ACCESSORIES AND REPLACEMENT PARTS

ITEM DESCRIPTION
CH-40 Battery Charger
HM142V Single headband
HM152V Double Headband
M121S Dynamic Microphone
MC-16C Microphone Cord
MC-44 Microphone Cord
MM-16 Microphone Cord
MM-36 Patch Cord
RK-51 Wind Screen
RK-119 Wind Screen
RK-142 Wind Screen
14040 Shoulder Strap
21329 Power Adapter Cord
CCPRO Carying Case
SS-5 Tripod Stand
Operating frequency:
Audio power output:
Distortion:
Amplifier freq. response:
Max. audio output(SPL):
FM deviation:
Wireless operating range:
RF signal-to-noise ratio:
Speaker:
Weight:
Dimensions:
USE
Replacement
With locking micro plug for M175
Headset Microphone series transmitters.
Double adjustable headband. With micro plug
Headset Microphone for M175 series transmitters.
For hand-held use plugged into the auxiliary MIC input of the LONG
RANGER III (cord not supplied).
16 ft. coil cord (1/4" male to male) for M121S
1/4" male to locking micro male; adapts M121S to M175
Straight cord (1/4" male to male) for M121S
36" RCA (male to male) For interconnecting AUX IN/OUT jacks.
For M121S microphone
For M119 and M140 microphones
HM142V and HM152V headset microphones
For carrying LONG RANGER III
For connecting LONG RANGER III to vehicle cigarette lighter adapter.
Molded, pre-cut foam lined
2-section legs, riser column; 60" max. height

SPECIFICATIONS

169 to 186 MHz
33 Watts, RMS, into 8 Ohms
less than 1%
50Hz to 20kHz; +0, -3 dB
140 dB at 3 feet
±15kHz
Up to 750 feet
96dB, A weighted
6" x 12" re-entrant horn
16 lbs.
15" high, 6 3/4" wide, 9 1/4" deep
Specifications subject to change without notice.
Rio Rancho, NM – USA
Portable Wireless Sound System
