Summary of Contents for Lectrosonics Long Ranger III
- Page 1 PORTABLE WIRELESS SOUND SYSTEM OPERATING INSTRUCTIONS and trouble-shooting guide LECTROSONICS, INC. Rio Rancho, NM...
-
Page 2: Table Of Contents
INTRODUCTION Thank you for selecting the Long Ranger III Portable Wireless Sound System. This system represents over 80 years of combined experience in the design of RF transmitters, receivers and Public Address systems. The Long Ranger III sets new standards for operational convenience, flexibility and mechanical ruggedness. The built-in wireless receiver, the rechargeable power supply and the high audio output set this system apart from any other portable PA system on the market. -
Page 3: General Technical Description
Since the LONG RANGER III consumes more power than the CH-40 charger can supply, the batteries will recharge faster if you turn the LONG RANGER III power off while charging. The batteries normally require 2 to 6 hours to recharge. If the unit is completely run down, it may require as much as 24 hours to fully charge the batteries. Leave the charger plugged in at least until the green lamp below the CH-40 jack goes out. -
Page 4: Controls And Functions
LONG RANGER IIIs together for simultaneous operation. This jack can also be used with a tape deck to either record from or play back into the LONG RANGER III. When used with a tape deck or other audio source, the sound output level must be controlled by the volume control on the tape deck since there is no volume control on the LONG RANGER III for the AUX IN/OUT jack. -
Page 5: Front Panel
A special jack used to connect an external 12 Volt DC source to the unit to substitute for the “on-board” battery pack. It is most commonly used for connecting the LONG RANGER III to a vehicle cigarette lighter receptacle. When an external power source is connected to this jack, the on-board battery pack is automatically disconnected. -
Page 6: System Setup Rules
CH-40 jack on the LONG RANGER III control panel goes out. 3) Set up the system so that the LONG RANGER III is as far from large metal surfaces as possible. Metal surfaces under the unit (such as pickup truck cabs) are generally no problem but large metal surfaces alongside the LONG RANGER III may interfere with reception. - Page 7 REMEMBER--the transmitter gain control is used only to adjust for proper MOD LEVEL lamp indications. DO NOT use it to adjust the output volume of the LONG RANGER III speaker. Different voices and different microphones will usually require readjustment of the transmitter gain control, so check the adjustment frequently. If several different people will be using the system and there is not time to make the adjustment for each individual, adjust it for the loudest voice.
-
Page 8: Using Additional Speakers
H300 into the right speaker jack. The ES300 column speaker, on the other hand, will not be nearly as loud as the built in horn, so it is normally used by itself, plugged into the left jack on the LONG RANGER III front panel. - Page 9 (the clear/white wire) to the antenna. Tighten both screws securely. 3) The Add-On receiver is to be mounted on the LONG RANGER III upright with velcro. The receiver should be positioned, control panel up, between the horn mounting screw and the screw which secures the battery pack to the upright.
-
Page 10: Initial Adjustments To The Add-On Receiver System
INITIAL ADJUSTMENTS TO THE ADD-ON RECEIVER SYSTEM 1) Set up the Long Ranger III system according to the Initial Equipment Adjustments on page 6. 2) Leave the Long Ranger III power turned on. Set both volume controls on the Long Ranger III control panel to minimum. -
Page 11: Multiple Long Ranger Iii Systems
MULTIPLE LONG RANGER III SYSTEMS A unique use of the AUX IN/OUT jack is for connecting two (or more) LONG RANGER III systems together for simulta- neous use. When the LONG RANGER IIIs are interconnected in this manner, they will operate like a single system. -
Page 12: Microphone Choices
The built-in volume control helps control feedback in difficult environments, such as when the user must be close to the LONG RANGER III. Worn on the head, the microphone will remain at a constant distance from the user’s mouth, which keeps the volume of the sound system constant as your head moves. -
Page 13: Accessories And Replacement Parts
HM142V and HM152V headset microphones 14040 Shoulder Strap For carrying LONG RANGER III 21329 Power Adapter Cord For connecting LONG RANGER III to vehicle cigarette lighter adapter. CCPRO Carying Case Molded, pre-cut foam lined SS-5 Tripod Stand 2-section legs, riser column; 60" max. height... -
Page 14: Troubleshooting
2) Hiss in sound system connected to LONG RANGER III. Turn off the LONG RANGER III. If hiss remains, problem is sound system. 3) Hiss in the Long Ranger III can be caused by poorly shielded computers, phone systems, older electronic organs, etc. Try turning off nearby suspect equipment. -
Page 15: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS’ service department is equipped and staffed to quickly repair your equipment. In warranty repairs are made at no charge in accordance with the terms of the warranty. Out of warranty repairs are charged at a modest flat rate plus parts and shipping. -
Page 16: Warranty
This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
