users of a service from using that service. Denial-of-Service 1. From the left-hand Management menu, click on Denial-of-Service. The following page is displayed: 2.
Page 188 Wi-Fi Personal Bridge 150 User Manual 6. Change setting successfully! Click on Reboot Now button to confirm.
Page 189: Log
Wi-Fi Personal Bridge 150 User Manual This page can be used to set remote log server and show the system log. System Log 1. From the left-hand Management menu, click on Log. The following page is displayed: Option Description Enable Log Enable/Disable the feature.
Page 190 Wi-Fi Personal Bridge 150 User Manual 2. Check the option Enable Log. 3. Check the option system all, wireless or DoS. 4. Check the option Enable Remote Log if you 5. Enter the IP Address in the Log Server IP Address field. 6.
Page 191: Firmware Update
Wi-Fi Personal Bridge 150 User Manual Firmware Update About firmware versions Firmware is a software program. It is stored as read-only memory on your device. Your device can check whether there are later firmware versions available. If there is a later version, you can download it via the Internet and install it on your device.
Page 192 Wi-Fi Personal Bridge 150 User Manual 5. Firmware update has been update complete. The following page is displayed:...
Page 193: Save/Reload Settings
Wi-Fi Personal Bridge 150 User Manual Save/Reload Settings This page allows you save current settings to a file or reload the settings from the file which was saved previously. Besides, you could reset the current configuration to factory default. If you do make changes to the default configuration but then wish to revert back to the original factory configuration, you can do so by resetting the device to factory defaults.
Page 194 Wi-Fi Personal Bridge 150 User Manual 2. Click on Save…. 3. If you are happy with this, click Save and then browse to where the file to be saved. Or click Cancel to cancel it.
Page 195: Load Settings From File
Wi-Fi Personal Bridge 150 User Manual Load Settings from File It allows you to reload the settings from the file which was saved previously. 1. From the left-hand Management menu, click on Reset factory default. The following page is displayed: Figure 3: Reset to Defaults page 2.
Page 196 Wi-Fi Personal Bridge 150 User Manual 4. Once it finished loading settings form file, it’ll show the message below.
Page 197: Resetting To Defaults
Wi-Fi Personal Bridge 150 User Manual Resetting to Defaults If you do make changes to the default configuration but then wish to revert back to the original factory configuration, you can do so by resetting the device to factory defaults. If you reset your device to factory defaults, all previous configuration changes that you have made are overwritten by the Note...
Page 198 Wi-Fi Personal Bridge 150 User Manual 4. Reload setting successfully! Please wait for a moment while rebooting ... 5. Once it finished resetting to factory, it’ll show the Status page.
Page 199: Password
2. This page displays the current username and password settings. Change your own unique password in the relevant boxes. They can be any combination of letters or numbers with a maximum of 30 characters. The default setting uses admin for the username and hamlet for password.
Page 200 Wi-Fi Personal Bridge 150 User Manual Figure 5: Administration Password 4. Change setting successfully. 5. Enter new User name and Password. 6. Click Apply.
Page 201: Logout
Wi-Fi Personal Bridge 150 User Manual Logout This page is used to logout. Logout To logout: 1. From the left-hand menu, click on Logout. The following page is displayed: 2. Click Apply Change.
Page 202: A Configuring Your Computers
Wi-Fi Personal Bridge 150 User Manual Configuring your Computers This appendix provides instructions for configuring the Internet settings on your computers to work with the Wireless Gateway. Configuring Ethernet PCs Before you begin By default, the Wireless Gateway automatically assigns the required Internet settings to your PCs. You need to configure the PCs to accept this information when it is assigned.
Page 203: Windows Me Pcs
Wi-Fi Personal Bridge 150 User Manual 5. In the Select Network Component Type dialog box, select Protocol, and then click Add… 6. Select Internet Protocol (TCP/IP) in the Network Protocols list, and then click OK. You may be prompted to install files from your Windows 2000 installation CD or other media. Follow the instructions to install the files.
Page 204: Assigning Static Internet Information To Your Pcs
Wi-Fi Personal Bridge 150 User Manual 4. Select Protocol, and then click Add… The Select Network Protocol dialog box displays. 5. Click on Microsoft in the Manufacturers list box, and then click TCP/IP in the Network Protocols list box. 6. Click OK to return to the Network dialog box, and then click OK again. You may be prompted to install files from your Windows 95/98 installation CD.
Page 205: B Ip Addresses, Network Masks, And Subnets
Wi-Fi Personal Bridge 150 User Manual IP Addresses, Network Masks, and Subnets IP Addresses This section refers only to IP addresses for IPv4 (version 4 of the Internet Protocol). IPv6 addresses are not covered. This section assumes basic knowledge of binary numbers, bits, Note and bytes.
Page 206: Subnet Masks
Wi-Fi Personal Bridge 150 User Manual Class C networks are the smallest, only able to hold 254 hosts at most, but the total possible number of class C networks exceeds 2 million (2,097,152 to be exact). LANs connected to the Internet are usually class C networks.
Page 207: C Upnp Control Point Software On Windows Me/Xp
Wi-Fi Personal Bridge 150 User Manual UPnP Control Point Software on Windows ME/XP This appendix provides instructions for configuring the UPnP on your computers to work with the Wireless Gateway. UPnP is an architecture for pervasive peer-to-peer network connectivity of intelligent appliances, Wireless devices, and PCs of all form factors.
Page 208: Ssdp Requirements
Wi-Fi Personal Bridge 150 User Manual To turn off the Firewall capability on any version of Windows XP, follow the steps below: 1. In the Control Panel, select "Network and Internet Connections". 2. In the "Network and Internet Connections" dialog box, select "Network Connections". 3.
Page 209 Wi-Fi Personal Bridge 150 User Manual 5. Select the following entries from the “Networking Services” window and then click "OK": If you are using Windows XP, select: • "Universal Plug and Play". If you are using Windows XP SP1, select: •...
Page 210: D Troubleshooting
If you have not changed the password from the default, try using “admin” the ID or password. user ID and “hamlet“ as password. Otherwise, you can reset the device to the default configuration by pressing the Reset Default button on the Rare panel of the device (see Rare Panel).
Page 211: Diagnosing Problem Using Ip Utilities
Wi-Fi Personal Bridge 150 User Manual Diagnosing Problem using IP Utilities ping Ping is a command you can use to check whether your PC can recognize other computers on your network and the Internet. A ping command sends a message to the computer you specify. If the computer receives the message, it sends messages in reply.
Page 212 Wi-Fi Personal Bridge 150 User Manual There may be several addresses associated with an Internet name. This is common for web sites that receive heavy traffic; they use multiple, redundant servers to carry the same information. To exit from the nslookup utility, type exit and press [Enter] at the command prompt.
Page 213: E Glossary
Wi-Fi Personal Bridge 150 User Manual Glossary 10BASE-T A designation for the type of wiring used by Ethernet networks with a data rate of 10 Mbps. Also known as Category 3 (CAT 3) wiring. See data rate, Ethernet. 100BASE-T A designation for the type of wiring used by Ethernet networks with a data rate of 100 Mbps. Also known as Category 5 (CAT 5) wiring.
Page 214 Wi-Fi Personal Bridge 150 User Manual Bridging Passing data from your network to your ISP and vice versa using the hardware addresses of the devices at each location. Bridging contrasts with routing, which can add more intelligence to data transfers by using network addresses instead. The Wireless Gateway can perform both routing and bridging.
Page 215 Wi-Fi Personal Bridge 150 User Manual Names and Numbers (ICANN). Domain names are a key element of URLs, which identify a specific file at a web site. See DNS. Download To transfer data in the downstream direction, i.e., from the Internet to the user. Digital Subscriber Line A technology that allows both digital data and analog voice signals to travel over existing copper telephone lines.
Page 216 Wi-Fi Personal Bridge 150 User Manual IEEE The Institute of Electrical and Electronics Engineers is a technical professional society that fosters the development of standards that often become national and international standards. Internet The global collection of interconnected networks used for both private and business communications.
Page 217 Wi-Fi Personal Bridge 150 User Manual Mask See network mask. Mbps Abbreviation for Megabits per second, or one million bits per second. Network data rates are often expressed in Mbps. Network Address Translation A service performed by many routers that translates your network’s publicly known IP address into a private IP address for each computer on your LAN.
Page 218 Wi-Fi Personal Bridge 150 User Manual Point-to-Point Protocol A protocol for serial data transmission that is used to carry IP (and other protocol) data between your ISP and your computer. The WAN interface on the Wireless Gateway uses two forms of PPP called PPPoA and PPPoE.
Page 219 Wi-Fi Personal Bridge 150 User Manual Subnet A subnet is a portion of a network. The subnet is distinguished from the larger network by a subnet mask that selects some of the computers of the network and excludes all others. The subnet's computers remain physically connected to the rest of the parent network, but they are treated as though they were on a separate network.
Page 220 Wi-Fi Personal Bridge 150 User Manual Twisted pair The ordinary copper telephone wiring used by telephone companies. It contains one or more wire pairs twisted together to reduce inductance and noise. Each telephone line uses one pair. In homes, it is most often installed with two pairs. For Ethernet LANs, a higher grade called Category 3 (CAT 3) is used for 10BASE-T networks, and an even higher grade called Category 5 (CAT 5) is used for 100BASE-T networks.
Page 221 Wi-Fi Personal Bridge 150 User Manual Web page A web site file typically containing text, graphics and hyperlinks (cross-references) to the other pages on that web site, as well as to pages on other web sites. When a user accesses a web site, the first page that is displayed is called the home page.

This manual is also suitable for:

Wi-fi personal bridge 150

Hamlet HNW150APBR User Manual

1 Introduction

2 Getting to Know the Device

3 Computer Configurations under Different OS, to Obtain IP Address Automatically

4 Connecting Your Device

5 Utility CD Execution

6 What the Internet/Wan Access of Your Own Network Now Is

7 Getting Started with the Web Pages

8 Quick Setup (this Function May Vary Depending on Router, Client or Wifi-AP Mode)

9 Wireless Network

10 LAN Interface

11 WAN Interface

12 Port Filtering

13 IP Filtering

14 MAC Filtering

15 Port Forwarding

16 URL Filtering

17 Dmz

18 Vlan

19 Qos

20 Route Setup

21 Status

22 Statistics

23 Dynamic DNS

24 Time Zone Setting

25 Denial-Of-Service

26 Log

27 Firmware Update

28 Save/Reload Settings

29 Password

30 Logout

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hamlet HNW150APBR

Summary of Contents for Hamlet HNW150APBR
