3
Remove the slot panel, then insert the Portable
Navigation device in the unit (See the illustration
below).
Optional Portable
Navigation
• The slot panel can be detached by placing a finger in the hole in the
centre of the panel and pulling it down.
• If the face plate is attached, first remove the face plate, then the slot
panel. After removing the slot panel, reattach the face plate.
4
After inserting, touch [CLOSE] on the EJECT/TILT
screen.
The movable monitor will close.
5
Press SOURCE.
The SOURCE selection screen is displayed.
6
When the source name of [BLACKBIRD] on the
SOURCE selection screen is displayed, touch the
desired source name.
• For details on operation, refer to the Owner's Manual of the Portable
Navigation device.
Removing the Portable Navigation Device
1 Press on the unit.
The display changes to the EJECT/TILT screen.
2 Touch [OPEN] or [ ] of BLACKBIRD on the EJECT/TILT
screen.
The movable monitor will open.
3 Press [ ] behind the monitor.
The Portable Navigation device is removed.
If an Optional Docking Station is used for
IVA-W205R
1
Select the BLACKBIRD in "Setting the AUX Mode"
(page 36).
2
Mount the Portable Navigation device to the optional
docking station.
The connection to the Portable Navigation device is
recognized in steps 1 and 2.
3
Press SOURCE.
The SOURCE selection screen is displayed.
4
Touch [BLACKBIRD].
For details on operation, refer to the Owner's Manual of the
Portable Navigation device.
50
-EN
Portable Navigation Slot
Push
Autogood products internet store http://130.com.ua
Auxiliary Device
(Optional)

Operating Auxiliary Devices (Optional)

To operate your devices connected to the AUX terminals on the rear
panel of IVA-W205R/IVA-W202R, follow the procedure described
below.
WARNING
It is dangerous for the driver to watch the TV/Video while
driving the vehicle. The driver may be distracted from
looking ahead and an accident could occur.
Install the IVA-W205R/IVA-W202R correctly so that the
driver cannot watch TV/Video unless the vehicle is
stopped and the emergency brake is applied.
If the IVA-W205R/IVA-W202R is not installed correctly,
the driver will be able to watch the TV/Video while driving
the vehicle and may be distracted from looking ahead
and cause an accident. The driver or other people could
be severely injured.
• If you try to activate the auxiliary device while driving, the display
will show the warning-PICTURE OFF FOR YOUR SAFETY.
1
Touch [SOURCE] on the main source screen.
The source screen appears on the display.
2
Touch [AUX]*.
The external input screen is displayed.
3
Touch [NTSC/PAL] to change the video input.
* The name which is given as the source name in "Setting the AUX
Mode" on page 36 is displayed.
• If the AUX mode is not displayed on the main menu, set AUX IN to
ON by following "Setting the AUX Mode" (page 36).
• The setting of switching NTSC/PAL, which you have set in this
section, can be used in same way in "Switching the Visual Input
Signal System" on page 36.
• The display mode changes by touching [WIDE].
For operation, refer to "Switching Display Modes" on page 28.
• After connecting the KCA-410C, its AUX input can be used only in
INTERRUPT MODE. For details, refer to the KCA-410C Owner's
Manual.
