WIRELESS ADSL2+ ROUTER
USER MANUAL
HRDSL512W-REV2.0
www.hamletcom.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HRDSL521W and is the answer not in the manual?

Questions and answers

Related Manuals for Hamlet HRDSL521W

Summary of Contents for Hamlet HRDSL521W

  • Page 1 WIRELESS ADSL2+ ROUTER USER MANUAL HRDSL512W-REV2.0 www.hamletcom.com...
  • Page 2 Hamlet assumes no liability resulting from errors or omissions in this document, or from the use of the information contained herein. Hamlet reserves the right to make changes or revisions in the product design or the product manual without reservation and without...

  • Page 3: Table Of Contents

    Wireless ADSL Router HRDSL521W Summary Chapter 1 ..........................4 1.1 Introducing the Wireless ADSL2+ Router........4 1.2 Features ..................6 1.3 Applications for the HRDSL512W Series ......... 8 Chapter 2 ..........................9 2.1 Important note for using the (802.11g) ADSL2+ Router ... 9 2.2 Package Contents..............

  • Page 4: Chapter 1

    Wireless ADSL Router HRDSL521W Chapter 1 Introduction to the Router 1.1 Introducing the Wireless ADSL2+ Router Welcome to the ADSL2+ Router. Your router is an “all-in-one” unit, combining an ADSL modem, ADSL router and Ethernet network switch, providing everything you need to get the machines on your network connected to the Internet over your ADSL broadband connection.
  • Page 5 Wireless ADSL Router HRDSL521W for a hacker to target a machine on your network. Secondly, it can block and redirect certain ports to limit the services that outside users can access. For example, to ensure that games and other Internet applications will run properly, user can open some specific ports for outside users to access internal services in network.

  • Page 6: Features

    Wireless ADSL Router HRDSL521W 1.2 Features ADSL Multi-Mode Standard Supports downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. It also supports rate management that allows ADSL subscribers to select an Internet access speed suiting their needs and budgets. It is compliant with Multi-Mode standard (ANSI T1.413, Issue 2;...
  • Page 7 Wireless ADSL Router HRDSL521W Domain Name System (DNS) relay Provides an easy way to map the domain name (a friendly name for users such as www.yahoo.com) and IP address. When a local machine sets its DNS server with this router’s IP address, every DNS conversion request packet from the PC to this router will be forwarded to the real DNS in the outside network.

  • Page 8: Applications For The Hrdsl512W Series

    Wireless ADSL Router HRDSL521W PPP over Ethernet (PPPoE) Provides embedded PPPoE client function to establish a connection. Users can get greater access speed without changing the operation concept, sharing the same ISP account and paying for one access account. No PPPoE client software is required for local computer.

  • Page 9: Chapter 2

    Wireless ADSL Router HRDSL521W Chapter 2 Installing the (802.11g) ADSL2+ Router 2.1 Important note for using the (802.11g) ADSL2+ Router Do not use the router in high humidity or high temperatures. Do not use the same power source for the router as other equipment.

  • Page 10: The Front Leds

    Wireless ADSL Router HRDSL521W 2.3 The Front LEDs DESCRIPTION Lit RED when power is ON, GREEN when the system is ready LAN PORT Lit when connected to an Ethernet device GREEN for 100Mbps; ORANGE for 10Mbps Blinking when data is Transmitted / Received...

  • Page 11: The Rear Ports

    Wireless ADSL Router HRDSL521W 2.4 The Rear Ports PORT DESCRIPTION ON / OFF Power ON/OFF switch POWER Connect the supplied power adapter to this jack RESET After the device is powered on, press it to reset the device 0-3 seconds: reset the device...

  • Page 12: Chapter 3

    Wireless ADSL Router HRDSL521W Chapter 3 Basic Installation The router can be configured through your web browser. A web browser is included as a standard application in the following operating systems: Windows 98/XP/Vista/7, Mac OS, Linux, etc. The product provides a very easy and user-friendly interface for configuration.

  • Page 13: Install Adsl Router

    Wireless ADSL Router HRDSL521W 3.2 Install Adsl Router Power Connection Plug the supplied power adapter to the wall jack and the other side to the router. Please note that the plug type may differ according to different countries. LAN Connection Connect the supplied RJ-45 Ethernet cable to one of the Ethernet ports, and the other side to the PC’s Ethernet interface.

  • Page 14: Factory Default Settings

    Wireless ADSL Router HRDSL521W 3.3 Factory Default Settings Before configuring your ADSL Router, you need to know the following default settings. Web Interface Username: admin Password: hamlet LAN Device IP Settings IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 ISP setting in WAN site...

  • Page 15: Lan And Wan Port Addresses

    Wireless ADSL Router HRDSL521W 3.4 LAN and WAN Port Addresses The parameters of LAN and WAN ports are pre-set in the factory. The default values are shown below. LAN Port WAN Port IP address 192.168.1.254 The PPPoE function is enabled to automatically get Subnet Mask 255.255.255.0...

  • Page 16: Configuring With Your Web Browser

    Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and click “Go”, a user name and password window prompt will appear. The default username and password are “admin” and “hamlet”. Congratulation! You are now successfully logon to the ADSL2+ Router!

  • Page 17: Chapter 4

    Wireless ADSL Router HRDSL521W Chapter 4 Configuration At the configuration homepage, the top navigation menu provides you the link to each configuration page. The category of each configuration page is listed as below. Quick Start (Wizard setup) Interface Setup (Internet, LAN, Wireless)
  • Page 18 Wireless ADSL Router HRDSL521W For detailed instructions on configuring WAN settings, see the Interface Setup section of this manual. The Quick Start Wizard is a useful and easy utility to help setup the device to connect to your ISP (Internet Service Provider) with only a few steps required. It will guide you step by step to configure the password, time zone, and WAN settings of your device.
  • Page 19 Wireless ADSL Router HRDSL521W Step 3: Choose your time zone. Step 4: Set your Internet connection.
  • Page 20 Wireless ADSL Router HRDSL521W Step 5: Configure the wireless network. Step 6: Click Next to save the new settings of your ADSL Router. Step 7: The changes have been saved. Click Close to restart the Router.

  • Page 21: Interface Setup

    Wireless ADSL Router HRDSL521W 4.2 Interface Setup The Interface Setup section configures the Internet, LAN and Wireless settings of the router. These functions are described in the following pages. 4.2.1 Internet...
  • Page 22 Wireless ADSL Router HRDSL521W ATM VC Virtual Circuit: VPI (Virtual Path Identifier) and VCI (Virtual Channel Identifier) define a virtual circuit. PVC Summary: VPI: The valid range for the VPI is 0 to 255. Enter the VPI assigned to you. This field may already be configured.
  • Page 23 Wireless ADSL Router HRDSL521W PPPoE/PPPoA: Select this option if your ISP requires you to use a PPPoE connection. This option is typically used for DSL services. Select Dynamic PPPoE to obtain an IP address automatically for your PPPoE connection. Select Static PPPoE to use a static IP address for your PPPoE connection.
  • Page 24 Wireless ADSL Router HRDSL521W RIP-2 format; the difference is that RIP2-M using Multicast and RIP2-B using Broadcast format.. RIP Direction: Select this option to specify the RIP direction. None is for disabling the RIP function. Both means the ADSL Router will periodically send routing information and accept routing information then incorporate into routing table.

  • Page 25: Router Local Ip

    Wireless ADSL Router HRDSL521W Router Local IP IP Address: Enter the IP address of ADSL Router in dotted decimal notation, for example, 192.168.1.254 (factory default). IP Subnet Mask: The default is 255.0.0.0. User can change it to other such as 255.255.255.0.Type the subnet mask assigned to you by your ISP (if given).
  • Page 26 Wireless ADSL Router HRDSL521W 4.2.3 Wireless This section introduces the wireless LAN and some basic configurations. Wireless LANs can be as simple as two computers with wireless LAN cards communicating in a peer-to-peer network or as complex as a number of computers with wireless LAN cards...

  • Page 27: Access Point Settings

    Wireless ADSL Router HRDSL521W Access Point Settings Access Point: Default setting is set to Activated. If you do not have any wireless, both 802.11g and 802.11b, device in your network, select Deactived. Channel : The range of radio frequencies used by IEEE 802.11b/g wireless devices is called a channel.

  • Page 28: Wds Settings

    Wireless ADSL Router HRDSL521W WEP.&WPA. If you require high security for transmissions, there are four alternatives to select from: 64-bit WEP, 128-bit WEP, WPA-PSK and WPA2-PSK. WEP 128 will offer increased security over WEP 64. You can disable or enable with WPA or WEP for protecting wireless network. The default type of wireless is disabled and to allow all wireless computers to communicate with the access points without any data encryption.

  • Page 29: Wps Settings

    Wireless ADSL Router HRDSL521W MAC Address: Enter the MAC addresses (in XX:XX:XX:XX:XX:XX format) of the wireless station that are allowed or denied access to the router in these address fields. WPS Settings WPS (WiFi Protected Setup) feature is a standard protocol created by Wi-Fi Alliance. This feature greatly simplifies the steps needed to create a Wi-Fi networks for a residential or an office setting.
  • Page 30 Wireless ADSL Router HRDSL521W PIN Method: Configure AP as Registrar 1. Jot down the client’s Pin (eg. 04640776). 2. Enter the Enrollee PIN code and then press Start WPS. 3. Launch the wireless client’s WPS utility (eg. Ralink Utility). Set the Config Mode as Enrollee, press the WPS button on the top bar, select the AP from the WPS AP List.
  • Page 31 Wireless ADSL Router HRDSL521W 4. The client’s SSID and security setting will now be configured to match the SSID and security setting of the Registrar.
  • Page 32 Wireless ADSL Router HRDSL521W PIN Method: Configure AP as Enrollee 1. Jot down the WPS PIN (eg. 87343540).Press Start WPS. 2. Launch the wireless client’s WPS utility (eg. Ralink Utility). Set the Config Mode as Registrar. Enter the PIN number in the PIN Code column then choose the correct AP...
  • Page 33 Wireless ADSL Router HRDSL521W 3. The router’s (AP’s) SSID and security setting will now be configured to match the SSID and security setting of the registrar. 4. Now to make sure that the setup is correctly done, cross check to see if the SSID and...
  • Page 34 Wireless ADSL Router HRDSL521W PBC Method 1. Press the PBC radio button, then Start WPS. 2. Launch the wireless client’s WPS Utility (eg. Ralink Utility). Set the Config Mode as Enrollee. Then press the WPS button and choose the correct AP (eg. “wlan-ap”) from the WPS AP List section before pressing the PBC button to run the scan.
  • Page 35 Wireless ADSL Router HRDSL521W Key 1 to Key 4: Enter the key to encrypt wireless data. To allow encrypted data transmission, the WEP Encryption Key values on all wireless stations must be the same as the router. There are four keys for your selection. The input format is in HEX style, 5 and 13 HEX codes are required for 64-bitWEP and 128-bitWEP respectively.
  • Page 36 Wireless ADSL Router HRDSL521W RADIUS RADIUS (Remote Authentication Dial In User Server). Radius client and Radius server communicate through a shared key authentication, and the user password uses ciphertext way in network transmission which enhances the security. Radius Server IP Address: Enter the IP address of RADIUS authentication server.

  • Page 37: Advanced Setup

    Wireless ADSL Router HRDSL521W 4.3 Advanced Setup 4.3.1 Firewall Your router includes a firewall for controlling Internet access from your LAN and helping to prevent attacks from hackers. In addition to this, when using NAT (Network Address Translation) the router acts as a “natural” Internet firewall, since all PCs on your LAN use private IP addresses that cannot be directly accessed from the Internet.
  • Page 38 Wireless ADSL Router HRDSL521W 4.3.2 Routing If you have another router with a LAN-to-LAN connection, you may create a static routing on the router that is the gateway to Internet. #: Item number Dest IP: IP address of the destination network Mask: The destination mask address.
  • Page 39 Wireless ADSL Router HRDSL521W Gateway IP Address: This is the gateway IP address to which packets are to be forwarded. Metric: It represents the cost of transmission for routing purposes. The number need not be precise, but it must be between 1 and 15.

  • Page 40: Virtual Server

    Wireless ADSL Router HRDSL521W The DMZ Host is a local computer exposed to the Internet. When setting a particular internal IP address as the DMZ Host, all incoming packets will be checked by the Firewall and NAT algorithms then passed to the DMZ host, when a packet received does not use a port number used by any other Virtual Server entries.
  • Page 41 Wireless ADSL Router HRDSL521W The reason for this is that when using NAT, your publicly accessible IP address will be used by and point to your router, which then needs to deliver all traffic to the private IP addresses used by your PCs. Please see the WAN configuration section of this manual for more information on NAT.

  • Page 42: Ip Address Mapping

    Wireless ADSL Router HRDSL521W Protocol: Choose the Protocol Type, ALL, TCP or UDP. Start Port Number: Enter a port number in this field. End Port Number: Enter a port number in this field. Local IP Address: Enter your server IP address in this field.
  • Page 43 Wireless ADSL Router HRDSL521W NOTE If you have disabled the NAT option in the WAN-ISP section, the Virtual Server function will hence be invalid. If the DHCP server option is enabled, you have to be very careful in assigning the IP addresses of the virtual servers in order to avoid conflicts. The easiest...

  • Page 44: Access Management

    Wireless ADSL Router HRDSL521W 4.4 Access Management 4.4.1 ACL Access Control Listing allows you to determine which services/protocols can access which router interface from which computers. You can configure the router for remote Telnet access or upload and download router firmware and configuration files using FTP.
  • Page 45 Wireless ADSL Router HRDSL521W 4.4.2 IP Filter You can Filter the packages by IP/MAC, Application and URL. Filter Type Filter Type Selection: There are three types ”IP/MAC Filter”, ”Application Filter”, and “URL Filter” that user can select for this connection.
  • Page 46 Wireless ADSL Router HRDSL521W IP/MAC Filter Set Editing IP filter Set Index: This is item number Interface: Select which channel (PVC) to configure. Direction: Select the access to the Internet (“Outgoing”) or from the Internet (“Incoming”).or Both. IP/MAC Filter Rule Editing IP Filter Rule Index: This is item number Active: Select Yes from the drop down list box to enable IP filter rule.

  • Page 47: Application Filter

    Wireless ADSL Router HRDSL521W Application Filter Application Filter: Select this option to Activated/Deactivated the Application filter. ICQ: Select this option to Allow / Deny ICQ. MSN: Select this option to Allow / Deny MSN. YMSG: Select this option to Allow / Deny Yahoo messenger.

  • Page 48: Url Filter

    Wireless ADSL Router HRDSL521W URL Filter Active: Select Actived to enable URL Filter. URL Index: This is item number. URL: Allow you to prevent users on your network from accessing particular websites by their URL.
  • Page 49 Wireless ADSL Router HRDSL521W 4.4.3 SNMP Simple Network Management Protocol (SNMP) is a protocol used for exchanging management information between network devices. SNMP is a member of the TCP/IP protocol suite. router supports SNMP agent functionality which allows a manager station to manage and monitor the router through the network.
  • Page 50 Wireless ADSL Router HRDSL521W UPnP: Select this checkbox to activate UPnP. Be aware that anyone could use a UPnP application to open the web configurator's login screen without entering the router 's IP address Auto-configured: Select this check box to allow UPnP-enabled applications to...
  • Page 51 Wireless ADSL Router HRDSL521W Dynamic DNS: Select this check box to use dynamic DNS. Service Provider: Select the name of your Dynamic DNS service provider. My Host Name: Type the domain name assigned to your router by your Dynamic DNS provider.

  • Page 52: Maintenance

    4.5 Maintenance 4.5.1 Administrator In factory setting, the default password is hamlet. You can change the default password to ensure that someone cannot adjust your settings without your permission. Every time you change your password, please record the password and keep it at a safe place.

  • Page 53: Time Zone

    Wireless ADSL Router HRDSL521W 4.5.2 Time Zone The router does not have a real time clock on board; instead, it uses the Simple Network Time Protocol (SNTP) to get the current time from an SNTP server outside your network. Choose your local time zone. After a successful connection to the Internet, the router will retrieve the correct local time from the SNTP server you have specified.
  • Page 54 Wireless ADSL Router HRDSL521W 4.5.3 Firmware Your router’s “firmware” is the software that allows it to operate and provides all its functionality. Think of your router as a dedicated computer, and the firmware as the software it runs. Over time this software may be improved and modified, and your router allows you to upgrade the software it runs to take advantage of these changes.
  • Page 55 Wireless ADSL Router HRDSL521W 4.5.4 SysRestart Click Restart with option Current Settings to reboot your router (and restore your last saved configuration). If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings.

  • Page 56: Status

    Wireless ADSL Router HRDSL521W 4.6 Status 4.6.1 Device Info This page displays the current information for the ADSL Router. It will display the Firmware version, LAN, WAN, and MAC address information. Device Information Firmware version: This is the Firmware version...
  • Page 57 Wireless ADSL Router HRDSL521W IP Address: LAN port IP address. Sub Net Mask: LAN port IP subnet mask. DHCP Server: LAN port DHCP role - Enabled, Relay or disabled Virtual Circuit: There are eight groups of PVC can be defined.

  • Page 58: System Log

    Wireless ADSL Router HRDSL521W 4.6.2 System Log Display system logs accumulated up to the present time. You can trace historical information with this function.
  • Page 59 Wireless ADSL Router HRDSL521W 4.6.3 Statistics Read-only information here includes port status and packet specific statistics. Also provided are "Transmit Statistics" and "Receive Statistics". Ethernet Interface: This field displays the type of port Transmit Frames: This field displays the number of frames transmitted in the last second.
  • Page 60 Wireless ADSL Router HRDSL521W ADSL Transmit total PDUs: This field displays the number of total PDU transmitted in the last second. Transmit total Error Counts: This field displays the number of total error transmitted in the last second. Receive total PDUs: This field displays the number of total PDU received in the last second.
  • Page 61 Wireless ADSL Router HRDSL521W WLAN Tx Frames Count: This field displays the number of frames transmitted in the last second. Tx Errors Count: This field displays the number of errors frames transmitted in the last second. Tx Drops Count: This field displays the number of drops frames transmitted in the last second.

  • Page 62: Help

    Wireless ADSL Router HRDSL521W 4.7 Help This help page provides you some useful messages such as the introductions of some concepts and some guidances. When some problems are encountered, you can turn to this page for help. For example, if you don’t understand what is Quick Start, you can go to this page, click on Quick Start, then you’ll see some messages about it, and understand it quickly.

  • Page 63: Chapter 5

    If your router is not functioning properly, please refer to the suggested solutions provided in this chapter. If your problems persist or the suggested solutions do not meet your needs, please kindly contact your service provider or Hamlet for support. Problems starting up the router...

  • Page 64: Problems With The Lan Interface

    Wireless ADSL Router HRDSL521W Ensure that all other devices connected to the same Frequent loss of ADSL telephone line as your router (e.g. telephones, fax machines, analogue modems) have a line filter connected linesync between them and the wall socket (unless you are using a (disconnections).
